Detailed steps for configuring mysql8.0.20 with binlog2sql and simple backup and recovery

Detailed steps for configuring mysql8.0.20 with binlog2sql and simple backup and recovery

First step installation

1. Install MySQL

2. Install Python3

[root@localhost /]#yum install python3

3. Download the binlog2sql file to your local computer (the file is in Baidu Cloud)

[root@localhost /]#mkdir tools
[root@localhost /]#cd tools
[root@localhost tools]# ll
total 317440
-rw-r--r--. 1 root root 317440 Sep 21 23:55 binlog2sql.tar
[root@localhost tools]#tar -xvf binlog2sql.tar
[root@localhost tools]#cd binlog2sql
[root@localhost binlog2sql]# ll
total 52
drwxr-xr-x. 3 mysql mysql 91 Jun 13 08:14 binlog2sql
drwxr-xr-x. 2 mysql mysql 54 Jun 13 07:45 example
-rw-r--r--. 1 mysql mysql 35141 Jun 13 07:45 LICENSE
-rw-r--r--. 1 mysql mysql 9514 Jun 13 07:45 README.md
-rw-r--r--. 1 mysql mysql 54 Jun 13 07:45 requirements.txt
drwxr-xr-x. 2 mysql mysql 37 Jun 13 07:45 tests

4. Modify requirements.txt in binlog2sql, change PyMySQL==0.7.11 to 0.9.3, save and exit

[root@localhost binlog2sql]# vi requirements.txt
PyMySQL==0.9.3
wheel==0.29.0
mysql-replication==0.13

5. Install and check to make sure it is 0.9.3 or there will be an error

[root@localhost binlog2sql]# pip3 install -r requirements.txt
[root@localhost binlog2sql]# pip3 show pymysql
Name: PyMySQL
Version: 0.9.3
Summary: Pure Python MySQL Driver
Home-page: https://github.com/PyMySQL/PyMySQL/
Author: yutaka.matsubara
Author-email: [email protected]
License: "MIT"
Location: /usr/local/lib/python3.6/site-packages
Requires:

Step 2: Prepare MySQL data

1. It is best to add the security directory secure-file-priv=/test to the configuration file and restart MySQL

[root@localhost /]# mkdir test
[root@localhost /]# chown -R mysql.mysql test
[root@localhost mysqldata]#vi my.cnf
secure-file-priv=/test
basedir=/application/mysql
datadir=/data/mysql
socket=/data/mysqldata/mysql.sock
log_error=/data/mysqldata/mysql8.0.err
port=3306
server_id=6
secure-file-priv=/test
autocommit=0
log_bin=/data/mysqldata/mysql-bin
[root@localhost mysqldata]# systemctl start mysqld

Note: Everyone has a different configuration file path.

2. Enter MySQL

Welcome to the MySQL monitor. Commands end with ; or \g.
Your MySQL connection id is 11
Server version: 8.0.20 MySQL Community Server - GPL

Copyright (c) 2000, 2020, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> show master status\g;
+------------------+----------+--------------+------------------+-------------------+
| File | Position | Binlog_Do_DB | Binlog_Ignore_DB | Executed_Gtid_Set |
+------------------+----------+--------------+------------------+-------------------+
| mysql-bin.000001 | 156 | | | |
+------------------+----------+--------------+------------------+-------------------+

mysql> create database csdn;
mysql> use csdn
mysql> insert into t1 values(1),(2),(3),(4),(5),(6),(7),(8);
mysql> commit;
mysql> update t1 set id=10 where id=1;
mysql> delete from t1 where id=3;
mysql> commit;

The third step is to test the binlog2sql directory.

[root@localhost binlog2sql]# pwd
/tools/binlog2sql/binlog2sql
[root@localhost binlog2sql]# ll
total 24
-rwxr-xr-x. 1 mysql mysql 7747 Jun 13 07:45 binlog2sql.py
-rwxr-xr-x. 1 mysql mysql 11581 Jun 13 07:45 binlog2sql_util.py
-rw-r--r--. 1 mysql mysql 92 Jun 13 07:45 __init__.py
drwxr-xr-x. 2 mysql mysql 44 Jun 13 07:50 __pycache__

2. Start the operation of backing up the tables in the database
2.1 View the operations under the database csdn just now

 [root@localhost binlog2sql]# python3 binlog2sql.py -h 192.168.0.112 -P3306 -uroot -p123 -d csdn -t t1 --start-file='mysql-bin.000001'
USE b'csdn';
create database csdn;
USE b'csdn';
create table t1 (id int);
INSERT INTO `csdn`.`t1`(`id`) VALUES (1); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (2); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (3); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (4); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (5); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (6); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (7); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (8); #start 609 end 807 time 2020-09-25 02:21:21
UPDATE `csdn`.`t1` SET `id`=10 WHERE `id`=1 LIMIT 1; #start 917 end 1095 time 2020-09-25 02:21:39
DELETE FROM `csdn`.`t1` WHERE `id`=3 LIMIT 1; #start 917 end 1183 time 2020-09-25 02:21:48

2.2 Operations under the backup database csdn

[root@localhost binlog2sql]# python3 binlog2sql.py -h 192.168.0.112 -P3306 -uroot -p123 -d csdn -t t1 --start-file='mysql-bin.000001' >/test/binlog2sql.sql

2.3 View the sql file just backed up

[root@localhost binlog2sql]# cat /test/binlog2sql.sql
USE b'csdn';
create database csdn;
USE b'csdn';
create table t1 (id int);
INSERT INTO `csdn`.`t1`(`id`) VALUES (1); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (2); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (3); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (4); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (5); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (6); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (7); #start 609 end 807 time 2020-09-25 02:21:21
INSERT INTO `csdn`.`t1`(`id`) VALUES (8); #start 609 end 807 time 2020-09-25 02:21:21
UPDATE `csdn`.`t1` SET `id`=10 WHERE `id`=1 LIMIT 1; #start 917 end 1095 time 2020-09-25 02:21:39
DELETE FROM `csdn`.`t1` WHERE `id`=3 LIMIT 1; #start 917 end 1183 time 2020-09-25 02:21:48

3. View the delete statement separately

[root@localhost binlog2sql]# python3 binlog2sql.py -h 192.168.0.112 -P3306 -uroot -p123 -d csdn -t t1 --start-file='mysql-bin.000001' --sql-type=delete
USE b'csdn';
create database csdn;
USE b'csdn';
create table t1 (id int);
DELETE FROM `csdn`.`t1` WHERE `id`=3 LIMIT 1; #start 917 end 1183 time 2020-09-25 02:21:48

4. Save the delete statement in reverse to the sql file and view it

[root@localhost binlog2sql]# python3 binlog2sql.py -h 192.168.0.112 -P3306 -uroot -p123 -d csdn -t t1 --start-file='mysql-bin.000001' --sql-type=delete --start-position=917 --stop-position=1183 -B >/test/roll.sql
[root@localhost binlog2sql]# cat /test/roll.sql
INSERT INTO `csdn`.`t1`(`id`) VALUES (3); #start 917 end 1183 time 2020-09-25 02:21:48

5. Enter MySQL and restore deleted data

mysql> source /test/roll.sql
Query OK, 1 row affected (0.00 sec)
mysql> select * from t1;
+------+
|id|
+------+
| 10 |
| 2 |
| 4 |
| 5 |
| 6 |
| 7 |
| 8 |
| 3 |
+------+
8 rows in set (0.00 sec)

Summarize

This is the end of this article about the configuration of mysql8.0.20 with binlog2sql and the detailed steps of simple backup and recovery. For more relevant mysql8.0.20 binlog2sql configuration and backup and recovery content, please search for previous articles on 123WORDPRESS.COM or continue to browse the following related articles. I hope everyone will support 123WORDPRESS.COM in the future!
