Native js implements custom scroll bar component

Native js implements custom scroll bar component

This article example shares the specific code of js to implement a custom scroll bar component for your reference. The specific content is as follows

Functional requirements:

1. Create menu content according to the data structure and display it on the page;
2. After clicking the menu, the corresponding sub-menu content is displayed. If the overall content overflows, a scroll bar appears;
3. The height of the scroll bar should change as the overall content height changes.
4. Drag the scroll bar with the mouse and the overall content will scroll upwards.
5. When the mouse scrolls, the scroll bar and the overall content will also scroll accordingly.

Let’s take a look at the effect:

Default state:

Click the menu, and a scroll bar will appear after the content overflows;

Drag the scroll bar with the mouse, and the entire content scrolls up:

analyze:

  • This case includes two components: the accordion menu and the scroll bar, so they can be written separately and then integrated together.
  • In the folding menu, we need to consider the situation of multi-level menus and use recursion to do it. The structure of the data must be unified to facilitate data processing.
  • There are two proportional equations in the creation of the scroll bar . One is the height of the scroll bar / the height of the outer div = the height of the outer div / the height of the overall content; the other is the position of the scroll bar / (the height of the outer div - the height of the scroll bar) = the scrollTop of the content / (the height of the overall content - the height of the outer div)
  • When the collapse menu is clicked, the height of the scroll bar needs to be set accordingly. The folding menu is in the Menu.js file, and the scroll bar setting is in the ScrollBar.js file, which requires throwing and listening events.
  • Monitor the mouse scrolling events of the menu. When the mouse scrolls, determine the direction of the scroll wheel and set the top value of the scroll bar and content. Event throwing and monitoring are also required.

The code is attached below:

HTML structure, simulate data, create outer container:

<!DOCTYPE html>
<html lang="en">
<head>
 <meta charset="UTF-8">
 <meta name="viewport" content="width=device-width, initial-scale=1.0">
 <title>scrollBar</title>
</head>
<body>
 <script type="module">
 import Utils from './js/Utils.js';
 import Menu from './js/Menu.js';
 import ScrollBar from './js/ScrollBar.js';
 var arr = [
  {name:"A",category:[
  {name:"Audi",category:[
   {name:"Audi A3",href:""},
   {name:"Audi A4L",category:[
   {name:"Audi A4L-1",href:""}
   ]},
   {name:"Audi Q3",href:""},
   {name:"Audi Q5L",href:""},
   {name:"Audi Q2L",href:""},
   {name:"Audi Q7 (Imported)",href:""},
   {name:"Audi Q8 (Imported)",href:""},
   {name:"Audi Q7 New Energy",href:""},
  ]},
  {name:"Alfa Romeo",category:[
   {name:"Stelvio (Imported)",href:""},
   {name:"Giulia (Imported)",href:""},
  ]}
  ]},
  {name:"B",category:[
  {name:"Mercedes-Benz",category:[
   {name:"Mercedes-Benz C-Class",href:""},
   {name:"Mercedes-Benz E-Class",href:""},
   {name:"Mercedes-Benz GLA-Class",href:""},
   {name:"Mercedes-Benz GLC-Class",href:""},
   {name:"Mercedes-Benz A-Class",href:""},
   {name:"Mercedes-Benz E-Class (Imported)",href:""},
   {name:"Mercedes-Benz A-Class (Imported)",href:""},
   {name:"Mercedes-Benz B-Class (Imported)",href:""},
   {name:"威霆",href:""},
   {name:"Mercedes-Benz V-Class",href:""},
  ]},
  {name:"BMW",category:[
   {name:"BMW 5 Series",href:""},
   {name:"BMW 1 Series",href:""},
   {name:"BMW X1",href:""},
   {name:"BMW X5 (Imported)",href:""},
   {name:"BMW X6 (Imported)",href:""},
  ]},
  {name:"Honda",category:[
   {name:"Jingrui",href:""},
   {name:"Civic",href:""},
   {name:"Honda CR-V",href:""},
   {name:"Honda XR-V",href:""},
   {name:"Honda UR-V",href:""},
   {name:"Elysion",href:""},
   {name:"Xiangyu",href:""},
   {name:"INSPIRE",href:""},
   {name:"Lingpai",href:""},
   {name:"Accord",href:""},
   {name:"Binzhi",href:""},
  ]},
  {name:"Buick",category:[
   {name:"Kailue",href:""},
   {name:"英朗",href:""},
   {name:"威朗",href:""},
   {name:"YueLang",href:""},
   {name:"Regal",href:""},
   {name:"LaCrosse",href:""},
   {name:"Angkola",href:""},
   {name:"Envision",href:""},
   {name:"Buick GL8",href:""},
   {name:"Buick GL6",href:""},
   {name:"VELITE",href:""},
  ]}
  ]}
 ]
 var container;
 init();
 function init(){
  createMenu(arr);
  createScrollBar();
 }
  function createMenu(arr){
  //Create a menu let menu=new Menu(arr);
  //Create the outermost container container=Utils.createE("div",{
  width:"235px",
  height:"360px",
  border:"1px solid #ccc",
  position:"relative",
  overflow:"hidden"
  })
  menu.appendTo(container);
  Utils.appendTo(container,"body")
 }
 function createScrollBar(){
  //Create a scroll bar let scrollBar=new ScrollBar(container);
  scrollBar.appendTo(container);
 }
 </script>
</body>
</html>

Menu.js file, creates the folding menu content according to the data:

import Utils from './Utils.js';
export default class Menu{
 static SET_BAR_HEIGHT="set_bar_height";
 static MOUSE_WHEEL_EVENT="mouse_wheel_event";
 constructor(_list){
 this.elem = this.createElem(_list);
 }
 createElem(_list){
 if(this.elem) return this.elem;
 //Create the outermost ul container let ul=Utils.createE("ul",{
  listStyle:"none",
  padding:"0px",
  margin:"0px",
  width:"235px",
  height:"360px",
  color:"#333",
  fontSize:"14px",
  userSelect: "none",
  position:"absolute"
 });
 //Create li list this.createMenu(_list,ul);
 //ul listens for click events ul.addEventListener("click",e=>this.clickHandler(e));
 //ul listens for scroll wheel events, Firefox uses DOMMouseScroll, other browsers use mousewheel
 ul.addEventListener("mousewheel",e=>this.mouseWheelHandler(e));
 ul.addEventListener("DOMMouseScroll",e=>this.mouseWheelHandler(e));
 return ul;
 }
 appendTo(parent){
 Utils.appendTo(this.elem,parent);
 }
 //Create a first level menu createMenu(_list,parent){
 for(let i=0;i<_list.length;i++){
  let li = Utils.createE("li",{
  background:"#f5f5f5",
  borderTop:"1px solid #ddd",
  lineHeight:"32px",
  },{
  data:1, //Control the first level menu from being folded by clicking})
  let span = Utils.createE("span",{
  marginLeft:"14px",
  fontSize:"18px"
  },{
  textContent:_list[i].name
  })
  Utils.appendTo(span,li);
  Utils.appendTo(li,parent);
  //Create a submenu. The third parameter controls whether the submenu is displayed this.createSubMenu(_list[i].category,li,0);
 }
 }
 //Create a submenu createSubMenu(_subList,_parent,_index){
 //If there is no submenu, jump out if(_subList.length===0) return;
 let subUl=Utils.createE("ul",{
  listStyle:"none",
  background:"#fff",
  padding:"0px",
  margin:"0px",
  fontSize:"14px",
  display:_index===0? "block" : "none"
 })
 for(let i=0;i<_subList.length;i++){
  let subLi=Utils.createE("li",{
  paddingLeft:"40px",
  position:"relative",
  cursor:"pointer"
  })
  if(!_subList[i].category){
  //If the current menu has no submenu, create a tag to jump let subA=Utils.createE("a",{
   color:"#333",
   textDecoration:"none",
   width:"100%",
   display:"inline-block"
  },{
   textContent:_subList[i].name,
   href:_subList[i].href || "javascript:void(0)",
   target:_subList[i].href ? "_blank" : "_self"
  })
  Utils.appendTo(subA,subLi);
  }else{
  //If the current menu has a submenu, create a span tag let subSpan=Utils.createE("span",{
   position:"absolute",
   left:"20px",
   top:"8px",
   border: "1px solid #ccc",
   display: "inline-block",
   width: "10px",
   height: "10px",
   lineHeight:"8px"
  },{
   textContent:_subList[i].category.length>0? "+" : "-"
  })
  subLi.textContent=_subList[i].name;
  Utils.appendTo(subSpan,subLi);
  }
  Utils.appendTo(subLi,subUl);
  //If the current menu has no submenu, skip the following execution if(!_subList[i].category) continue;
  //Use the submenu of the current menu as a parameter and perform recursion this.createSubMenu(_subList[i].category,subLi,1);
 }
 Utils.appendTo(subUl,_parent);
 }
 clickHandler(e){
 //If the current click is not a li tag or span, jump out directly if(e.target.nodeName!=="LI" && e.target.nodeName!=="SPAN") return;
 let targ;
 if(e.target.nodeName==="SPAN") targ=e.target.parentElement;
 else targ=e.target;
 //If there is no submenu under the current click Li, jump out directly if(targ.children.length<=1) return;
 //If the current click is the first-level menu, jump out directly if(targ.data===1) return;
 //Control the display and hide of ul under the currently clicked Li if(!targ.bool) targ.lastElementChild.style.display="block";
 else targ.lastElementChild.style.display="none";
 targ.bool=!targ.bool;
 //Change the content of the span tag this.changeSpan(targ);
 //Throw an event to change the height of the scroll bar var evt = new Event (Menu.SET_BAR_HEIGHT);
 document.dispatchEvent(evt)
 }
 changeSpan(elem){
 if(elem.lastElementChild.style.display==="block"){
  elem.firstElementChild.textContent="-";
 }else{
  elem.firstElementChild.textContent="+";
 }
 }
 mouseWheelHandler(e){
 //Stop event bubbling e.stopPropagation();
 //Firefox checks e.detail. When e.detail<0, it means the wheel is down and the page is up. let tag=e.detail,wheelDir;
 //Other browsers judge e.deltaY. When e.deltaY<0, it means the scroll wheel is down and the page is up if(tag===0) tag=e.deltaY;

 if(tag>0){
  //The wheel scrolls down and the page goes up wheelDir="down";
 }else{
  wheelDir="up";
 }
 //Throw an event and pass the scroll wheel direction let evt = new Event(Menu.MOUSE_WHEEL_EVENT);
 evt.wheelDirection=wheelDir;
 this.elem.dispatchEvent(evt);
 }
}

ScrollBar.js file, create a scroll bar, and operate the scroll bar:

import Utils from './Utils.js';
import Menu from './Menu.js';
export default class ScrollBar {
 bar;
 conHeight;
 menuHeight;
 wheelSpeed=6;
 barTop=0;
 static SET_BAR_HEIGHT="set_bar_height";
 constructor(parent) {
 this.container = parent;
 this.menuUl=this.container.firstElementChild;
 this.elem = this.createElem();
 //Listen to the menu's click event and dynamically change the scroll bar's height document.addEventListener(ScrollBar.SET_BAR_HEIGHT,()=>this.setBarHeight());
 //ul menu listens for wheel events this.menuUl.addEventListener(Menu.MOUSE_WHEEL_EVENT,e=>this.mouseWheelHandler(e));
 }
 createElem() {
 if (this.elem) return this.elem;
 //Create the outer container of the scroll bar let div = Utils.createE("div", {
  width: "8px",
  height: "100%",
  position: "absolute",
  right: "0px",
  top: "0px",
 })
 this.createBar(div);
 return div;
 }
 appendTo(parent) {
 Utils.appendTo(this.elem,parent);
 }
 createBar(_parent) {
 if(this.bar) return this.bar;
 //Create scroll bar this.bar = Utils.createE("div", {
  width: "100%",
  position: "absolute",
  left: "0px",
  top: "0px",
  borderRadius: "10px",
  backgroundColor: "rgba(255,0,0,.5)"
 })
 //Set the scroll bar hover state style this.bar.addEventListener("mouseenter",e=>this.setMouseStateHandler(e));
 this.bar.addEventListener("mouseleave",e=>this.setMouseStateHandler(e));
 //Set the height of the scroll bar this.setBarHeight();
 //Listen for mouse drag events this.mouseHand = e => this.mouseHandler(e);
 this.bar.addEventListener("mousedown", this.mouseHand);
 Utils.appendTo(this.bar, _parent);
 }
 setBarHeight() {
 //The height of the outer parent container this.conHeight = this.container.clientHeight;
 //The actual content height this.menuHeight = this.container.firstElementChild.scrollHeight;
 //If the actual content height is less than the parent container height, the scroll bar is hidden if (this.conHeight >= this.menuHeight) this.bar.style.display = "none";
 else this.bar.style.display = "block";
 //Calculate the height of the scroll bar let h = Math.floor(this.conHeight / this.menuHeight * this.conHeight);
 this.bar.style.height = h + "px";
 }
 setMouseStateHandler(e){
 //Set the scroll bar hover state style if (e.type == = "mouseenter") {
  this.bar.style.backgroundColor="rgba(255,0,0,1)";
 }else{
  this.bar.style.backgroundColor="rgba(255,0,0,.5)";
 }
 }
 mouseHandler(e) {
 switch (e.type) {
  case "mousedown":
  e.preventDefault();
  this.y = e.offsetY;
  document.addEventListener("mousemove", this.mouseHand);
  document.addEventListener("mouseup", this.mouseHand);
  break;
  case "mousemove":
  //Note: In the result returned by getBoundingClientRect(), width and height both include border var rect = this.container.getBoundingClientRect();
  this.barTop = e.clientY - rect.y - this.y;
  //Scroll bar movement this.barMove();
  break;
  case "mouseup":
  document.removeEventListener("mousemove", this.mouseHand);
  document.removeEventListener("mouseup", this.mouseHand);
  break;
 }
 }
 mouseWheelHandler(e){
 //Roller event if(e.wheelDirection==="down"){
  //Scroll down, menu content goes up this.barTop+=this.wheelSpeed;
 }else{
  this.barTop-=this.wheelSpeed;
 }
 //Scroll bar movement this.barMove();
 }
 barMove(){
 if (this.barTop < 0) this.barTop = 0;
 if (this.barTop > this.conHeight - this.bar.offsetHeight) this.barTop = this.conHeight - this.bar.offsetHeight;
 this.bar.style.top = this.barTop + "px";
 //Menu content scrolling this.menuMove();
 }
 menuMove(){
 //Calculate the scroll height of the content let menuTop=this.barTop/(this.conHeight-this.bar.offsetHeight)*(this.menuHeight-this.conHeight);
 this.menuUl.style.top=-menuTop+"px";
 }
}

Utils.js file is a toolkit:

export default class Utils{
 static createE(elem,style,prep){
 elem = document.createElement(elem);
 if(style) for(let prop in style) elem.style[prop]=style[prop];
 if(prep) for(let prop in prep) elem[prop]=prep[prop];
 return elem;
 }
 static appendTo(elem,parent){
 if (parent.constructor === String) parent = document.querySelector(parent);
 parent.appendChild(elem);
 }
 static randomNum(min,max){
 return Math.floor(Math.random*(max-min)+min);
 }
 static randomColor(alpha){
 alpha=alpha||Math.random().toFixed(1);
 if(isNaN(alpha)) alpha=1;
 if(alpha>1) alpha=1;
 if(alpha<0) alpha=0;
 let col="rgba(";
 for(let i=0;i<3;i++){
  col+=Utils.randomNum(0,256)+",";
 }
 col+=alpha+")";
 return col;
 }
 static insertCss(select,styles){
 if(document.styleSheets.length===0){
  let styleS = Utils.createE("style");
  Utils.appendTo(styleS,document.head);
 }
 let styleSheet = document.styleSheets[document.styleSheets.length-1];
 let str=select+"{";
 for(var prop in styles){
  str+=prop.replace(/[AZ]/g,function(item){
  return "-"+item.toLocaleLowerCase();
  })+":"+styles[prop]+";";
 }
 str+="}"
 styleSheet.insertRule(str,styleSheet.cssRules.length);
 }
 static getIdElem(elem,obj){
 if(elem.id) obj[elem.id]=elem;
 if(elem.children.length===0) return obj;
 for(let i=0;i<elem.children.length;i++){
  Utils.getIdElem(elem.children[i],obj);
 }
 }
}

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.

You may also be interested in:
  • Implementing custom scroll bar with native js
  • js realizes automatic scrolling of the scroll bar
  • Vue.js desktop custom scroll bar component beautification scroll bar VScroll
  • JS custom scroll bar effect
  • JavaScript implements a simple chat dialog box (with scroll bar)
  • Implementation of js custom scroll bar using js wheel event
  • JS implements scroll bar bottoming out to load more
  • Using js to implement a simple scroll bar process analysis
  • layer.js open example of hiding scroll bar
  • Vue pure js monitors the example of the scroll bar to the bottom
  • JavaScript gets the scroll bar position and slides the page to the anchor point

<<:  A quick solution to the error #1929 Incorrect datetime value: '''' for column ''createtime'' when using MySQL 5.x or above

>>:  Linux concurrent execution is simple, just do it this way

Recommend

Solution to 2059 error when connecting Navicat to MySQL

Recently, when I was learning Django, I needed to...

JavaScript error handling try..catch...finally + covers throw+TypeError+RangeError

Table of contents 1. Purpose 2. Grammar 3. Practi...

Introduction to TypeScript basic types

Table of contents 1. Basic types 2. Object Type 2...

Sample code for implementing DIV suspension with pure CSS (fixed position)

The DIV floating effect (fixed position) is imple...

Practical operation of using any font in a web page with demonstration

I have done some research on "embedding non-...

How to introduce img images into Vue pages

When we learn HTML, the image tag <img> int...

Summary of problems encountered in the implementation of Vue plug-ins

Table of contents Scene Introduction Plugin Imple...

Steps to use VMWare to build a Linux environment under Windows (picture and text)

Since I returned the Mac, my original laptop has ...

7 skills that web designers must have

Web design is both a science and an art. Web desi...

html base url tag

Its function is to set a global style. Then your s...

Linux uses stty to display and modify terminal line settings

Sttty is a common command for changing and printi...

Using Docker+jenkins+python3 environment to build a super detailed tutorial

Preface: After the automation is written, it need...

Implementing the page turning effect through sliding and the click event problem on the mobile terminal

aforementioned This article is very short~ The ma...

Conditional comments to determine the browser (IE series)

<!--[if IE 6]> Only IE6 can recognize <![...

Tutorial diagram of installing mysql8.0.18 under linux (Centos7)

1 Get the installation resource package mysql-8.0...
