Nginx builds rtmp live server implementation code

1. Create a new rtmp directory in the nginx source directory and enter git clone https://github.com/arut/nginx-rtmp-module.git

2. Recompile nginx code as follows

./configure --prefix=/usr/local/nginx-1.2.9/ --add-module=./rtmp/nginx-rtmp-module --with-http_ssl_module --with-pcre=/lamp_source/pcre-8.38;
make;make install;
#Reinstall nginx

3. After completing the installation.

Open nginx.conf and add the following code after http{server...}

rtmp{
    server{
        listen 1935;
        chunk_size 4000;
        application hls
            live on;
            hls on;
            hls_path /your server path is used to store cache files. Must be writable;
            hls_fragment 5s;
        }
    }
}

Then create a new host configuration

server {

    listen 8851;
    location /index.html {
    root /website storage directory;
}
    location / {# return 403;
      # Serve HLS fragments
      types {
        application/vnd.apple.mpegurl m3u8;
        video/mp2t ts;
      }
      root /same as above, for caching;
      expires -1;
    }
  }

After completing the above configuration. Just download a software called open broadcaster software and use it to push the stream (note that you can also use ffmpeg to push the stream). Software usage as shown in screenshots

Then click Start Streaming.

Download and open VLC player (streaming). Enter rtmp://your website:1935/hls/the password in the picture above and it will be ok. Successful online live broadcast
