Detailed steps for porting busybox to build a minimal root file system

Busybox: A Swiss Army knife filled with small commands.

STEP 1: Create a directory structure

Create the root file system directory, mainly including the following directories

/dev /etc /lib /usr /var /proc /tmp /home /root /mnt /bin /sbin /sys
#mkdir /home/rootfs
#cd /home/rootfs
#mkdir dev etc lib usr var proc tmp home root mnt sys

STEP 2: Use busybox to build /bin /sbin linuxrc

Enter the busybox-1.16.1 directory and execute

#make defconfig
#make menuconfig
Busybox Setting ----->
 Build Options ----->
  //1 Choose to compile busybox statically [*]Build BusyBox as a static binary (no shared libs)
  //2. Specify the cross compiler as (/usr/local/arm/4.3.2/bin/arm-linux-)Cross Compiler prefix
Installation Options -----> (Select the directory to store the generated files, or you can put them directly in rootfs without copying)

  //3. Select Don't use /usr
Busybox Library Tuning--->
 [*]Username completion
 [*]Fancy shell prompts
 [*]Query cursor position from terminal
  //4. The compiled busybox shell command interpreter supports displaying the current path and host information

Save and exit

#make #make install

In the busybox directory, you will see the _install directory, which contains three files: /bin /sbin and linuxrc. Copy these three directories or files to the rootfs folder created in the first step.

#cp bin/ sbin/ linuxrc /home/rootfs -ra

Remember to bring the -a parameter, because most of the bin directory is links. If you don't bring the -a parameter, it will be copied accordingly after copying, and it will no longer be in the form of a link.

STEP 3 Build the etc directory: (mainly etc/inittab file, etc/init.d/rcs, etc/fstab)

1) Enter the etc directory of the root file system rootfs and perform the following operations:

Copy Busybox-1.16.1/examples/bootfloopy/etc/* to the current directory

 #cp –r busybox-1.16.1/examples/bootfloopy/etc/* rootfs/etc

Modify inittab, (create other subprocesses based on it)

The original file is:

1 ::sysinit:/etc/init.d/rcS 2 ::respawn:-/bin/sh　
    3 tty2::askfirst:-/bin/sh 4 ::ctrlaltdel:/bin/umount -a -r

After modification:

---(1): Start the computer without logging in, and directly open the shell (the number in front is the line number)

1 ::sysinit:/etc/init.d/rcS　
        2 #::respawn:-/bin/sh　
        3 #::respawn:-/bin/login　
        4 console::askfirst:-/bin/sh　
        5 #tty2::askfirst:-/bin/sh 6 ::ctrlaltdel:/bin/umount -a -r

---(2): You need to log in to boot up (the number in front is the line number)

 1 ::sysinit:/etc/init.d/rcS　
        2 #::respawn:-/bin/sh　
      3 ::respawn:-/bin/login　
        4 #console::askfirst:-/bin/sh　
       5 #tty2::askfirst:-/bin/sh　
       6 ::ctrlaltdel:/bin/umount -a -r

2) Copy /etc/passwd, /etc/group, /etc/shadow on the virtual machine to rootfs/etc

  # cp /etc/passwd rootfs/etc
  # cp /etc/group rootfs/etc
  # cp /etc/shadow roofs/etc

Modify the following three files and only save the items related to root. The content will vary depending on the specific situation.

Change passwd to root:x:0:0:root:/root:/bin/sh, which means only save items related to root, and finally change it to /bin/ash.

Change group to root:x:0:root

Modify shadow to root:$1$x9yv1WlB$abJ2v9jOlOc9xW/y0QwPs.:14034:0:99999:7:::

When logging into the development board, you need to enter your username and password, which is the same as the virtual machine.

3) Modify profile

PATH=/bin:/sbin:/usr/bin:/usr/sbin //Executable program environment variable export LD_LIBRARY_PATH=/lib:/usr/lib //Dynamic link library environment variable /bin/hostname osee
  USER="`id -un`"
  LOGNAME=$USER
  HOSTNAME='/bin/hostname'
  PS1='[\u@\h \W]# ' //Display host name, current path and other information:

4) Modify the etc/init.d/rc.S file (add automatic execution commands) #! /bin/sh

/bin/mount -n -t ramfs ramfs /var　
   /bin/mount -n -t ramfs ramfs /tmp
  /bin/mount -n -t sysfs none /sys
  /bin/mount -n -t ramfs none /dev
  /bin/mkdir /var/tmp
  /bin/mkdir /var/modules
  /bin/mkdir /var/run
  /bin/mkdir /var/log
  /bin/mkdir -p /dev/pts //Required by telnet service /bin/mkdir -p /dev/shm //Required by telnet service #echo /sbin/mdev > /proc/sys/kernel/hotplug //USB automatic mounting requires /sbin/mdev -s //Start mdev to automatically create device file nodes under /dev /bin/mount -a
  ########Configure Network#################################
  /sbin/ifconfig lo 127.0.0.1 netmask 255.0.0.0
  /sbin/ifconfig eth0 192.168.1.70
  /sbin/ifconfig eth0 netmask 255.255.255.0
  /sbin/route add default gw 192.168.1.1 eth0
  /sbin/ifconfig eth1 192.168.1.71 netmask 255.255.255.0
  /sbin/route add default gw 192.168.1.1 eth1

5) Modify the etc/fstab file and add the following file to mount the proc tmpfs file system

#device mount-point type options dump fsck order
  none /dev/pts devpts mode=0622 0 0
  tmpfs /dev/shm tmpfs defaults 0 0
  proc /proc proc defaults 0 0

STEP 4 Build the lib directory:

(~/at91/x-tools/arm-zch-linux-gnueabi/arm-zch-linux-gnueabi/sysroot/lib, I just copy the SO file in this directory)

1 )#cd /usr/local/arm/4.3.2/arm-none-linux-gnueabi/libc/armv4t/lib

Copy the following dynamic libraries to rootfs/lib

#cp *so* roofs/lib -a

2 )#cd /usr/local/arm/4.3.2/arm-none-linux-gnueabi/libc/armv4t/usr/lib

Copy the following dynamic libraries to rootfs/lib

#cp ./libstdc++.so.* rootfs/lib -a

STEP 5 Build the lmdev directory:

Method 1: Statically create device files cat /proc/devices

mknod console c 5 1
mknod null c 1 3
mknod ttySAC0 c 204 64
mknod mtdblock0 b 31 0

Method 2: Use mdev to create a device file

Make sure your kernel sets CONFIG_SYSFS CONFIG_TMPFS

When the kernel starts, mdev is automatically run

Modify etc/fstab to automatically mount the root file system. Modify etc/init.d/rcS to add commands to run automatically.

Summarize
