JavaScript realizes the queue structure process

JavaScript realizes the queue structure process

1. Understanding Queues

The previous blog has talked about the restricted data structure - the stack. Now, let’s take a look at the Queue .

  • It is a restricted linear list, first in first out ( FIFO ), that is, first in first out.
  • It is limited in that it only allows delete operations on the front of the table.
  • Insertion operations are performed at the rear of the table.

Its structure diagram can be expressed as:

Something similar to queues in life: for example , when we queue up to buy something, first come first served.

2. Encapsulation Queue

The queue structure is also implemented in an array format. First, create a class.

 function Queue(){

        }

Add properties and methods inside it, and add the array to the class through the property methods. Then use the prototype method to add commonly used operations.

Common operations on queues are:

  • enqueue (element): Add one (or more) new items to the end of the queue
  • dequeue() : Removes the first item in the queue and returns the removed element.
  • front() : Returns the first element in the queue - the first element to be added and the first element to be removed
  • isEmpty() : Returns true if the queue does not contain any elements, otherwise returns false
  • size() : Returns the number of elements in the queue
  • toString() : Convert the contents of the queue into a string

Now let’s implement it:

function Queue(){
     this.items = [];
     //Add one (or more) new items to the end of the queue enqueue()
     Queue.prototype.enqueue = function(element){
         this.items.push(element);
     }
     //Remove the first item in the queue (i.e. the front item in the queue) dequeue()
     Queue.prototype.dequeue = function(){
          return this.items.shift();
      }
     //Return the first element in the queue front()
     Queue.prototype.front = function() {
          return this.items[0];
      }
     // Check if the stack is empty isEmpty()
     Queue.prototype.isEmpty = function(){
         return this.items.length == 0;
     }
     //Return the number of elements contained in the queue size()
     Queue.prototype.size = function(){
         return this.items.length;
     }
     //Convert the contents of the queue into a string form toString()
     Queue.prototype.toString = function(){
         var str = '';
         for(var i =0;i<this.items.length;i++){
             str += this.items[i] + ' ';
         }
         return str;
     }
 }

The above is the encapsulation of the queue, now verify it:

 var queue = new Queue();
 queue.enqueue(10);
 queue.enqueue(20);
 queue.enqueue(30);
 queue.enqueue(40);
 queue.enqueue(50);
 console.log(queue);
 console.log('The first item removed is: ' + queue.dequeue());
 console.log('The first element in the queue is: ' + queue.front());
 console.log('Is the stack empty: '+queue.isEmpty());
 console.log('The contents of the stack structure are:');
 console.log(queue.toString());

The output is:

Build successful.

Let’s take a look at a case of passing the parcel while beating the drum!

3. The Case of Passing the Flower by Beating the Drum

Original game rules:

  • Play a game in the class. All students stand in a circle and pass a bouquet of flowers from one student to the next student.
  • At this time, a man is beating a drum. When the drum stops, whoever holds the flower will be punished.

Modify the game rules:

  • A few friends play a game together. They sit in a circle and start counting. The person who counts to a certain number is automatically eliminated.
  • The last person left wins. Which position does the last person left from win?

Encapsulate a queue-based function:

  • Parameters: names of all participants, numbers based on
  • Result: The name of the person who is left at the end

The code is as follows:

 // Encapsulate queue function Queue(){
     this.items = [];
     //Add elements at the end Queue.prototype.enqueue = function(element){
         this.items.push(element);
     }
     //Remove the first element Queue.prototype.dequeue = function(){
         return this.items.shift();
     }
     //Return the first element Queue.prototype.front = function(){
         return this.items[0];
     }
     //Return the number of elements contained in the queue Queue.prototype.size = function(){
         return this.items.length;
     }
 }

 function passGame(nameList,num){
     // Create a queue var queue = new Queue();
     //Add all people to the queue for(var i = 0;i<nameList.length;i++){
         queue.enqueue(nameList[i]);
     }
     //Play the game while (queue.size() > 1) {
         //The people before num are added to the end of the queue for(var i =1;i<num;i++){
             queue.enqueue(queue.dequeue());
         }
       //People with num numbers are directly removed from queue.dequeue();
    }
    //Get the winner information var endName = queue.front();
    console.log('The remaining people are:' + endName);
    return nameList.indexOf(endName);
 }

 //Test var nameList = ['a','b','c','d','e'];
 var g = passGame(nameList,5);
 console.log('This person's location is: '+g);

The output is:

This is the end of this article about the process of implementing queue structure in JavaScript. For more relevant content about implementing queue structure in JavaScript, please search previous articles on 123WORDPRESS.COM or continue to browse the following related articles. I hope you will support 123WORDPRESS.COM in the future!
