The implementation principle of Zabbix dynamic execution monitoring collection script

When using Zabbix custom scripts to collect monitoring data, you will usually encounter the following problems:

• After the server capacity is expanded, how to deploy the monitoring script to the new server?
• When a monitoring script needs to be modified, how can all identical monitoring scripts be automatically modified?
• How to back up monitoring and collection scripts to avoid loss due to server abnormalities?
• How to avoid excessive operations by system administrators when deploying custom monitoring?
• How can we solve the above problems without extensive R&D?

Implementation principle : Use the file server to uniformly store and manage monitoring scripts, pre-embed the general script in the zabbix agent, and pull the script from the file server according to the key and parameters transmitted by the zabbix server and return the data after execution.

Architecture design:

Specific implementation:

1. Build a file server, taking nginx as an example

Modify the nginx configuration and restart

erver
    listen 8080;
    server_name zabbix;
    root /usr/local/static/;
    location / {
      autoindex on;
      autoindex_exact_size on;
      autoindex_localtime on;
      charset utf-8;
    }
  }

2. Write scripts for file pulling and execution

url="http://192.168.24.108:8080/" #Define the URL of the file server
parentDir="/usr/local/zabbix/bin/zabbix_script"
file_directory=$parentDir/$1 #Define the directory where the script is stored locally file_name=$2 #Script name file_path=$1/$2 #Join the script path of the file server if [ ! -d $file_directory ];then #Judge whether the file directory exists mkdir -p $file_directory
fi

if [ ! -f $parentDir/$file_path ];then #Judge whether the script already exists wget -P $file_directory $url$file_path 2>>log
fi

timestamp=$(date +%s)
filetimestamp=$(stat -c %Y $parentDir/$file_path)
if [ $[$timestamp - $filetimestamp] -gt 3600 ];then #Judge the difference between the current time and the script modification time, and update every 3600 seconds wget $url$file_path -O $parentDir/$file_path 2>>log #Overwrite the script touch -c $parentDir/$file_path #Modify the script modification time fi
python $parentDir/$file_path $3 #Execute the script

3. Add the configuration file of zabbix

UserParameter=requests_file[*],sh /usr/local/zabbix/bin/zabbix_script/requests_file.sh $1 $2 $3

4. Restart zabbix agent

5. Write the test script and upload it to the specified directory of the file server

#Monitor the number of server connections#!/usr/bin/python
import pwd
import os,sys
import re
import glob
state = sys.argv[1]

cmd = "netstat -an | grep " + state + " | wc -l"
os.system(cmd)

6. Configure the monitoring items of the zabbix page:

7. Observe whether the data is normal:

8. The new monitoring script is placed after the file server, and the monitoring items of the configuration page can be directly configured for data collection.

This article focuses on providing a solution for centralized management of custom monitoring scripts in Zabbix. Based on this idea, you can freely expand the use of Zabbix to be more concise and efficient, further simplifying operation and maintenance.
