How to create a simple column chart using Flex layout in css
|
The following is a bar chart using Flex layout:
HTML:
<div class="his_box">
<div>Score distribution histogram</div>
<div class="histogram">
<div><div>10</div></div>
<div><div>8</div></div>
<div><div>15</div></div>
<div><div>12</div></div>
<div><div>5</div></div>
</div>
</div>CSS:
.his_box{ /*box*/
width: 400px;
height: 220px;
border: solid 1px #1E90FF;
display: flex;
flex-direction: column;
align-items: center;
}
.histogram{ /*histogram*/
display: flex;
}
.histogram>div{ /*a tile*/
width: 30px;
height: 200px; /*Block height at 100%*/
font-size: 14px;
text-align: center;
margin-right: 5px;
display: flex;
flex-direction: column-reverse;
}
.histogram>div:nth-child(3n) div{ /*tile color*/
background-color: #ff404b;
}
.histogram>div:nth-child(3n+1)div{
background-color: #99CCFF;
}
.histogram>div:nth-child(3n+2)div{
background-color: #F0AD4E;
}
.histogram>div:nth-child(1)div{
flex: 0 0 50%; /*20 is 100%, 50% is 10*/
}
.histogram>div:nth-child(2)div{
flex: 0 0 40%; /*8/20*/
}
.histogram>div:nth-child(3)div{
flex: 0 0 75%; /*15/20*/
}
.histogram>div:nth-child(4)div{
flex: 0 0 60%; /*12/20*/
}
.histogram>div:nth-child(5)div{
flex: 0 0 25%; /*5/20*/
}In this example, the highest point of the tile is 20, and the height of each column is defined proportionally: the first data is 10, and the height is 50%; the second data is 8, and the height is 40%, and so on. The tile colors are cycled through 3 colors. During layout, the outermost container uses align-items: center; to center the elements within the container as a whole. The histogram module uses display: flex; to arrange the columns in the module horizontally. Each column is also a flex module, but its layout direction is vertical, and the direction is from bottom to top flex-direction: column-reverse; If you want to make a vertically arranged histogram:
CSS:
.his_box{ /*box*/
width: 400px;
height: 220px;
border: solid 1px #1E90FF;
display: flex;
flex-direction: column;
justify-content: space-between;
}
.his_box>div{
text-align: center;
}
.histogram{ /*histogram*/
display: flex;
flex-direction: column;
}
.histogram>div{ /*a tile*/
height: 30px;
width: 200px; /*Block width at 100%*/
line-height: 30px;
font-size: 14px;
text-align: right;
margin-bottom: 5px;
display: flex;
}
.histogram>div:nth-child(3n) div{ /*tile color*/
background-color: #ff404b;
}
.histogram>div:nth-child(3n+1)div{
background-color: #99CCFF;
}
.histogram>div:nth-child(3n+2)div{
background-color: #F0AD4E;
}
.histogram>div:nth-child(1)div{
flex: 0 0 50%; /*20 is 100%, 50% is 10*/
}
.histogram>div:nth-child(2)div{
flex: 0 0 40%; /*8/20*/
}
.histogram>div:nth-child(3)div{
flex: 0 0 75%; /*15/20*/
}
.histogram>div:nth-child(4)div{
flex: 0 0 60%; /*12/20*/
}
.histogram>div:nth-child(5)div{
flex: 0 0 25%; /*5/20*/
}This is the end of this article about how to use CSS to create a simple bar chart with Flex layout. For more relevant CSS bar chart content, please search 123WORDPRESS.COM's previous articles or continue to browse the following related articles. I hope that everyone will support 123WORDPRESS.COM in the future! |
