Example of how to quickly build a Redis cluster with Docker

# Enable cluster cluster-enabled yes

# Cluster configuration file cluster-config-file nodes-6379.conf

# Cluster node timeout cluster-node-timeout 15000

├── conf
│ ├── redis.conf
│ └── sentinel.conf
├── redis
│ ├── data_6379
│ ├── data_6380
│ ├── data_6381
│ ├── data_6382
│ ├── data_6383
│ └── data_6384
└── scripts
  ├── cluster.sh
  ├── run.sh
  └── sentinel.sh

#!/usr/bin/env bash
set -e

# Script current directory cPath=$(cd $(dirname "$0") || exit; pwd)

# Root directory dirPath=$(dirname "$cPath")

# Get the port port="$1"
if [[ ! "$port" ]]; then
 port=6379
fi

# Create a data directory mkdir -p "$dirPath"/redis/data_"$port"

# Delete the started service containerId=$(docker ps -a | grep "redis_$port" | awk -F' ' '{print $1}')
if [[ "$containerId" ]]; then
  docker rm -f ${containerId} > /dev/null
fi

# Start the service containerName=redis_"$port"
docker run -itd --privileged=true -p "$port":6379 --name ${containerName} \
-v="$dirPath"/conf/redis.conf:/etc/redis/redis.conf \
-v="$dirPath"/redis/data_"$port":/data \
redis \
redis-server /etc/redis/redis.conf > /dev/null

# Get the container IP address dockerIp=$(docker inspect -f "{{.NetworkSettings.IPAddress}}" "$containerName")

# Get the container startup status isRunning=$(docker inspect -f "{{.State.Running}}" "$containerName")
if [[ "$isRunning" == "true" ]]; then
  echo "Container: $containerName - IP: $dockerIp - Started successfully"
fi

#!/usr/bin/env bash
set -e

# Script current directory cPath=$(cd $(dirname "$0") || exit; pwd)

# Start the cluster number num="$1"
if [[ ! "$num" ]]; then
 num=6
fi

sPort=6378
for((i=1;i<=$num;i++)); do
  sh ${cPath}/run.sh $(($sPort+$i))
done

sh scripts/cluster.sh

root@DESKTOP-Q13EI52:~/docker-config/redis# docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
c0601df1a456 redis "docker-entrypoint.s..." 27 seconds ago Up 26 seconds 0.0.0.0:6384->6379/tcp redis_6384
6fecf70465b8 redis "docker-entrypoint.s..." 27 seconds ago Up 26 seconds 0.0.0.0:6383->6379/tcp redis_6383
1af15e90b7a0 redis "docker-entrypoint.s..." 28 seconds ago Up 27 seconds 0.0.0.0:6382->6379/tcp redis_6382
6c495f31a5df redis "docker-entrypoint.s..." 28 seconds ago Up 28 seconds 0.0.0.0:6381->6379/tcp redis_6381
e54fd9fd0550 redis "docker-entrypoint.s..." 29 seconds ago Up 28 seconds 0.0.0.0:6380->6379/tcp redis_6380
be92ad2f7046 redis "docker-entrypoint.s..." 29 seconds ago Up 29 seconds 0.0.0.0:6379->6379/tcp redis_6379

docker inspect -f "{{.NetworkSettings.IPAddress}}:6379" `docker ps | grep redis_ | awk -F' ' '{print $1}'` | sort |xargs | sed 's/ /, /g'

# Return result# 172.17.0.2:6379, 172.17.0.3:6379, 172.17.0.4:6379, 172.17.0.5:6379, 172.17.0.6:6379, 172.17.0.7:6379

./redis-cli --cluster create 172.17.0.2:6379, 172.17.0.3:6379, 172.17.0.4:6379, 172.17.0.5:6379, 172.17.0.6:6379, 172.17.0.7:6379 --cluster-replicas 1

licas 1
>>> Performing hash slots allocation on 6 nodes...
Master[0] -> Slots 0 - 5460
Master[1] -> Slots 5461 - 10922
Master[2] -> Slots 10923 - 16383
Adding replica 172.17.0.6:6379 to 172.17.0.2:6379
Adding replica 172.17.0.7:6379 to 172.17.0.3:6379
Adding replica 172.17.0.5:6379 to 172.17.0.4:6379
M: e8da1fef656984de3ec2a677edc8d9c48d01cd95 172.17.0.2:6379
  slots:[0-5460] (5461 slots) master
M: 68b925ab0fbbc1a632c1754587fb6dad3fa14c91 172.17.0.3:6379
  slots:[5461-10922] (5462 slots) master
M: 0a46ab2f6d176738b55fe699c2df1c34f8200d06 172.17.0.4:6379
  slots:[10923-16383] (5461 slots) master
S: bd3064ad5297dfc258e9236943455c589be8b2a3 172.17.0.5:6379
  replicates 0a46ab2f6d176738b55fe699c2df1c34f8200d06
S: f1d8c897882d29e6538b1158525493b3b782289a 172.17.0.6:6379
  replicates e8da1fef656984de3ec2a677edc8d9c48d01cd95
S: 619e1cb52f39e07b321719b77fc3631fa6293cef 172.17.0.7:6379
  replicates 68b925ab0fbbc1a632c1754587fb6dad3fa14c91
Can I set the above configuration? (type 'yes' to accept):

>>> Nodes configuration updated
>>> Assign a different config epoch to each node
>>> Sending CLUSTER MEET messages to join the cluster
Waiting for the cluster to join
.....
>>> Performing Cluster Check (using node 172.17.0.2:6379)
M: e8da1fef656984de3ec2a677edc8d9c48d01cd95 172.17.0.2:6379
  slots:[0-5460] (5461 slots) master
  1 additional replica(s)
S: f1d8c897882d29e6538b1158525493b3b782289a 172.17.0.6:6379
  slots: (0 slots) slave
  replicates e8da1fef656984de3ec2a677edc8d9c48d01cd95
S: bd3064ad5297dfc258e9236943455c589be8b2a3 172.17.0.5:6379
  slots: (0 slots) slave
  replicates 0a46ab2f6d176738b55fe699c2df1c34f8200d06
M: 0a46ab2f6d176738b55fe699c2df1c34f8200d06 172.17.0.4:6379
  slots:[10923-16383] (5461 slots) master
  1 additional replica(s)
S: 619e1cb52f39e07b321719b77fc3631fa6293cef 172.17.0.7:6379
  slots: (0 slots) slave
  replicates 68b925ab0fbbc1a632c1754587fb6dad3fa14c91
M: 68b925ab0fbbc1a632c1754587fb6dad3fa14c91 172.17.0.3:6379
  slots:[5461-10922] (5462 slots) master
  1 additional replica(s)
[OK] All nodes agree about slots configuration.
>>> Check for open slots...
>>> Check slots coverage...
[OK] All 16384 slots covered.

redis-cli -c <port>

127.0.0.1:6379> cluster info
cluster_state:ok
cluster_slots_assigned:16384
cluster_slots_ok:16384
cluster_slots_pfail:0
cluster_slots_fail:0
cluster_known_nodes:6
cluster_size:3
cluster_current_epoch:6
cluster_my_epoch:1
cluster_stats_messages_ping_sent:104
cluster_stats_messages_pong_sent:120
cluster_stats_messages_sent:224
cluster_stats_messages_ping_received:115
cluster_stats_messages_pong_received:104
cluster_stats_messages_meet_received:5
cluster_stats_messages_received:224

127.0.0.1:6379> cluster help
 1) CLUSTER <subcommand> arg arg ... arg. Subcommands are:
 2) ADDSLOTS <slot> [slot ...] -- Assign slots to current node.
 3) BUMPEPOCH -- Advance the cluster config epoch.
 4) COUNT-failure-reports <node-id> -- Return number of failure reports for <node-id>.
 5) COUNTKEYSINSLOT <slot> - Return the number of keys in <slot>.
 6) DELSLOTS <slot> [slot ...] -- Delete slots information from current node.
 7) FAILOVER [force|takeover] -- Promote current replica node to being a master.
 8) FORGET <node-id> -- Remove a node from the cluster.
 9) GETKEYSINSLOT <slot> <count> -- Return key names stored by current node in a slot.
10) FLUSHSLOTS -- Delete current node own slots information.
11) INFO - Return information about the cluster.
12) KEYSLOT <key> -- Return the hash slot for <key>.
13) MEET <ip> <port> [bus-port] -- Connect nodes into a working cluster.
14) MYID -- Return the node id.
15) NODES -- Return cluster configuration seen by node. Output format:
16) <id> <ip:port> <flags> <master> <pings> <pongs> <epoch> <link> <slot> ... <slot>
17) REPLICATE <node-id> -- Configure current node as replica to <node-id>.
18) RESET [hard|soft] -- Reset current node (default: soft).
19) SET-config-epoch <epoch> - Set config epoch of current node.
20) SETSLOT <slot> (importing|migrating|stable|node <node-id>) -- Set slot state.
21) REPLICAS <node-id> -- Return <node-id> replicas.
22) SAVECONFIG - Force saving cluster configuration on disk.
23) SLOTS -- Return information about slots range mappings. Each range is made of:
24) start, end, master and replicas IP addresses, ports and ids

Cluster Manager Commands:
 create host1:port1 ... hostN:portN
         --cluster-replicas <arg>
 check host:port
         --cluster-search-multiple-owners
 info host:port
 fix host:port
         --cluster-search-multiple-owners
 reshard host:port
         --cluster-from <arg>
         --cluster-to <arg>
         --cluster-slots <arg>
         --cluster-yes
         --cluster-timeout <arg>
         --cluster-pipeline <arg>
         --cluster-replace
 rebalance host:port
         --cluster-weight <node1=w1...nodeN=wN>
         --cluster-use-empty-masters
         --cluster-timeout <arg>
         --cluster-simulate
         --cluster-pipeline <arg>
         --cluster-threshold <arg>
         --cluster-replace
 add-node new_host:new_port existing_host:existing_port
         --cluster-slave
         --cluster-master-id <arg>
 del-node host:port node_id
 call host:port command arg arg .. arg
 set-timeout host:port milliseconds
 import host:port
         --cluster-from <arg>
         --cluster-copy
         --cluster-replace
