JS realizes the automatic playback effect of pictures

This article shares the specific code of JS to achieve the automatic playback effect of pictures for your reference. The specific content is as follows

JS realizes automatic playback of pictures

1. Look at the renderings first

2. Complete code

<!DOCTYPE html>
<html>
<head>
 <style>
  /* Define styles */
  body{
   margin: 5% 30%;
  }
  .bannerimage{width:700px;height:400px;float:left;background-size:100% 100%;color:#fff;box-shadow: 0 0 12px 2px #142732;}
  .box{width:700px;height:400px;margin:0px auto;overflow: hidden;}
        /* The width of the box is the number of imgs multiplied by the width of the bannerimage*/
  .img-g{width:4900px;height:400px;position:relative;}
  .img-g img{float:left;width:700px;height:400px;}
  .button-g{position:relative;top:-35px;text-align:center;}
  .button-g span{display:inline-block;position:relative;z-index:10;width:10px;height:10px;margin:0 5px;border-radius:100%;cursor: pointer;}
 </style>

 <script type="text/javascript" src="js/jquery.js"></script>

 <script type="text/javascript">
 $(function () {
     // Implement automatic playback var p=document.getElementsByClassName('img-g')[0];
  var button = document.querySelectorAll('.button-g span')
  // Set the playback time to 3 seconds window.timer=setInterval(move,3000);
  // Carousel settings function move(){
      // bannerimage width multiplied by the number of images if(parseInt(p.style.left)>-4200){
       // Keep the width the same as bannerimage: 700
    p.style.left=parseInt(p.style.left)-700+'px'
    p.style.transition='left 1s';
    tog(-Math.round(parseInt(p.style.left)/700))
    if (parseInt (p.style.left) <= -4200) {
     setTimeout(function(){
      tog(0)
      p.style.left='0px'
      p.style.transition='left 0s';
     },1000)
    }
   }else{
    p.style.left='0px'
    p.style.transition='left 0s';
   }
  }

  //Set the small dot for(var i=0;i<button.length;i++){
   // button[i].style.backgroundColor='#eee';
   button[i].onclick=function(){
    p.style.left=-700*this.getAttribute('data-index')+'px'
    tog(this.getAttribute('data-index'))
    clearInterval(window.timer)
    window.timer=setInterval(move,3000);
   }
  }
  //Set the small dot function tog(index){
   if(index>5){
    tog(0);
    return;
   }
   for(var i=0;i<button.length;i++){
    button[i].style.backgroundColor='rgba(255, 255, 255, 0.5)';
   }
   button[index].style.backgroundColor='rgb(255, 255, 255)';
  }

  // Mouse over event p.onmouseover=function(){
   clearInterval(window.timer)
  }
        // Mouse removal event p.onmouseout=function(){
   window.timer=setInterval(move,3000);
  }
 });
 </script>
</head>
<body>
 <div class="bannerimage">
  <div class='box'>
   <div class='img-g' style='left:0px;transition:left 1s;'>
    <img src="images/img_1.jpg" alt="1">
    <img src="/images/img_2.jpg" alt="2">
    <img src="/images/img_3.jpg" alt="3">
    <img src="/images/img_4.jpg" alt="4">
    <img src="/images/img_5.jpg" alt="5">
    <img src="/images/img_6.jpg" alt="6">
    <img src="/images/img_1.jpg" alt="1">
   </div>
   <div class='button-g'>
    <span data-index='0' style="background-color: #eeeeee"></span>
    <span data-index='1' style="background-color: rgba(255, 255, 255, 0.5)"></span>
    <span data-index='2' style="background-color: rgba(255, 255, 255, 0.5)"></span>
    <span data-index='3' style="background-color: rgba(255, 255, 255, 0.5)"></span>
    <span data-index='4' style="background-color: rgba(255, 255, 255, 0.5)"></span>
    <span data-index='5' style="background-color: rgba(255, 255, 255, 0.5)"></span>
   </div>
  </div>
 </div>
</body>
</html>

3. Key code explanation

3.1. CSS setting notes: The width of img-g is: the number of imgs multiplied by the width of bannerimage, as follows:

.img-g{width:4900px;height:400px;position:relative;}

3.2. Carousel constants and event settings

Constant 1 is set to the width of bannerimage multiplied by the number of images, as follows:

if (parseInt(p.style.left)>-4200){}

Constant 2 is set to keep the width of bannerimage consistent (700), as follows:

p.style.left=parseInt(p.style.left)-700+'px'

Small dot display settings:

//Set the small dot for(var i=0;i<button.length;i++){
 button[i].style.backgroundColor='#eee';
 button[i].onclick=function(){
     p.style.left=-700*this.getAttribute('data-index')+'px'
     tog(this.getAttribute('data-index'))
     clearInterval(window.timer)
     window.timer=setInterval(move,3000);
 }
}
// Set the small dot click event function tog(index){
    //Number of dotsif(index>5){
  tog(0);
  return;
 }
 for(var i=0;i<button.length;i++){
        // Default dot display color button[i].style.backgroundColor='rgba(255, 255, 255, 0.5)';
 }
    // The display color of the current dot button[index].style.backgroundColor='rgb(255, 255, 255)';
}

Mouse event: Stop playing when the mouse is moved over, and play after 3 seconds when the mouse is removed.

// Mouse over event p.onmouseover=function(){
 clearInterval(window.timer)
}
// Mouse removal event p.onmouseout=function(){
 window.timer=setInterval(move,3000);
}

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.
