A brief introduction to mysql mycat middleware

# tar zxvf Mycat-server-1.6-RELEASE-20161028204710-linux.tar.gz -C /usr/local/

# vim /usr/local/mycat/conf/server.xml //Add the following content<user name="user"> //mycat user name<property name="password">user</property> //mycat password<property name="schemas">mytest</property> //mycat virtual database name<property name="readOnly">true</property> //Read-only</user>
<user name="tankzhang">
<property name="password">admin</property>
<property name="schemas">mytest</property>
</user>

# cat schema.xml
<?xml version="1.0"?>
<!DOCTYPE mycat:schema SYSTEM "schema.dtd">
<mycat:schema xmlns:mycat="http://io.mycat/">
<schema name="mytest" checkSQLschema="false" sqlMaxLimit="100" dataNode="my1" />//Define the virtual database name mytest
<dataNode name="my1" dataHost="test1" database="test" /> //The real database name is test
<dataHost name="test1" maxCon="1000" minCon="10" balance="1" writeType="0" dbType="mysql" dbDriver="native" >
<heartbeat>select user()</heartbeat>
<writeHost host="hostM1" url="192.168.5.213:3306" user="tank" password="123456" > //Real database connection method <readHost host="hostS1" url="192.168.5.214:3306" user="tank" password="123456" /> //Same as above</writeHost>
</dataHost>
</mycat:schema>

grant all privileges on test.* to tank@"192.168.%" identified by '123456';
flush privileges

./mycat start Start./mycat stop Stop./mycat console Run in the foreground./mycat restart Restart the service./mycat pause Pause./mycat status Check the startup status

# ./mycat start
Starting Mycat-server...
# netstat -tpnl |grep 8066
tcp 0 0 :::8066 :::* LISTEN 31728/java
# ./mycat status
Mycat-server is running (31726).

# mysql -u tankzhang -p -P 8066 -h 127.0.0.1 //Be sure to include 127.0.0.1
Enter password:
Welcome to the MySQL monitor. Commands end with ; or \g.
Your MySQL connection id is 1
Server version: 5.6.29-mycat-1.6-RELEASE-20161028204710 MyCat Server (OpenCloundDB)

Copyright (c) 2000, 2016, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> show databases;
+----------+
| DATABASE |
+----------+
| mytest | //Virtual database+----------+
1 row in set (0.00 sec)

mysql> use mytest;
Reading table information for completion of table and column names
You can turn off this feature to get a quicker startup with -A

mysql> CREATE TABLE IF NOT EXISTS `user` (
-> `id` int(11) unsigned NOT NULL DEFAULT '0' COMMENT 'ID',
-> `name` varchar(20) NOT NULL DEFAULT '' COMMENT 'Name',
-> `create_time` int(10) NOT NULL DEFAULT '0' COMMENT 'Creation time',
-> PRIMARY KEY (`id`)
-> ) ENGINE=MyISAM DEFAULT CHARSET=utf8 AUTO_INCREMENT=1 ;
Query OK, 0 rows affected (0.08 sec)
Database changed
mysql> show tables;
+----------------+
| Tables_in_test |
+----------------+
| user |
+----------------+
1 row in set (0.01 sec)
mysql> INSERT INTO `user` (`id` ,`name`) VALUES ('1', 'tank');
Query OK, 1 row affected (0.00 sec)

mysql> select * from user; //Modify the name in the user table of the slave database, and you will find that the read is read from the slave database +----+-----------+-------------+
| id | name | create_time |
+----+-----------+-------------+
| 1 | tankzhang | 0 |
+----+-----------+-------------+
1 row in set (0.01 sec)
