Summary of several commonly used CentOS7 images based on Docker

sudo docker pull registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003_v1
sudo docker pull registry-internal.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003_v1

sudo docker pull registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003-dev_v1
sudo docker pull registry-internal.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003-dev_v1

sudo docker pull registry.cn-shanghai.aliyuncs.com/yore/bigdata:dev-mysql_v1
sudo docker pull registry-internal.cn-shanghai.aliyuncs.com/yore/bigdata:dev-mysql_v1

# 1 Check if Docker is already installed on your system
systemctl status docker
rpm -qa | grep -E "docker"
## 1.1 If you want to reinstall, you can uninstall the old version of Docker first
yum remove docker-ce
rm -rf /var/lib/docker
## 1.2 Update system packages yum -y update

# 2 Visit the following website and download the Docker RPM package# https://download.docker.com/linux/centos/7/x86_64/stable/Packages/
# For example, wget https://download.docker.com/linux/centos/7/x86_64/stable/Packages/docker-ce-18.06.3.ce-3.el7.x86_64.rpm

# 3 Install yum install docker-ce-18.06.3.ce-3.el7.x86_64.rpm

# 4 Start systemctl start docker
## View information docker info

vim /etc/docker/daemon.json

# Add your own mirror address, save and exit {
  "registry-mirrors": ["https://xxxxxxxx.mirror.aliyuncs.com"]
}

systemctl daemon-reload
systemctl restart docker
# Check the startup status systemctl status docker

FROM centos:7.8.2003

ENV LANG=zh_CN.UTF-8 \
    LANGUAGE=zh_CN:zh \
    LC_ALL=zh_CN.UTF-8

# Install tools
RUN yum update -y && \
    yum reinstall -y glibc-common && \
    yum install -y telnet net-tools && \
    yum clean all && \
    rm -rf /tmp/* rm -rf /var/cache/yum/* && \
    localedef -c -f UTF-8 -i zh_CN zh_CN.UTF-8 && \
    ln -sf /usr/share/zoneinfo/Asia/Shanghai /etc/localtime

# Define default command.
CMD ["bash"]

# View the image. You will see two images, one is the original image and the other is the custom configured image docker images

# 1 Run. The following will make further modifications to this container. # -d runs the container in the background. # -p specifies the port mapping, the format is: host port: container port. # --name="yore_centos7" specifies a name for the container. # -h "hostname" specifies the hostname of the container.
# -m sets the maximum memory usage of the container;
# --volume, -v bind a volume # --privileged=false specifies whether the container is a privileged container. Privileged containers have all capabilities
# --cap-add=[], add permissions, for a list of permissions, see: http://linux.die.net/man/7/capabilities
docker run --privileged=true --cap-add SYS_ADMIN -e container=docker -it \
-p 30022:22 -p 30080:80 -h "bigdata" \
--name="centos7_base" -d yore/centos7_v1:latest /usr/sbin/init

# 2 Start and stop the container## 2.1 Close the containerdocker stop $CONTAINER_ID
## 2.2 Start a container docker start $CONTAINER_ID
## 2.3 Remove the container docker rm -f $CONTAINER_ID

# 3 Delete the image## image rm is equivalent to rmi
docker image rm $IMAGE_ID
## If there are multiple identical IMAGE IDs, delete them using docker rmi $REPOSITORY:$TAG

# 4 Enter the container docker exec -it $CONTAINER_ID /bin/bash
## View the Centos7 version in the current container cat /etc/redhat-release

# 1 For better file editing, you can install vim
yum install -y vim

# 2 To view port information more conveniently, you can install lsof
yum install -y lsof

# 3 Install wget
yum install -y wget

# 4 Install tree
yum install -y tree

# 5 python tool yum install -y python-devel

# 6 Install the C compilation environment yum install -y gcc gcc-c++
yum install -y zlib
yum install -y zlib-devel
yum install -y tcl build-essential tk gettext

 vim ~/.bashrc

 # Add source /etc/profile at the end

# 1 yum install spenssl service yum -y install passwd openssl openssh-server openssh-clients
mkdir /var/run/sshd/

# 2 Modify the configuration vim /etc/ssh/sshd_config +39
## About between lines 38 and 45, modify or add the following three configurations: PermitRootLogin yes
RSAAuthentication yes
PubkeyAuthentication yes

# 3 Start and stop the sshd service## 3.1 Start systemctl start sshd.service
## 3.2 View the sshd service status systemctl status sshd
## 3.3 Stop systemctl start sshd.service

# 4 Set it to start automatically at boot systemctl enable sshd.service

# [Can be skipped] 5 Generate ssh private key and public key# ssh-keygen -t rsa

# 6 View SSH service lsof -i:22

# 7 Set root password (2020)
passwd

# 8 Access the container via ssh root@bigdata

# The hash_of_the_container can be obtained by viewing the CONTAINER ID vim /var/lib/docker/containers/${hash_of_the_container}/hostconfig.json

"NetworkMode": "default",
  "PortBindings": {
    "22/tcp": [
      {
        "HostIp": "bigdata01",
        "HostPort": "30022"
      }
    ],
    "80/tcp": [
      {
        "HostIp": "bigdata01",
        "HostPort": "30080"
      }
    ],
    "3306/tcp": [
      {
        "HostIp": "bigdata01",
        "HostPort": "33306"
      }
    ]
  }

# 1 Stop the currently running container docker stop $CONTAINER_ID

# 2 commit the docker container docker commit $CONTAINER_ID new_image:tag

# 3 View the current image library docker images

# 4 Use the generated new image to start a new container docker run --privileged=true --cap-add SYS_ADMIN -e container=docker -it \
-p 30022:22 -p 30080:80 -p 33306:3306 \
--name="yore_centos7_v2" -h "bigdata01" -d yore/centos7_v2:latest /usr/sbin/init

# 1 Stop the currently running container docker stop $CONTAINER_ID

# 2 commit the docker container docker commit $CONTAINER_ID centos7_base:v1

# 3 View the current image library docker images

# View the existing local docker images

# 2 Access credentials (fixed password of the access credentials set previously)
sudo docker login --username=7910*****@qq.com registry.cn-shanghai.aliyuncs.com

# 3 tag
docker tag $IMAGE_ID registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003_v1

# 4 Push to Alibaba Cloud image docker push registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003_v1

# 5 If the image of the previous tag needs to be deleted, execute the following command docker rmi $REPOSITORY:$TAG

# View the images currently in Docker sudo docker images

# Pull the uploaded image## The image connection can be viewed through the basic information. There are public network addresses, private networks, and classic networks to choose from. sudo docker pull registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003_v1

# 1 Run. The following will further modify the settings of this container# Based on the base image, start the containerdocker run --privileged=true --cap-add SYS_ADMIN -e container=docker -it \
-p 30022:22 -p 30080:80 -h "bigdata01" \
--name="centos7_dev1" -d centos7_base:v1 /usr/sbin/init

# 2 Enter the container docker ps
docker exec -it $CONTAINER_ID /bin/bash

# 3 hosts changed to.
172.17.0.3 yore.node1 bigdata01

# 1 Download. If the link below is invalid, you need to log in to the Oracle account.
# Visit https://www.oracle.com/technetwork/java/javase/downloads/jdk8-downloads-2133151.html to download jdk8
wget https://download.oracle.com/otn/java/jdk/8u231-b11/5b13a193868b4bf28bcb45c792fce896/jdk-8u231-linux-x64.tar.gz?AuthParam=1573137213_adc79b33f2d9ed27cb8b09b6adf71820

# 2 Unzip tar -zxf jdk-8u231-linux-x64.tar.gz -C /usr/local/
chown root:root -R /usr/local/jdk1.8.0_231

# 3 Configure environment variables vim /etc/profile
# Add the following configuration### set java environment
JAVA_HOME=/usr/local/jdk1.8.0_231
JRE_HOME=$JAVA_HOME/jre
CLASS_PATH=.:$JAVA_HOME/lib/dt.jar:$JAVA_HOME/lib/tools.jar:$JRE_HOME/lib
PATH=$PATH:$JAVA_HOME/bin:$JRE_HOME/bin
export JAVA_HOME JRE_HOME CLASS_PATH PATH

# 4 And load it to take effect:
source /etc/profile

# 5 To make vim ~/.bashrc take effect every time you enter the container
# Add the last line and save source /etc/profile

# 6 Check the Java version java -version

# 1 Download source code,
wget -O git-2.27.0.tar.gz https://mirrors.edge.kernel.org/pub/software/scm/git/git-2.27.0.tar.gz

# 2 Unzip tar -zxf git-2.27.0.tar.gz -C /tmp/
cd /tmp/git-2.27.0

# 3 Check related dependencies and set the installation path./configure --prefix=/usr/local/git

# 4 Install make && make install

# 5 Create a soft link ln -s /usr/local/git/bin/git /usr/bin/git

# 6 Check the version git -v

# 1 Download wget https://mirrors.tuna.tsinghua.edu.cn/apache/maven/maven-3/3.6.3/binaries/apache-maven-3.6.3-bin.tar.gz

# 2 Unzip tar -zxf apache-maven-3.6.3-bin.tar.gz
mv apache-maven-3.6.3 /usr/local/maven3

# 3 Modify the configuration vim /usr/local/maven3/conf/settings.xml

<!--Add around line 55 to specify the path to the local warehouse-->
 <localRepository>/opt/.m2/repo</localRepository>

 <!--About line 158, configure the domestic mirror, here is the Alibaba Maven mirror-->
<!-- Configure Alibaba Cloud's image -->
<mirror>
      <id>nexus-aliyun</id>
      <mirrorOf>*</mirrorOf>
      <name>Nexus aliyun</name>
      <url>http://maven.aliyun.com/nexus/content/groups/public</url>
</mirror>

<mirror>
  <id>central-repos1</id>
  <name>Central Repository 2</name>
  <url>https://repo1.maven.org/maven2/</url>
      <!-- means mirroring only the central repository. If you want to mirror all repositories, you can change it to -->
  <mirrorOf>*</mirrorOf>
</mirror>

# 4 Configure environment variables,
vim /etc/profile
# set Maven environment
export MAVEN_HOME=/usr/local/maven3
export PATH=$PATH:$MAVEN_HOME/bin

# 5 Take effect source /etc/profile

# 6 Check the version mvn -version

# 1 Download the Nginx offline installation package. Take x86 and centos7 versions as examples: wget http://nginx.org/packages/mainline/centos/7/x86_64/RPMS/nginx-1.17.6-1.el7.ngx.x86_64.rpm

# 2 Install rpm -ivh nginx-1.17.6-1.el7.ngx.x86_64.rpm

# 3 Configuration file /etc/nginx
# The server service can be configured to the following path, ending with .conf, and restart or make the configuration take effect /etc/nginx/conf.d/

# 4 Common commands## 4.1 Start, because the internal port 80 has been mapped to the host's port 30080, access systemctl start nginx through the host's IP and port 30080 in the browser
## 4.2 Status systemctl status nginx
## 4.3 Stop systemctl stop nginx
## 4.4 Restart systemctl restart nginx
## 4.5 Configuration re-effective /usr/sbin/nginx -s reload

# The image provided here has stopped the Nginx service. Please start it manually when needed.

# 1 Download wget https://nodejs.org/dist/v12.18.2/node-v12.18.2-linux-x64.tar.xz

# 2 Unzip tar -xf node-v12.18.2-linux-x64.tar.xz
mv node-v12.18.2-linux-x64 /usr/local/nodejs

# 3 Create a connection ln -s /usr/local/nodejs/bin/node /usr/bin/node
ln -s /usr/local/nodejs/bin/npm /usr/bin/npm

# 4 Check the version node -v
npm -v

# 1 Stop the currently running container docker stop $CONTAINER_ID

# 2 commit the docker container docker commit $CONTAINER_ID centos7_dev:v1

# 3 View the current image library docker images

docker tag $IMAGE_ID registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003-dev_v1
docker push registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003-dev_v1

# View the images currently in Docker sudo docker images

# Pull the uploaded image## The image connection can be viewed through the basic information. There are public network addresses, private networks, and classic networks to choose from. sudo docker pull registry.cn-shanghai.aliyuncs.com/yore/bigdata:7.8.2003-dev_v1

# 1 View existing networks (three will be created by default)
# bridge bridge network. Each time the Docker container is restarted, the corresponding IP address will be obtained in sequence, which may cause the IP address to change after the restart # host host network. The Docker container's network will be attached to the host, and the two are interconnected.
# none The container will not be assigned a LAN IP
[yore@VM_0_3_centos app]$ sudo docker network ls
NETWORK ID NAME DRIVER SCOPE
ba8077c371b9 bridge bridge local
1be5b2b64e10 host host local
77ef163ae7c4 none null local

# 2 Create a custom network.
# sudo docker network prune
# Note: It cannot conflict with the existing network segment sudo docker network create --subnet=172.19.0.0/16 mynetwork

# 1 Run. The following will make further modifications to this container. # Based on the centos7_dev image, start the container. # The network mode is specified as the previously customized mynetwork, so that we can directly specify the ip
docker run --privileged=true --cap-add SYS_ADMIN -e container=docker -it \
--network mynetwork --ip 172.19.0.2 -h "bigdata02" --name="dev_mysql_v1" \
-p 30022:22 -p 33306:3306 \
-d centos7_dev:v1 /usr/sbin/init

# 2 Enter the container docker ps
docker exec -it $CONTAINER_ID /bin/bash

# 3 [Optional] Change hosts to. You can also specify 172.19.0.2 yore.node2 bigdata02 when running

# 1 Stop the currently running container# docker stop $CONTAINER_ID

# 2 commit the docker container docker commit $CONTAINER_ID dev_mysql:v1

# 3 View the current image library docker images

docker tag $IMAGE_ID registry.cn-shanghai.aliyuncs.com/yore/bigdata:dev-mysql_v1
docker push registry.cn-shanghai.aliyuncs.com/yore/bigdata:dev-mysql_v1

# View the images currently in Docker sudo docker images

# Pull the uploaded image## The image connection can be viewed through the basic information. There are public network addresses, private networks, and classic networks to choose from. sudo docker pull registry.cn-shanghai.aliyuncs.com/yore/bigdata:dev-mysql_v1
