Implementing search box function with search icon based on html css

Preface

Let me share with you how to make a search box with small icons which is very useful in the front end.

Effect display

insert image description here

Basic idea

1. Use absolute positioning to place the search image above the search box

2. Set the text indentation of the input box to the size of the search image plus the margins on the left and right sides of the image

Prepare

Just a search icon image, similar to the one below

insert image description here

Code

<!DOCTYPE html>
<html lang="en">
<head>
 <meta charset="UTF-8">
 <title>Search box demo</title>
 <style type="text/css">
  *{
   margin: 0;
   padding: 0;
  }
  body{
   width: 100vw;
   height: 100vh;
   background: radial-gradient(at center,
    #3498db,#2980b9);
   display: flex;
   justify-content: center;
   align-items: center;
  }
  div.search{
   height: 40px;
   width: 500px;
  }
  div.search form{
   width: 100%;
   height: 100%;
  }
  div.search form input:nth-child(2){
   width: 400px;
   height: 100%;
   font-size: 16px;
   text-indent: 40px;
   border: none;
   float: left;
  }
  div.search form input:nth-child(3){
   width: 100px;
   height: 100%;
   font-size: 16px;
   letter-spacing: 5px;
   border: none;
  }
  div.search form img{
   position: absolute;
   left: 50vw;
   transform: translateX(-250px);
   margin-top: 10px;
   margin-left: 10px;
   height: 20px;
  }
 </style>
</head>
<body>
 <div class="search">
  <form action="#" method="post">
   <img src="./search_ico.png" alt="">
   <input type="text" name="condition" placeholder="Please enter the search condition">
   <input type="submit" value="Search">
  </form>
 </div>
</body>
</html>

Summarize

The above is the search box function with search icon based on HTML CSS introduced by the editor. I hope it will be helpful to everyone. If you have any questions, please leave me a message and the editor will reply to you in time. I would also like to thank everyone for their support of the 123WORDPRESS.COM website!
If you find this article helpful, please feel free to reprint it and please indicate the source. Thank you!
