How to use ECharts in WeChat Mini Programs using uniapp

How to use ECharts in WeChat Mini Programs using uniapp

Today, we use uniapp to integrate Echarts to display map charts.

Please refer to mpvue-echarts

Reference: https://github.com/F-loat/mpvue-echarts

https://ask.dcloud.net.cn/article/36288

Make improvements

There are many tutorials on the Internet, but they are not very clear. Let's go directly to the steps below.

1. npm install echarts mpvue-echarts

After executing this command, mpvue-echarts and echarts will be generated under node_modules, and then the src under mpvue-echarts will be placed under components, and then the js file of echarts will be customized at https://echarts.apache.org/zh/builder.html, as shown below:

insert image description here

Map implementation:

<template>
	<view class="wrap" >
		<mpvue-echarts id="main" ref="mapChart" :echarts="echarts" @onInit="renderMap" />
	</view>
</template>

<script>
import * as echarts from '@/common/echarts.min'; /*chart.min.js is customized online*/
import * as henanJson from 'echarts/map/json/province/henan.json'; /*chart.min.js is customized online*/
import mpvueEcharts from '@/components/mpvue-echarts/src/echarts.vue';


export default {
	data() {
		return {
			echarts,
		};
	},
	components:
		mpvueEcharts
	},
	onLoad() {

	},
	methods: {
		renderMap(e) {
			var mydata = [
				{ name: 'Zhengzhou City', value: 100 },
				{ name: 'Luoyang City', value: 10 },
				{ name: 'Kaifeng City', value: 20 },
				{ name: 'Xinyang City', value: 30 },
				{ name: 'Zhumadian City', value: 40 },
				{ name: 'Nanyang City', value: 41 },
				{ name: 'Zhoukou City', value: 15 },
				{ name: 'Xuchang City', value: 25 },
				{ name: 'Pingdingshan City', value: 35 },
				{ name: 'Xinxiang City', value: 35 },
				{ name: 'Luohe City', value: 35 },
				{ name: 'Shangqiu City', value: 35 },
				{ name: 'Sanmenxia City', value: 35 },
				{ name: 'Jiyuan City', value: 35 },
				{ name: 'Jiaozuo City', value: 35 },
				{ name: 'Anyang City', value: 35 },
				{ name: 'Hebi City', value: 35 },
				{ name: 'Puyang City', value: 35 },
				{ name: 'Kaifeng City', value: 45 }
			];
			let { canvas, width, height } = e;
			echarts.setCanvasCreator(() => canvas);
			const chart = echarts.init(canvas, null, {
				width: width,
				height: height
			});
			echarts.registerMap('henan', henanJson);
			canvas.setChart(chart);
			var optionMap = {
				tooltip: {
					trigger: 'item',
					formatter: '{b}: {c}mg/m³'
				},
				//Small navigation icon on the left visualMap: {
					show:true,
					min: 0,
					max: 100,
					left: 'right',
					orient:'horizontal',
				},
				//Configuration properties series: [
					{
						type: 'map',
						mapType: 'henan',
						label: {
							normal: {
								show: true
							},
							emphasis:
								textStyle: {
									color: '#fff'
								}
							}
						},
						itemStyle: {
							normal: {
								borderColor: '#389BB7',
								areaColor: '#fff'
							},
							emphasis:
								areaColor: '#389BB7',
								borderWidth: 0
							}
						},
						animation: false,
						data: mydata //data }
				]
			};
			//Initialize echarts instance chart.setOption(optionMap);
			this.$refs.mapChart.setChart(chart);
		}
	}
};
</script>

<style scoped lang="scss">
.wrap {
  width: 100%;
  height: 400px;
}
</style>

Effect:

insert image description here

Regarding the json file of the map, in echarts\map

This is the end of this article about how uniapp uses ECharts in WeChat Mini Programs. For more information about how uniapp uses ECharts, please search for previous articles on 123WORDPRESS.COM or continue to browse the following related articles. I hope you will support 123WORDPRESS.COM in the future!
