Detailed example of MySQL data storage process parameters

There are three types of MySQL stored procedure parameters: in, out, and inout. What are their respective functions and characteristics?

1. MySQL stored procedure parameters (in)

MySQL stored procedure "in" parameter: Similar to the value passing of function parameters in C language, this parameter may be modified inside the MySQL stored procedure, but the modification of the in type parameter is not visible to the caller.

drop procedure if exists pr_param_in;
create procedure pr_param_in
(
  in id int -- in type MySQL stored procedure parameter)
begin
  if (id is not null) then
   set id = id + 1;
  end if;
  select id as id_inner;
end;

set @id = 10;
call pr_param_in(@id);
select @id as id_out;

mysql> call pr_param_in(@id);
+----------+
| id_inner |
+----------+
| 11 |
+----------+

mysql> select @id as id_out;
+--------+
| id_out |
+--------+
| 10 |
+--------+

It can be seen that the value passed into the user variable @id is 10. After executing the stored procedure, the value inside the procedure is: 11 (id_inner), but the value of the external variable is still: 10 (id_out).

2. MySQL stored procedure parameters (out)

MySQL stored procedure "out" parameter: pass values ​​from within the stored procedure to the caller. Inside a stored procedure, the initial value of the parameter is null, regardless of whether the caller sets a value for the stored procedure parameter.

drop procedure if exists pr_param_out;
create procedure pr_param_out
(
  out id int
)
begin
  select id as id_inner_1; -- The initial value of id is null
  if (id is not null) then
   set id = id + 1;
   select id as id_inner_2;
  else
   select 1 into id;
  end if;
  select id as id_inner_3;
end;

set @id = 10;
call pr_param_out(@id);
select @id as id_out;

mysql> set @id = 10;
mysql>
mysql> call pr_param_out(@id);
+------------+
| id_inner_1 |
+------------+
| NULL |
+------------+

+------------+
| id_inner_3 |
+------------+
| 1 |
+------------+

mysql> select @id as id_out;
+--------+
| id_out |
+--------+
| 1 |
+--------+

It can be seen that although we set the user-defined variable @id to 10, after passing @id to the stored procedure, the initial value of id inside the stored procedure is always null (id_inner_1). Finally the id value (id_out = 1) is passed back to the caller.

3. MySQL stored procedure parameters (inout)

MySQL stored procedure inout parameters are similar to out parameters, and both can pass values ​​from within the stored procedure to the caller. The difference is that the caller can also pass values ​​to the stored procedure through inout parameters.

drop procedure if exists pr_param_inout;
create procedure pr_param_inout
(
  inout id int
)
begin
  select id as id_inner_1; -- The id value is the value passed by the caller if (id is not null) then
   set id = id + 1;
   select id as id_inner_2;
  else
   select 1 into id;
  end if;
  select id as id_inner_3;
end;

set @id = 10;
call pr_param_inout(@id);
select @id as id_out;

mysql> set @id = 10;

mysql>
mysql> call pr_param_inout(@id);
+------------+
| id_inner_1 |
+------------+
| 10 |
+------------+

+------------+
| id_inner_2 |
+------------+
| 11 |
+------------+

+------------+
| id_inner_3 |
+------------+
| 11 |
+------------+
mysql>
mysql> select @id as id_out;
+--------+
| id_out |
+--------+
| 11 |
+--------+

From the results, we can see that after we pass @id (10) to the stored procedure, the stored procedure finally returns the calculated value 11 (id_inner_3) to the caller. The behavior of inout parameters in MySQL stored procedures is similar to passing by reference in C language functions.

Through the above examples: if you just want to pass data to the MySQL stored procedure, then use the "in" type parameter; if you just return the value from the MySQL stored procedure, then use the "out" type parameter; if you need to pass the data to the MySQL stored procedure and then pass it back to us after some calculations, then use the "inout" type parameter.
