Docker custom network implementation

1. Customize the network to realize container interconnection

Four types of network modes, use docker network ls to view the docker network mode

–net=bridge This is the default value, connecting to the default bridge.

–net=host tells Docker not to put the container network into an isolated namespace, that is, not to containerize the network inside the container. At this point the container uses the local host's network and has full access to the local host interface. The container process can open low-range ports like other root processes on the host, access local network services such as D-bus, and allow the container to do things that affect the entire host system, such as restarting the host. Therefore use this option with caution. If --privileged=true is further used, the container will be allowed to directly configure the host's network stack.

–net=container:NAME_or_ID tells Docker to put the newly created container process into the network stack of an existing container. The new container process has its own file system, process list, and resource limits, but will share network resources such as IP addresses and ports with the existing container. The two processes can communicate directly through the lo loopback interface.

–net=none tells Docker to put the new container into an isolated network stack, but not to do any network configuration. Afterwards, users can configure it themselves.

Custom Network

# --driver bridge bridge mode# --subnet 192.168.0.0/16 subnet segment# --gateway 192.168.0.1 gateway# mynet network namedocker network create --driver bridge --subnet 192.168.0.0/16 --gateway 192.168.0.1 mynet

View customized network information:

docker network inspect mynet

Creating a container in a custom network

docker run -d -P --name tomcat01-net-01 --net mynet tomcat
docker run -d -P --name tomcat01-net-02 --net mynet tomcat

Check the custom network information again: the two newly created containers are found to be added to the network.

Ping test between containers using their names

tomcat01-net-01 pings tomcat01-net-02:

tomcat01-net-02 pings tomcat01-net-01:

Now containers can ping each other without using --link, and containers can communicate with each other.

2. Network connectivity

Demand analysis diagram

Create two containers, tomcat01 and tomcat02:

docker run -d -P --name tomcat01 tomcat
docker run -d -P --name tomcat02 tomcat

Obviously, it is impossible to ping directly. You need to connect the tomcat01 container to the mynet network first.

docker network connect

The docker network connect command is used to connect a docker container to a network. You can use the container name or container ID.

usage:

docker network connect [OPTIONS] NETWORK CONTAINER

Connect the tomcat01 container to the mynet network:

docker network connect mynet tomcat01

View the network information of mynet: docker inspect mynet

tomcat01 is already connected to the mynet network, as are tomcat01-net-tomcat01 and tomcat01-net-tomcat02.

At this point, tomcat01 has been connected to the two containers in the mynet network. Since the three containers are in the same network, they can of course communicate with each other:

One container, two networks:

View the metadata of tomcat01: docker inspect tomcat01

After tomcat01 is connected to the custom mynet network, there are two networks.
