Implementation of Docker container connection and communication

Port mapping is not the only way to connect Docker to another container.

Docker has a connection system that allows multiple containers to be connected together and share connection information.

A docker connection creates a parent-child relationship where the parent container can see the child container's information.

Container naming

When we create a container, Docker will automatically name it. Alternatively, we can use the --name flag to name the container, for example:

runoob@runoob:~$ docker run -d -P --name runoob training/webapp python app.py
43780a6eabaaf14e590b6e849235c75f3012995403f97749775e38436db9a441

We can use the docker ps command to view the container name.

runoob@runoob:~$ docker ps -l
CONTAINER ID IMAGE COMMAND ... PORTS NAMES
43780a6eabaa training/webapp "python app.py" ... 0.0.0.0:32769->5000/tcp runoob

Create a new network

Let's create a new Docker network.

$ docker network create -d bridge test-net

Parameter Description:

-d: The parameter specifies the Docker network type, which can be bridge or overlay.

The overlay network type is used for Swarm mode, and you can ignore it in this section.

Connecting Containers

Run a container and connect to the newly created test-net network:

$ docker run -itd --name test1 --network test-net ubuntu /bin/bash

Open a new terminal, run another container and join the test-net network:

$ docker run -itd --name test2 --network test-net ubuntu /bin/bash

The following ping command is used to prove that the test1 container and the test2 container are interconnected.

If there is no ping command in the test1 and test2 containers, run the following command in the container to install ping (learn and use right away: you can install it in a container, submit the container to the image, and then re-run the above two containers with the new image).

apt-get update
apt install iputils-ping

Enter the following command in the test1 container:

Click on the image to see a larger version:
