Docker container deployment attempt - multi-container communication (node+mongoDB+nginx)

The reason is this

I wanted to deploy a mocker platform, so I chose the ready-made project api-mocker on the recommendation of a friend.

The project is divided into server node, client vue, and database mongoDB

When I tried to deploy directly, I found that I needed to install a lot of environments, such as node, mongo, and nginx. It was very troublesome. I had used docker before, so I was wondering if I could use docker to deploy directly without the environment? So there was this attempt

Multi-container communication

The project is divided into 3 parts, so 3 containers (node, mongo, nginx) need to be established

How do containers communicate with each other?

 # Establish a connection through the link command$ docker run --name <Name> -d -p <path1>:<path2> --link <containerName>:<alias> <containerName:tag/imageID>

- --link container connection instruction
- < containerName > : < alias >
- <connected container name> : <container access alias>
- Note: The alias is accessed in the container that actively establishes the connection and is used by the connected container
- The following instructions detect the connection status in the container
$ curl <alias>

Next, we start trying to deploy

Implementation process

1. Build a mongo container

2. Build the node container and establish a connection with the mongo container

3. Build the nginx container and establish a connection with the node container

Build the mongo container

Let's pull the mongo image first

$ docker pull mongo:latest

Now let's run this image.

 $ docker images
 REPOSITORY TAG IMAGE ID CREATED SIZE
 mongo latest 05b3651ee24e 2 weeks ago 382MB

The --auth directive turns on the Mongo connection identity verification. The verification is turned on because the identity verification is not set when the node is connected across containers. The server cannot connect to the Mongo database.

```
nodejs.MongoError: [egg-mongoose]Authentication failed.
```

View Container

$ docker ps -a
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
0d440be90935 mongo "docker-entrypoint.s..." 14 hours ago Up 14 hours 0.0.0.0:27017->27017/tcp mock-mongo

Since we have enabled authentication for mongo, we need to enter the mongo container and configure the account used when the node connects

$ docker exec -it mock-mongo /bin/bash
$ mongo admin
# Create a manager user
$ db.createUser({user:"admin", pwd:"admin", roles:[{role:"admin", db:"admin"}]})
# Account authorization $ db.auth('admin','admin')

Now that our mongo database is running, we will create a node container.

Build the node container and establish a connection with the mongo container

Before we start building the node container, we must first agree on the mongo container alias, port number, and login account password

• mongo container alias:
• db mongo port number: 27017
• Account password:admin:admin

Let's first modify the configuration of the node server

File configuration dockerfile/api-mocker/server/config/config.default.js Modify the mongo connection configuration, db is the alias of the pre-set mock-mongo container

 mongoose: {
 url: 'mongodb://admin:admin@db:27017/api-mock?authSource=admin'
 },

Now we write a Dockerfile to build the image

 # Specify the base image FROM node:latest

 # Maintainer MAINTAINER [email protected]

 # Working directory WORKDIR /www

 #Copy the local file to the container without decompressing it COPY api-mocker node-server/api-mocker

 EXPOSE 7001

 WORKDIR /www/node-server/api-mocker/server

 RUN npm install

 WORKDIR /www/node-server/api-mocker

 # Called after building the container, and called when the container starts CMD ["make", "prod_server"]

We use the written Dockerfile file to build the image

 $ docker build -t="mock-server:1.0.0" .

Let's check out the image

 $ docker images
 REPOSITORY TAG IMAGE ID CREATED SIZE
 mock-server 1.0.0 957ad2aa1f97 8 minutes ago 674MB
 mongo latest 05b3651ee24e 2 weeks ago 382MB

Now comes the critical step. We will run the mocker-server image and establish a connection between the server and the database.

Let's take a look at the container that is currently running

 $ docker ps
 CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
 ee780b903c64 mock-server:1.0.0 "/bin/bash" About a minute ago Up 11 seconds 0.0.0.0:7001->7001/tcp mock-server
 0d440be90935 mongo "docker-entrypoint.s..." 16 hours ago Up 16 hours 0.0.0.0:27017->27017/tcp mock-mongo

Check the connection status between the node container and the mongo container

 $ docker exec -it mock-server /bin/bash
 $ curl db

Now that our server and database have established a connection, we will start deploying our client.

Build the nginx container and establish a connection with the node container

Before setting up nginx, we must first agree on the node container alias, the port number forwarded by nginx, and the domain name and port number for client access to nginx

• Node server alias: node
• Port number mapped by the node container: 7001
• nginx domain name: 127.0.0.1
• nginx port number: 90

Let's first pull the nginx image and create a container

$ docker pull nginx:latest
$ docker run -p 90:80 --link mock-node:node nginx:latest --name mock-nginx
# Check the container connection status $ docker exec -it mock-nginx /bin/bash
$env
# If you see the following data, it means the connection is successful NODE_PORT_7001_TCP=tcp://172.17.0.3:7001
NODE_PORT_7001_TCP_PORT=7001
NODE_ENV_YARN_VERSION=1.9.4

Now let's take a look at the running containers

$ docker ps
 CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
 09644025d148 nginx "nginx -g 'daemon of..." 5 hours ago Up 5 hours 0.0.0.0:90->80/tcp mock-nginx
 ee780b903c64 mock-server:1.0.0 "/bin/bash" About a minute ago Up 11 seconds 0.0.0.0:7001->7001/tcp mock-server
 0d440be90935 mongo "docker-entrypoint.s..." 24 hours ago Up 24 hours 0.0.0.0:27017->27017/tcp mock-mongo

Due to the independent deployment of the front end, we need to modify the configuration of nginx. There are several ways to modify the configuration of nginx:

• When creating a container, use the -v command to mount the configuration file to the local host, and restart nginx in the container after modifying it locally.
• Copy the configuration file to the local host, modify it and replace the corresponding file in the container, and then restart nginx in the container
• ...

Our current operating environment is a 17-version 15-inch MacBook Pro, which requires special configuration for mounting, so I used the second method.

Configuration file modification

• Configuration file path in the container: /etc/nginx/conf.d/default.conf
• Copy the configuration file to your local computer

 $ docker cp mock-nginx:/etc/nginx/conf.d/default.conf ~/nginx/default.conf

Add the following configuration to the nginx configuration file

server {
 location /mock-api/ {
  # node is the alias of the command server container proxy_pass http://node:7001/;
 }

 location /mock {
  autoindex on;
  alias /root/dist;
 }
}

Overwrite the configuration in the container and restart nginx

$ docker cp ~/nginx/default.conf mock-nginx:/etc/nginx/conf.d/default.conf
# Enter the container$ docker exec -it mock-nginx /bin/bash
# Restart nginx. If you see the following prompt, it means the restart is successful. $ nginx -s reload
2018/11/03 17:23:14 [notice] 68#68: signal process started

Now comes our final exciting step

Modify the network domain name requested by our front-end project and package and upload it

//api-mocker/client/config
// module.exports > build > serverRoot

module.exports = {
 build: {
  serverRoot: '127.0.0.1:90/mock-api'
 }
}

Upload the packaged dist file to the /root/dist directory of the nginx configuration

 $ docker cp ~/Sites/api-mocker/client/dist mock-nginx:/root

> Of course, nginx container construction can also be implemented by writing a dockfile file. We will not explain it in detail here. Mount the configuration file and log to the local host. If you are interested, you can try it yourself. Copy the code

test

We have completed all the exciting configurations, now let's test it

Visit the front-end project: http://127.0.0.1:90/mock We will see the following interface indicating that our front-end project has been deployed successfully

We try to register an account and see a successful prompt, which means that our entire project has been deployed successfully.

At this point, our deployment is complete, and we can happily mock the interface and write the project. Sprinkle flowers~~~

Summarize

It was difficult to write an article for the first time and to deploy it like this for the first time. I sorted out my thoughts and hope it can be of some help to you.

Finally, I attach my own commonly used docker commands and the configuration files used in this project.
