Use CSS to draw a file upload pattern

As shown below, if it were you, how would you achieve it:

Usually we use font icons to display the plus sign in the middle, and wrap it with a div on the outside; or use pseudo-elements to simulate the horizontal and vertical lines in the middle, which is more troublesome.

In fact, we can directly use div+css to achieve it.

Outline

The outline property is a shorthand property for setting one or more individual outline properties, for example.

A contour has the following properties:

{
    outline-style: solid;
    outline-width: 10px;
    outline-color: red;
}

They have a shorthand form:

{
    outline: 10px solid red;
}

Features of the outline

Outlines do not take up space; they are drawn on top of the content.

You can achieve the following effect:

I found that when setting outline-offset to a negative value, the outline will appear inside the div. If you continue to expand its negative value, the outline will eventually shrink into a "➕" plus sign, which can be used as the plus sign in the middle of the file upload style.

This is interesting, so here comes the code:

div {
    margin: 100px;
    width: 100px;
    height: 100px;
    outline: 15px solid #545454;
    outline-offset: -66px;
    border: 2px solid #545454;
}

outline-offset: -66px; is the key, it represents the distance of the outline from the edge of the div. If it is a negative value, it will shrink inwards, finally forming a plus sign. The specific uploaded style size and outline width need to be adjusted slowly by yourself to achieve harmony.

It should be noted that:

The container must be a square

The width of the outline border itself cannot be too small

Original github repository address: https://github.com/Daotin/front-end-notes/issues
