How to use Docker+DockerCompose to encapsulate web applications

Technology Stack
Backend build API
Front-end web building
Gateway construction gateway

Nginx Configuration
Dockerfile
Lua implements gateway authentication based on enterprise WeChat

Container orchestration using DockerCompose

This article will introduce how to run the backend, frontend, and gateway using Docker containers, and finally use DockerCompose for container orchestration.

Technology Stack

front end

React
Ant Design

rear end

Go
Iris

Gateway

Nginx
OpenResty
Lua
WeChat Business

Backend build API

Although we wrote EXPOSE 4182 here, this is only used during testing. In fact, we will not expose the backend interface port in the production environment.
Instead, containers access each other through the network between them, and eventually forward using Nginx.

FROM golang:1.15.5

LABEL maintainer="K8sCat <[email protected]>"

EXPOSE 4182

ENV GOPROXY=https://goproxy.cn,direct \
    GO111MODULE=on

WORKDIR /go/src/github.com/k8scat/containerized-app/api

COPY . .

RUN go mod download && \
go build -o api main.go && \
chmod +x api

ENTRYPOINT [ "./api" ]

Front-end web building

It is worth mentioning here that the front-end will definitely call the back-end interface, and the address of this interface changes according to the deployment.
So here we use the ARG instruction to set the backend interface address, so that we only need to pass in --build-arg REACT_APP_BASE_URL=https://example.com/api when building the image to adjust the backend interface address instead of changing the code.

Another point is that some friends will definitely find that Entrypoint and CMD are used here at the same time. This is to adjust the front-end port during operation, but in fact we don’t need to adjust it here, because Nginx is ultimately used for forwarding here.

FROM node:lts

LABEL maintainer="K8sCat <[email protected]>"

WORKDIR /web

COPY . .

ARG REACT_APP_BASE_URL

RUN npm config set registry https://registry.npm.taobao.org && \
npm install && \
npm run build && \
npm install -g serve

ENTRYPOINT [ "serve", "-s", "build" ]
CMD [ "-l", "3214" ]

Gateway construction gateway

Nginx Configuration

Here we set the upstream of the backend and frontend respectively, and then set the location rules for forwarding.
Here are a few points to mention:

Get the environment variables of the container through set_by_lua, and finally set these environment variables by setting environment at runtime, which is more flexible
server_name uses $hostname, and the hostname of the container needs to be set at runtime
ssl_certificate and ssl_certificate_key cannot be set using variables
Load the gateway.lua script to implement the gateway authentication of WeChat for Enterprise

upstream web {
    server ca-web:3214;
}

upstream api {
 server ca-api:4182;
}

server {
 set_by_lua $corp_id 'return os.getenv("CORP_ID")';
 set_by_lua $agent_id 'return os.getenv("AGENT_ID")';
 set_by_lua $secret 'return os.getenv("SECRET")';
 set_by_lua $callback_host 'return os.getenv("CALLBACK_HOST")';
 set_by_lua $callback_schema 'return os.getenv("CALLBACK_SCHEMA")';
 set_by_lua $callback_uri 'return os.getenv("CALLBACK_URI")';
 set_by_lua $logout_uri 'return os.getenv("LOGOUT_URI")';
 set_by_lua $token_expires 'return os.getenv("TOKEN_EXPIRES")';
 set_by_lua $use_secure_cookie 'return os.getenv("USE_SECURE_COOKIE")';

 listen 443 ssl http2;
 server_name $hostname;
 resolver 8.8.8.8;
 ssl_certificate /certs/cert.crt;
 ssl_certificate_key /certs/cert.key;
 ssl_session_cache shared:SSL:1m;
 ssl_session_timeout 5m;
 ssl_protocols TLSv1 TLSv1.1 TLSv1.2;
 ssl_ciphers AESGCM:HIGH:!aNULL:!MD5;
 ssl_prefer_server_ciphers on;
 lua_ssl_verify_depth 2;
    lua_ssl_trusted_certificate /etc/pki/tls/certs/ca-bundle.crt;

 if ($time_iso8601 ~ "^(\d{4})-(\d{2})-(\d{2})T(\d{2})") {
  set $year $1;
  set $month $2;
  set $day $3;
 }
 access_log logs/access_$year$month$day.log main;
 error_log logs/error.log;

 access_by_lua_file "/usr/local/openresty/nginx/conf/gateway.lua";

 location ^~ /gateway {
        root html;
        index index.html index.htm;
    }

 location ^~ /api {
        proxy_pass http://api;
        proxy_read_timeout 3600;
        proxy_http_version 1.1;
        proxy_set_header X_FORWARDED_PROTO https;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header Host $host;
        proxy_set_header Connection "";
    }

 location ^~ / {
        proxy_pass http://web;
        proxy_read_timeout 3600;
        proxy_http_version 1.1;
        proxy_set_header X_FORWARDED_PROTO https;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header Host $host;
        proxy_set_header Connection "";
    }

 error_page 500 502 503 504 /50x.html;
 location = /50x.html {
  root html;
 }
}

server {
 listen 80;
 server_name $hostname;

 location / {
  rewrite ^/(.*) https://$server_name/$1 redirect;
 }
}

Dockerfile

FROM openresty/openresty:1.19.3.1-centos

LABEL maintainer="K8sCat <[email protected]>"

COPY gateway.conf /etc/nginx/conf.d/gateway.conf
COPY gateway.lua /usr/local/openresty/nginx/conf/gateway.lua
COPY nginx.conf /usr/local/openresty/nginx/conf/nginx.conf

# Install lua-resty-http
RUN /usr/local/openresty/luajit/bin/luarocks install lua-resty-http

Lua implements gateway authentication based on enterprise WeChat

Some of the configuration parameters here are obtained by obtaining variables set by Nginx.

local json = require("cjson")
local http = require("resty.http")

local uri = ngx.var.uri
local uri_args = ngx.req.get_uri_args()
local scheme = ngx.var.scheme

local corp_id = ngx.var.corp_id
local agent_id = ngx.var.agent_id
local secret = ngx.var.secret
local callback_scheme = ngx.var.callback_scheme or scheme
local callback_host = ngx.var.callback_host
local callback_uri = ngx.var.callback_uri
local use_secure_cookie = ngx.var.use_secure_cookie == "true" or false
local callback_url = callback_scheme .. "://" .. callback_host .. callback_uri
local redirect_url = callback_scheme .. "://" .. callback_host .. ngx.var.request_uri
local logout_uri = ngx.var.logout_uri or "/logout"
local token_expires = ngx.var.token_expires or "7200"
token_expires = tonumber(token_expires)

local function request_access_token(code)
    local request = http.new()
    request:set_timeout(7000)
    local res, err = request:request_uri("https://qyapi.weixin.qq.com/cgi-bin/gettoken", {
        method = "GET",
        query = {
            corpid = corp_id,
            corpsecret = secret,
        },
        ssl_verify = true,
    })
    if not res then
        return nil, (err or "access token request failed: " .. (err or "unknown reason"))
    end
    if res.status ~= 200 then
        return nil, "received " .. res.status .. " from https://qyapi.weixin.qq.com/cgi-bin/gettoken: " .. res.body
    end
    local data = json.decode(res.body)
    if data["errcode"] ~= 0 then
        return nil, data["errmsg"]
    else
        return data["access_token"]
    end
end

local function request_user(access_token, code)
    local request = http.new()
    request:set_timeout(7000)
    local res, err = request:request_uri("https://qyapi.weixin.qq.com/cgi-bin/user/getuserinfo", {
        method = "GET",
        query = {
            access_token = access_token,
            code = code,
        },
        ssl_verify = true,
    })
    if not res then
        return nil, "get profile request failed: " .. (err or "unknown reason")
    end
    if res.status ~= 200 then
        return nil, "received " .. res.status .. " from https://qyapi.weixin.qq.com/cgi-bin/user/getuserinfo"
    end
    local userinfo = json.decode(res.body)
    if userinfo["errcode"] == 0 then
        if userinfo["UserId"] then
            res, err = request:request_uri("https://qyapi.weixin.qq.com/cgi-bin/user/get", {
                method = "GET",
                query = {
                    access_token = access_token,
                    userid = userinfo["UserId"],
                },
                ssl_verify = true,
            })
            if not res then
                return nil, "get user request failed: " .. (err or "unknown reason")
            end
            if res.status ~= 200 then
                return nil, "received " .. res.status .. " from https://qyapi.weixin.qq.com/cgi-bin/user/get"
            end
            local user = json.decode(res.body)
            if user["errcode"] == 0 then
                return user
            else
                return nil, user["errmsg"]
            end
        else
            return nil, "UserId not exists"
        end
    else
        return nil, userinfo["errmsg"]
    end
end

local function is_authorized()
    local headers = ngx.req.get_headers()
    local expires = tonumber(ngx.var.cookie_OauthExpires) or 0
    local user_id = ngx.unescape_uri(ngx.var.cookie_OauthUserID or "")
    local token = ngx.var.cookie_OauthAccessToken or ""
    if expires == 0 and headers["OauthExpires"] then
        expires = tonumber(headers["OauthExpires"])
    end
    if user_id:len() == 0 and headers["OauthUserID"] then
        user_id = headers["OauthUserID"]
    end
    if token:len() == 0 and headers["OauthAccessToken"] then
        token = headers["OauthAccessToken"]
    end
    local expect_token = callback_host .. user_id .. expires
    if token == expect_token and expires then
        if expires > ngx.time() then
            return true
        else
            return false
        end
    else
        return false
    end
end

local function redirect_to_auth()
    return ngx.redirect("https://open.work.weixin.qq.com/wwopen/sso/qrConnect?" .. ngx.encode_args({
        appid = corp_id,
        agentid = agent_id,
        redirect_uri = callback_url,
        state = redirect_url
    }))
end

local function authorize()
    if uri ~= callback_uri then
        return redirect_to_auth()
    end
    local code = uri_args["code"]
    if not code then
        ngx.log(ngx.ERR, "not received code from https://open.work.weixin.qq.com/wwopen/sso/qrConnect")
        return ngx.exit(ngx.HTTP_FORBIDDEN)
    end

    local access_token, request_access_token_err = request_access_token(code)
    if not access_token then
        ngx.log(ngx.ERR, "got error during access token request: " .. request_access_token_err)
        return ngx.exit(ngx.HTTP_FORBIDDEN)
    end

    local user, request_user_err = request_user(access_token, code)
    if not user then
        ngx.log(ngx.ERR, "got error during profile request: " .. request_user_err)
        return ngx.exit(ngx.HTTP_FORBIDDEN)
    end
    ngx.log(ngx.ERR, "user id: " .. user["userid"])

    local expires = ngx.time() + token_expires
    local cookie_tail = "; version=1; path=/; Max-Age=" .. expires
    if use_secure_cookie then
        cookie_tail = cookie_tail .. "; secure"
    end

    local user_id = user["userid"]
    local user_token = callback_host .. user_id .. expires

    ngx.header["Set-Cookie"] = {
        "OauthUserID=" .. ngx.escape_uri(user_id) .. cookie_tail,
        "OauthAccessToken=" .. ngx.escape_uri(user_token) .. cookie_tail,
        "OauthExpires=" .. expires .. cookie_tail,
    }
    return ngx.redirect(uri_args["state"])
end

local function handle_logout()
    if uri == logout_uri then
        ngx.header["Set-Cookie"] = "OauthAccessToken==deleted; path=/; expires=Thu, 01 Jan 1970 00:00:00 GMT"
        --return ngx.redirect("/")
    end
end

handle_logout()
if (not is_authorized()) then
    authorize()
end

Container orchestration using DockerCompose

There are a few points to mention here:

Set the front-end args to pass in the back-end interface address when building the front-end
Set the hostname of the gateway. You can set the hostname of the gateway container.
Setting the gateway environment can pass in relevant configurations
In the final runtime, only the gateway layer exposes the port

version: "3.8"

services:
  API:
    build: ./api
    image: ca-api:latest
    container_name: ca-api

  web:
    build:
      context: ./web
      args:
        REACT_APP_BASE_URL: https://example.com/api
    image: ca-web:latest
    container_name: ca-web

  gateway:
    build: ./gateway
    image: ca-gateway:latest
    hostname: example.com
    volumes:
      - ./gateway/certs/fullchain.pem:/certs/cert.crt
      - ./gateway/certs/privkey.pem:/certs/cert.key
    ports:
      - 80:80
      -443:443
    environment:
      -CORP_ID=
      -AGENT_ID=
      -SECRET=
      - CALLBACK_HOST=example.com
      - CALLBACK_SCHEMA=https
      - CALLBACK_URI=/gateway/oauth_wechat
      -LOGOUT_URI=/gateway/oauth_logout
      -TOKEN_EXPIRES=7200
      - USE_SECURE_COOKIE=true
    container_name: ca-gateway

Open Source Code

GitHub https://github.com/k8scat/containerized-app
Gitee https://gitee.com/k8scat/containerized-app

This is the end of this article about Docker+DockerCompose packaging of web applications. For more relevant content about Docker+DockerCompose packaging of web applications, please search for previous articles on 123WORDPRESS.COM or continue to browse the following related articles. I hope everyone will support 123WORDPRESS.COM in the future!

You may also be interested in:

A brief discussion on docker-compose network settings
Docker Compose network settings explained
A brief analysis of the problem of mysql being inaccessible when deployed with docker-compose
Two simplest ways to install docker-compose
Detailed steps for installing and setting up Docker-compose
Detailed explanation of the available environment variables in Docker Compose
Detailed explanation of achieving high availability of eureka through docker and docker-compose

<<: The spacing between multiple divs with inline-block is different from the programming method

>>: Steps to use ORM to add data in MySQL
