Docker meets Intellij IDEA, Java development improves productivity tenfold

1. Preparation before development
2. New Project

Idea is a powerful tool for Java development, SpringBoot is the most popular microservice framework in the Java ecosystem, and Docker is the hottest container technology nowadays. So what kind of chemical reaction will occur when they are combined together?

1. Preparation before development

1. For Docker installation, please refer to https://docs.docker.com/install/

2. Configure Docker remote connection port

 vi /usr/lib/systemd/system/docker.service

Find ExecStart and add -H tcp://0.0.0.0:2375 at the end, as shown in the figure below

3. Restart Docker

systemctl daemon-reload
 systemctl restart docker

4. Open ports

firewall-cmd --zone=public --add-port=2375/tcp --permanent

5.Idea installs the docker plugin and restarts

6. Connect to remote docker

(1) Edit configuration

(2) Fill in the remote docker address

(3) If the connection is successful, the remote Docker container and image will be listed.

2. New Project

Create a springboot project

Project structure diagram

(1) Configure the pom file

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
     xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
  <modelVersion>4.0.0</modelVersion>
  <parent>
    <groupId>com.fengqi</groupId>
    <artifactId>dockerDemo</artifactId>
    <version>1.0.0</version>
    <relativePath>../pom.xml</relativePath> <!-- lookup parent from repository -->
  </parent>
  <groupId>com.fengqi</groupId>
  <artifactId>web</artifactId>
  <version>1.0.0</version>
  <name>web</name>
  <description>Demo project for Spring Boot</description>

 <dependencies>
    <dependency>
      <groupId>org.springframework.boot</groupId>
      <artifactId>spring-boot-starter</artifactId>
    </dependency>

    <dependency>
      <groupId>org.springframework.boot</groupId>
      <artifactId>spring-boot-starter-test</artifactId>
      <scope>test</scope>
    </dependency>
    <dependency>
      <groupId>org.springframework.boot</groupId>
      <artifactId>spring-boot-starter-web</artifactId>
    </dependency>
    <dependency>
      <groupId>log4j</groupId>
      <artifactId>log4j</artifactId>
      <version>1.2.17</version>
    </dependency>
  </dependencies>

  <build>
    <plugins>
      <plugin>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-maven-plugin</artifactId>
      </plugin>
      <plugin>
        <groupId>com.spotify</groupId>
        <artifactId>docker-maven-plugin</artifactId>
        <version>1.0.0</version>
        <configuration>
          <dockerDirectory>src/main/docker</dockerDirectory>
          <resources>
            <resource>
              <targetPath>/</targetPath>
              <directory>${project.build.directory}</directory>
              <include>${project.build.finalName}.jar</include>
            </resource>
          </resources>
        </configuration>
      </plugin>
      <plugin>
        <artifactId>maven-antrun-plugin</artifactId>
        <executions>
          <execution>
            <phase>package</phase>
            <configuration>
              <tasks>
                <copy todir="src/main/docker" file="target/${project.artifactId}-${project.version}.${project.packaging}"></copy>
              </tasks>
            </configuration>
            <goals>
              <goal>run</goal>
            </goals>
          </execution>
        </executions>
      </plugin>
    </plugins>
  </build>

(2) Create a docker directory in the src/main directory and create a Dockerfile file

FROM openjdk:8-jdk-alpine
ADD *.jar app.jar
ENTRYPOINT ["java","-Djava.security.egd=file:/dev/./urandom","-jar","/app.jar"]

(3) Create an application.properties file in the resource directory

logging.config=classpath:logback.xml
logging.path=/home/developer/app/logs/
server.port=8990

(4) Create a DockerApplication file

@SpringBootApplication
public class DockerApplication {
 public static void main(String[] args) {
 SpringApplication.run(DockerApplication.class, args);
 }
}

(5) Create a DockerController file

@RestController
public class DockerController {
 static Log log = LogFactory.getLog(DockerController.class);
 @RequestMapping("/")
 public String index() {
 log.info("Hello Docker!");
 return "Hello Docker!";
 }
}

(6) Add configuration

Command Explanation

Image tag: Specify the image name and tag. The image name is docker-demo and the tag is 1.1.

Bind ports: Bind host ports to container internal ports. The format is [host port]:[container internal port]

Bind mounts: Mount the host directory to the container's internal directory. The format is [host directory]:[container internal directory]

This springboot project will print logs in the container /home/developer/app/logs/ directory. After mounting the host directory to the container's internal directory, the logs will be persisted in the host directory outside the container.

(7) Maven packaging

(8) Run

Here we can see that the image name is docker-demo:1.1 and the docker container is docker-server

(9) Successful operation

(10) Browser access

(11) Log View

Since then, the springboot project has been deployed to docker successfully through idea! It's hard to imagine that deploying a Java web project is so simple and convenient!
