js to achieve the effect of dragging the slider

This article shares the specific code of how to drag the slider in js for your reference. The specific content is as follows

To realize dragging the slider, first analyze that the slider can be dragged, so the coordinates of the slider in the page should be changed. Then use positioning to get the top and left of the element and assign them values. The next step is to prepare events. Since it is mouse dragging, there should be three events: mousedown, mousemove, and mouseup. The slider is selected through the mousedown event, and the slider is dragged through the mousemove event. When dragging the slider, the coordinates of the mouse in the visible window are obtained and assigned to the top and left of the slider.

Specific code implementation

<!DOCTYPE html>
<html lang="en">

<head>
    <meta charset="UTF-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Document</title>
    <style>
        * {
            margin: 0;
            padding: 0;
            box-sizing: border-box;
        }

        div {
            width: 60px;
            height: 60px;
            background-color: coral;
            border-radius: 20%;
            position: absolute;
            border: 6px solid skyblue;
            left: 0;
            top: 0;
        }
    </style>
</head>

<body>
    <div></div>
    <script>
        let div = document.querySelector('div')
        let x, y
        let fn = function (e) {
            // console.log('hhhhhhhh')
            div.style.left = e.clientX - x + 'px'
            div.style.top = e.clientY - y + 'px'
            if (e.clientX - x < 30) {
                div.style.left = 0
            }
            if (e.clientY - y < 30) {
                div.style.top = 0
            }
            if (e.clientX - x > document.documentElement.clientWidth - div.offsetWidth - 30) {
                div.style.left = document.documentElement.clientWidth - div.offsetWidth + 'px'
            }
            if (e.clientY - y > document.documentElement.clientHeight - div.offsetHeight - 30) {
                div.style.top = document.documentElement.clientHeight - div.offsetHeight + 'px'
            }
        }
        div.addEventListener('mousedown', function (e) {
            x = e.offsetX
            y = e.offsetY
            document.addEventListener('mousemove', fn)
        })
        div.addEventListener('mouseup', function () {
            document.removeEventListener('mousemove', fn)
        })
    </script>
</body>

</html>

run

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.
