Detailed explanation of the use of stat function and stat command in Linux

stat function and stat command

Explanation of [inode = index node] in the Linux file: To understand inode, you must understand the disk and [directory entry]. Inode is actually the intermediate material connecting the [directory entry] and the disk.

The big circle in the picture represents the hardware disk, and the small circle inside represents a file stored on the disk.

The node of [inode = index node] (the structure that carries the node information is: stat, the definition of stat is later) contains:

1. File size
2. The last modification time of the file
3. The user to whom the file belongs
4. File permissions
5. Hard link count (the number displayed by ls -l)
6. Block location: Specifies the specific location on disk where the file is stored.

In the figure below, hello is a normal file, and hello.hard is a hard link to hello.

The folder contains the [Directory Item] of each file as shown below. The [Directory Item] contains:

1. file name
2. The size of the directory entry
3. File Type
4. inode

How to view the file's inode? Use the -i option

ls -li filename

Execution Result:

ys@ys-VirtualBox:~/lianxi1$ ls -li hello hello.hard
3801352 -rw-rw-r-- 2 ys ys 0 April 24 11:01 hello
3801352 -rw-rw-r-- 2 ys ys 0 April 24 11:01 hello.hard

It is found that the inode (3801352) of hello and hello.hard are the same, which means that only one copy is stored on the disk.

How to view directory items? Use emacs or vim to open the directory (lianxi1), as shown in the screenshot below. But I can't see the file's inode.

1. stat function: Get the file attributes of the specified file. The file attributes are stored in the structure stat.

#include <sys/types.h>
#include <sys/stat.h>
#include <unistd.h>

int stat(const char *pathname, struct stat *statbuf);
int fstat(int fd, struct stat *statbuf);
int lstat(const char *pathname, struct stat *statbuf);

struct stat structure:

struct stat {
    dev_t st_dev; /* ID of device containing file */
    ino_t st_ino; /* Inode number */
    mode_t st_mode; /* File type and mode */
    nlink_t st_nlink; /* Number of hard links */
    uid_t st_uid; /* User ID of owner */
    gid_t st_gid; /* Group ID of owner */
    dev_t st_rdev; /* Device ID (if special file) */
    off_t st_size; /* Total size, in bytes */
    blksize_t st_blksize; /* Block size for filesystem I/O */
    blkcnt_t st_blocks; /* Number of 512B blocks allocated */

    /* Since Linux 2.6, the kernel supports nanosecond
     precision for the following timestamp fields.
     For the details before Linux 2.6, see NOTES. */

    struct timespec st_atim; /* Time of last access */
    struct timespec st_mtim; /* Time of last modification */
    struct timespec st_ctim; /* Time of last status change */

   #define st_atime st_atim.tv_sec /* Backward compatibility */
   #define st_mtime st_mtim.tv_sec
   #define st_ctime st_ctim.tv_sec
   };

st_dev: device ID, not commonly used
st_ino: [inode], what is [inode]? If you don't know, just look at the explanation of [inode] above.
st_mode: file type and permissions, a total of 16 bits, as shown below.

• 0-11 bits control file permissions
• 12-15 bits control the file type

0-2 bits: other user permissions
Bits 3-5: Group user permissions
6-8 bits: User permissions
Bits 9-11: Special permissions
Bits 12-15: File type (since there are only 7 file types, bits 12-14 are sufficient)

The file type macros are as follows (the numbers below are in octal):

• S_IFSOCK 0140000 socket
• S_IFLNK 0120000 symbolic link
• S_IFREG 0100000 regular file
• S_IFBLK 0060000 block device (block device file)
• S_IFDIR 0040000 directory
• S_IFCHR 0020000 character device (character device file)
• S_IFIFO 0010000 FIFO (pipe)

Function to determine the file type, return true, false
 S_ISREG(stat.st_mode) is it a regular file?
 S_ISDIR(stat.st_mode) directory?
 S_ISCHR(stat.st_mode) character device?
 S_ISBLK(stat.st_mode) block device?
 S_ISFIFO(m) FIFO (named pipe)?
 S_ISLNK(stat.st_mode) symbolic link? (Not in POSIX.1-1996.)
 S_ISSOCK(stat.st_mode) socket? (Not in POSIX.1-1996.)

The macros for file permissions are as follows:

 S_ISUID 04000 set-user-ID bit
  S_ISGID 02000 set-group-ID bit (see below)
  S_ISVTX 01000 sticky bit (see below)

  S_IRWXU 00700 owner has read, write, and execute permission
  S_IRUSR 00400 owner has read permission
  S_IWUSR 00200 owner has write permission
  S_IXUSR 00100 owner has execute permission

  S_IRWXG 00070 group has read, write, and execute permission
  S_IRGRP 00040 group has read permission
  S_IWGRP 00020 group has write permission
  S_IXGRP 00010 group has execute permission

  S_IRWXO 00007 others (not in group) have read, write, and
       execute permission
  S_IROTH 00004 others have read permission
  S_IWOTH 00002 others have write permission
  S_IXOTH 00001 others have execute permission

• st_nlink: hard link count
• st_uid: The ID of the user to whom this file belongs
• st_gid: The group ID of the user to whom this file belongs
• st_rdev: special device ID, not commonly used
• st_size: the size of the file
• st_blksize: unknown what it does
• st_blocks: Unknown what it does
• struct timespec st_atim: time of last access
• struct timespec st_mtim: time of last modification
• struct timespec st_ctim: time of the last state change

struct timespec {
	__kernel_time_t tv_sec; /* seconds */The number of seconds from the current time to 1970.1.1 00:00:00 long tv_nsec; /* nanoseconds *//Nanoseconds (not sure from where to where)
};
1s second = 1000ms millisecond 1ms millisecond = 1000us microsecond 1us microsecond = 1000ns nanosecond

pathname: file name

Return value: 0 for success; -1 for failure, and error is set

Example: statbuf is the structure stat, and we can see that st_mode is a decimal number.

st_mode

Use gdb to display st_mode, and find that the returned st_mode is a decimal number. Use gdb's [p/o] (o represents octal representation) command to convert the decimal 33204 into octal [0100664]. The first 0 represents octal, and the last three digits [100] represent the file type. From the above description, we can see that [100] represents a normal file, and the last three digits [664] represent the permissions of this file (this user: rw-, group user: rw-, other users: r--). So from st_mode we can know the file type and permission settings (only 16 bits are used, which really saves space, awesome!)

st_uid

st_gid

It is found that st_uid and st_gid are 1000, but how does this 1000 correspond to the user? Checking the /etc/passwd file, it is found that the uid and gid used for ys are both 1000, so they correspond.

The stat command corresponds to the stat function, and the execution results are as follows:

ys@ys-VirtualBox:~/lianxi1$ stat hello
 File: hello
 Size: 11 Blocks: 8 IO Blocks: 4096 regular file
Device: 801h/2049d Inode: 3801352 Links: 2
Access: (0764/-rwxrw-r--) Uid: ( 1000/ ys) Gid: ( 1000/ ys)
Access: 2019-04-24 17:02:39.199461489 +0800
Modify: 2019-04-24 16:54:16.407461489 +0800
Change: 2019-04-24 17:03:44.927461489 +0800

2. getpwuid function: returns the line with the specified uid in the /etc/passwd file and puts the information of this line into the structure passwd. Although the return value is a pointer, there is no need to call the free function.

#include <sys/types.h>
#include <pwd.h>
struct passwd *getpwnam(const char *name);
struct passwd *getpwuid(uid_t uid);

struct passwd {
 char *pw_name; /* username */
 char *pw_passwd; /* user password */
 uid_t pw_uid; /* user ID */
 gid_t pw_gid; /* group ID */
 char *pw_gecos; /* user information */
 char *pw_dir; /* home directory */
 char *pw_shell; /* shell program */
};

3. getgrgid function: returns the line with the specified gid in the /etc/group file and puts the information of this line into the structure group. Although the return value is a pointer, there is no need to call the free function.

#include <sys/types.h>
#include <grp.h>
struct group *getgrnam(const char *name);
struct group *getgrgid(gid_t gid);

struct group {
 char *gr_name; /* group name */
 char *gr_passwd; /* group password */
 gid_t gr_gid; /* group ID */
 char **gr_mem; /* NULL-terminated array of pointers
        to names of group members */
};

4. localtime function: pass in st_mtim.tv_sec (the number of seconds from the current time to 1970.1.1 00:00:00) obtained from the stat function to get the structure tm. Although the return value is a pointer, there is no need to call the free function.

#include <time.h>
struct tm *localtime(const time_t *timep);
struct tm {
 int tm_sec; /* Seconds (0-60) */
 int tm_min; /* Minutes (0-59) */
 int tm_hour; /* Hours (0-23) */
 int tm_mday; /* Day of the month (1-31) */
 int tm_mon; /* Month (0-11) */
 int tm_year; /* Year - 1900 */
 int tm_wday; /* Day of the week (0-6, Sunday = 0) */
 int tm_yday; /* Day in the year (0-365, 1 Jan = 0) */
 int tm_isdst; /* Daylight saving time */
};

5. lstat function: When stat encounters a soft link, it will trace back to the source file and penetrate; lstat does not penetrate.

Example: Imitate ls -l file

#include <sys/types.h>
#include <sys/stat.h>
#include <unistd.h>
#include <stdio.h>
#include <string.h>
#include <pwd.h>//getpwuid
#include <stdlib.h>
#include <time.h>//localtime
#include <grp.h> //getgrgid

int main(int argc, char* argv[]){

 struct stat sbuf;
 //stat(argv[1], &sbuf);
 lstat(argv[1], &sbuf);

 char str[11] = {0};
 memset(str, '-', (sizeof str - 1));

 //File type if(S_ISREG(sbuf.st_mode)) str[0] = '-';
 if(S_ISDIR(sbuf.st_mode)) str[0] = 'd';
 if(S_ISCHR(sbuf.st_mode)) str[0] = 'c';
 if(S_ISBLK(sbuf.st_mode)) str[0] = 'b';
 if(S_ISFIFO(sbuf.st_mode)) str[0] = 'p';
 if(S_ISLNK(sbuf.st_mode)) str[0] = 'l';
 if(S_ISSOCK(sbuf.st_mode)) str[0] = 's';

 //File permissions for this user if(sbuf.st_mode & S_IRUSR) str[1] = 'r';
 if(sbuf.st_mode & S_IWUSR) str[2] = 'w';
 if(sbuf.st_mode & S_IXUSR) str[3] = 'x';

 //File permissions of this user's group if(sbuf.st_mode & S_IRGRP) str[4] = 'r';
 if(sbuf.st_mode & S_IWGRP) str[5] = 'w';
 if(sbuf.st_mode & S_IXGRP) str[6] = 'x';

 //File permissions for other users if(sbuf.st_mode & S_IROTH) str[7] = 'r';
 if(sbuf.st_mode & S_IWOTH) str[8] = 'w';
 if(sbuf.st_mode & S_IXOTH) str[9] = 'x';

 char ymd[20] = {0};
 //Get date and time struct tm* tm = localtime(&sbuf.st_atim.tv_sec);
 sprintf(ymd, "%2d月%2d %02d:%02d", tm->tm_mon + 1, tm->tm_mday,
	 tm->tm_hour + 1,tm->tm_sec);

 //-rw-r--r-- 1 ys ys 134 April 25 09:21 st2.c
 printf("%s %ld %s %s %ld %s %s\n", str, sbuf.st_nlink,
	 getpwuid(sbuf.st_uid)->pw_name, getgrgid(sbuf.st_gid)->gr_name,
	 sbuf.st_size, ymd, argv[1]);
 return 0;
}

6. Access function: Determine the permissions of the user who calls the program for the specified file (readable? writable? executable?)

#include <unistd.h>
int access(const char *pathname, int mode);

example:

#include <stdio.h>
#include <unistd.h>//access

int main(int argc, char* argv[]){
 if (access(argv[1], R_OK) == 0)
 printf("read ok\n");
 if (access(argv[1], W_OK) == 0)
 printf("write ok\n");
 if (access(argv[1], X_OK) == 0)
 printf("exe ok\n");
 if (access(argv[1], F_OK) == 0)
 printf("exists\n");
}

First use ls -l to check the permissions of the /usr/include/time.h file. The results are as follows

ys@ys-VirtualBox:~/lianxi$ ls -l /usr/include/time.h
-rw-r--r-- 1 root root 10360 April 17, 2018 /usr/include/time.h

Run the example program as user ys and view the /usr/include/time.h file. The results are as follows. Because time.h belongs to the root user and is [r--] for other users, the following result is obtained.

ys@ys-VirtualBox:~/lianxi$ ./ac /usr/include/time.h
read ok
exists

Still execute it with user ys, but add sudo, the result is as follows. The results are the same as those of the root user. Because sudo was added, the root user was programmed.

ys@ys-VirtualBox:~/lianxi$ sudo ./ac /usr/include/time.h
[sudo] password for ys:
read ok
write ok
exists

7. truncate function: truncate and expand the file size

#include <unistd.h>
#include <sys/types.h>
int truncate(const char *path, off_t length);

path: file
length:
If length is greater than the original file size, the file size is expanded to length.
If length is smaller than the original file size, the file size is truncated to length.

8. Link function: create a hard link

#include <unistd.h>
int link(const char *oldpath, const char *newpath);

Return value: Return 0 if successful, -1 if failed, and set errno.

9. Symlink function: create a soft link

#include <unistd.h>
int symlink(const char *target, const char *linkpath);

Return value: Return 0 if successful, -1 if failed, and set errno.

10. readlink function: find the actual file corresponding to the soft link and put the file name into buf. Note: Hard links will not work.

#include <unistd.h>
ssize_t readlink(const char *pathname, char *buf, size_t bufsiz);

Return value: If successful, it returns the number of bytes written to buf; if failed, it returns -1 and sets errno.

11. unlink function: delete soft and hard links, and can also delete files.

#include <unistd.h>
int unlink(const char *pathname);

Return value: Return 0 if successful, -1 if failed, and set errno.

There is a special usage: the following open code wants to create a hello file, and then delete it directly with unlink, but it can be written successfully, ret is greater than 0, and after the program is executed, it is found that the hello file is not created.

Conclusion: After executing unlink, the count is 0, but it is found that other processes still reference this file. At this point in time, unlink will not delete this file. It will be deleted after this process ends, so the following write code can be written successfully.
This feature can be used to achieve the following: when watching videos online, the video file is actually downloaded to the local computer (then unlink is used in the code). After watching the video, the count of the video file is 0 and it is automatically deleted, so there is no need to worry about the video being leaked.

#include <unistd.h>
#include <sys/types.h>
#include <stdio.h>
#include <sys/stat.h>
#include <fcntl.h>

int main(){
 int fd = open("hello", O_WRONLY | O_CREAT, 0666);
 unlink("hello");
 int ret = write(fd, "aaa", 4);
 if(ret > 0){
 printf("write OK\n");
 }

}

12. chown function: change the user and group to which the file belongs

#include <unistd.h>
int chown(const char *pathname, uid_t owner, gid_t group);

pathname: file

owner: User ID (numeric) /etc/passwd

group: group ID (numeric) /etc/group

Return value: 0 on success, -1 on failure.

13. rename function: rename

#include <stdio.h>
int rename(const char *oldpath, const char *newpath);

oldpath: the original file name or directory

newpath: new file name or directory

Return value: 0 on success, -1 on failure.

14. getcwd function: Get the current working directory

#include <unistd.h>
char *getcwd(char *buf, size_t size);

buf: current working directory

size: buffer size

Return value: Returns the current working directory if successful; returns NULL if failed

15. chdir function: change the working directory of the process

#include <unistd.h>
int chdir(const char *path);

path: target working directory

Return value: 0 for success, -1 for failure

16. mkdir function: create a directory

#include <sys/stat.h>
#include <sys/types.h>
int mkdir(const char *pathname, mode_t mode);

pathname: target working directory mode: mode & ~umask & 0777 . Note that if you do not have x permissions, you cannot cd into this directory. Return value: 0 for success, -1 for failure

17. rmdir function: delete a directory. The directory must be an empty directory, that is, there are no files in it.

#include <unistd.h>
int rmdir(const char *pathname);

18. opendir function: open a directory

#include <sys/types.h>
#include <dirent.h>
DIR *opendir(const char *name);

name: directory name

Return value: a pointer to the directory stream

19. readdir function: read directory

#include <sys/types.h>
#include <dirent.h>
DIR *opendir(const char *name);

dirp: the return value of the opendir function

Return value: dirent structure, which can be understood as the "directory entry" mentioned above. NULL means reading to the end or an error. Other than NULL means the contents of the directory entry.

20. closedir function: close directory

#include <sys/types.h>
#include <dirent.h>
int closedir(DIR *dirp);

dirp: the return value of the opendir function

21. strerron function: prints out the text information corresponding to errno.

#include <string.h>
char *strerror(int errnum);

The errnum macro is placed in the file: /usr/include/asm-generic/errno.h

example:

#include <string.h>
#include <stdio.h>
#include <asm-generic/errno.h> //EDEADLK
int main(){
 char* buf = strerror(EDEADLK);
 printf("%s\n", buf); // Resource deadlock avoided
}

22. dup and dup2 functions: redirection of file descriptors

#include <unistd.h>
int dup(int oldfd);
int dup2(int oldfd, int newfd);

dup: Similar to open, first open a new file descriptor and let the new file descriptor also point to where oldfd points. Returns the newly opened file descriptor if successful; returns -1 if unsuccessful.

dup2: first eliminate the pointer to newfd and then let newfd point to the place where oldfd points. Return newfd if successful; return -1 if failed.

Example: Call printf twice. The first printf writes the content to the file; the second printf prints the content to the screen.

#include <stdio.h>
#include <unistd.h>
#include <sys/types.h>
#include <sys/stat.h>
#include <fcntl.h>

int main(){

 int oldfd = dup(STDOUT_FILENO);
 int fd = open("www", O_WRONLY | O_CREAT, 0666);
 dup2(fd, STDOUT_FILENO);
 printf("aaaa\n");
 fflush(stdout);
 int ret = dup2(oldfd, STDOUT_FILENO);
 //int ret = dup2(oldfd, 6);
 //perror("dup2:");
 printf("reg:%d\n", ret);
 printf("aaaa\n");
 close(fd);
}

This is the end of this article about the detailed usage of stat function and stat command in Linux. For more relevant Linux stat function and stat command content, please search 123WORDPRESS.COM's previous articles or continue to browse the following related articles. I hope everyone will support 123WORDPRESS.COM in the future!
