WeChat applet uses canvas to draw clocks

WeChat applet uses canvas to draw clocks

This article shares the specific code of using canvas to draw a clock in WeChat applet for your reference. The specific content is as follows

Analog clock

Use canvas to draw a clock to realize the function of analog clock. The clock time is consistent with the system time. The scale converts the 24-hour system to the 12-hour system. It is necessary to draw the center circle, outer circle, minute hand, hour hand, and second hand separately.

The effect diagram is as follows:

The code is as follows:

index.wxml

<canvas canvas-id="myCanvas" class="mycanvas"></canvas>

index.wxss

/**index.wxss**/
.mycanvas {
  width: 100%;
  height: 100%;
  position: fixed;
}

index.js

Page({
  width: 0, //window width height: 0, //window height onLoad: function () {
    // Get system information wx.getSystemInfo({
      // Get system information successfully, save the obtained width and height of the system window success: res => {
        // console.log(res)
        this.width = res.windowWidth
        this.height = res.windowHeight
        }
      })
    },
  timer: null, //timer onReady: function(){
    //Create ctx instance var ctx = wx.createCanvasContext('myCanvas')
    //Convert the angle to radians for later use //Calculation formula: radians = angle*Math.PI / 180
    const D6 = 6 * Math.PI / 180
     const D30 = 30 * Math.PI / 180
     const D90 = 90 * Math.PI / 180
     // Get the width and height values ​​var width = this.width, height = this.height
     // Calculate the dial radius and leave 30px margin var radius = width / 2 -30
     // Draw once per second draw()
     this.timer = setInterval(draw, 1000)
     //Drawing function function draw(){
       // Set the axis origin to the center of the window ctx.translate(width / 2, height / 2)
       // Draw the dial drawClock(ctx,radius)
       // Draw the pointer drawHand(ctx, radius)
       //Execute drawing ctx.draw()
   }

    // Draw the dial function drawClock(ctx, radius){
      // Draw a big circle // The radius of the big circle is radius and the line thickness is 2px
      ctx.setLineWidth(2) //Set line thickness ctx.beginPath() //Start a new path ctx.arc(0, 0, radius, 0, 2 * Math.PI, true)
      ctx.stroke() //Draw lines //Draw concentric circles //The radius of the center circle is 8px and the line thickness is 1px
      ctx.setLineWidth(1) //Set line thickness ctx.beginPath() //Start a new path ctx.arc(0, 0, 8, 0, 2 * Math.PI, true)
      ctx.stroke() //Draw a line // Draw a large dial with a line thickness of 5px
      ctx.setLineWidth(5)
      for (var i = 0; i < 12; ++i){
        // Clockwise with the origin as the center (the rotation angles will be superimposed if multiple calls are made)
        // The large dial needs to draw 12 lines, representing 12 hours, and rotates 30 degrees each time ctx.rotate(D30) // 360 / 12 = 30
        ctx.beginPath()
        ctx.moveTo(radius, 0)
        ctx.moveTo(radius - 15, 0) //Large scale length 15px
        ctx.stroke()
      }
      // Draw a small dial with a line thickness of 1px
      ctx.setLineWidth(1)
      for(var i = 0; i < 60; ++i){
        // The small dial needs to draw 60 lines, representing 60 minutes or 60 seconds, and rotates 6 degrees each time ctx.rotate(D6)
        ctx.beginPath()
        ctx.moveTo(radius, 0)
        ctx.lineTo(radius - 10, 0) //Small dial length 10px
        ctx.stroke()
      }
      //Draw text ctx.setFontSize(20) //Font size ctx.textBaseline = 'middle' // Vertically center the text // Calculate the radius r of the text from the center of the dial
      var r = radius - 30
      for(var i = 1; i <= 12; ++i){
        // Calculate text coordinates using trigonometric functions var x = r * Math.cos(D30 * i - D90)
        var y = r * Math.sin(D30 * i - D90)
        if(i > 10){ // Adjust the positions of 11 and 12 // Draw text on the canvas fillText(text, upper left corner x coordinate, upper left corner y coordinate)
          ctx.fillText(i, x - 12, y)
        } else {
          ctx.fillText(i, x-6, y)
        }
      }
    }
    //Draw the pointer function drawHand(ctx, radius){
      var t = new Date() // Get the current time var h = t.getHours() //Hours var m = t.getMinutes() //Minutes var s = t.getSeconds() //Seconds h = h > 12 ? h -12 :h //Convert 24-hour system to 12-hour system //The time starts at 3 o'clock and rotates 90 degrees counterclockwise to point to 12 o'clock ctx.rotate(-D90)
      //Draw the hour hand ctx.save() //Record the rotation status // Calculate the scale pointed by the hour hand // 30 degrees * h can be used to calculate the rotation angle of each hour // If the time is not an hour, you need to use h + m / 60 + s / 3600 to calculate the exact offset ctx.rotate(D30 * (h + m / 60 + s / 3600))
      ctx.setLineWidth(6)
      ctx.beginPath()
      ctx.moveTo(-20, 0)
      ctx.lineTo(radius / 2.6, 0)
      ctx.stroke()
      ctx.restore()
      // Draw the minute hand ctx.save()
      ctx.rotate(D6 * (m + s / 60))
      ctx.setLineWidth(4)
      ctx.beginPath()
      ctx.moveTo(-20, 0)
      ctx.lineTo(radius / 1.8, 0)
      ctx.stroke()
      ctx.restore()
      //Draw the second hand ctx.save()
      ctx.rotate(D6 * s)
      ctx.setLineWidth(2)
      ctx.beginPath()
      ctx.moveTo(-20, 0)
      ctx.lineTo(radius / 1.6, 0)
      ctx.stroke()
      ctx.restore()
    }
  }
})

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.
