uni-app implements NFC reading function

uni-app implements NFC reading function

This article shares the specific code of uni-app to implement the NFC reading function for your reference. The specific content is as follows

I haven’t written a blog for a long time. Today I have the rare time to record every bit of my learning.

1. NFC method.js

//Package path const package_NdefRecord = 'android.nfc.NdefRecord';
const package_NdefMessage = 'android.nfc.NdefMessage';
const package_TECH_DISCOVERED = 'android.nfc.action.TECH_DISCOVERED';
const package_Intent = 'android.content.Intent';
const package_Activity = 'android.app.Activity';
const package_PendingIntent = 'android.app.PendingIntent';
const package_IntentFilter = 'android.content.IntentFilter';
const package_NfcAdapter = 'android.nfc.NfcAdapter';
const package_Ndef = 'android.nfc.tech.Ndef';
const package_NdefFormatable = 'android.nfc.tech.NdefFormatable';
const package_Parcelable = 'android.os.Parcelable';
const package_String = 'java.lang.String';

let NfcAdapter;
let NdefRecord;
let NdefMessage;
let readyRead = true; //Start reading let noNFC = false;
let techListsArray = [
 ['android.nfc.tech.IsoDep'],
 ['android.nfc.tech.NfcA'],
 ['android.nfc.tech.NfcB'],
 ['android.nfc.tech.NfcF'],
 ['android.nfc.tech.Nfcf'],
 ['android.nfc.tech.NfcV'],
 ['android.nfc.tech.NdefFormatable'],
 ['android.nfc.tech.MifareClassi'],
 ['android.nfc.tech.MifareUltralight']
];
// Data to be written let text = '{id:8888,name:nfc,stie:wangqin.com}';
let readResult = '';

export default {
 listenNFCStatus: function() {
  console.log("---------listenNFCStatus--------------")
  let that = this;
  try {
   let main = plus.android.runtimeMainActivity();
   let Intent = plus.android.importClass('android.content.Intent');
   let Activity = plus.android.importClass('android.app.Activity');
   let PendingIntent = plus.android.importClass('android.app.PendingIntent');
   let IntentFilter = plus.android.importClass('android.content.IntentFilter');
   NfcAdapter = plus.android.importClass('android.nfc.NfcAdapter');
   let nfcAdapter = NfcAdapter.getDefaultAdapter(main);
   if (nfcAdapter == null) {
    uni.showToast({
     title: 'The device does not support NFC! ',
     icon: 'none'
    })
    noNFC = true;
    return;
   }
   if (!nfcAdapter.isEnabled()) {
    uni.showToast({
     title: 'Please enable the NFC function in the system settings first! ',
     icon: 'none'
    });
    noNFC = true;
    return;
   } else {
    noNFC = false;
   }

   let intent = new Intent(main, main.getClass());
   intent.addFlags(Intent.FLAG_ACTIVITY_SINGLE_TOP);
   let pendingIntent = PendingIntent.getActivity(main, 0, intent, 0);
   let ndef = new IntentFilter("android.nfc.action.TECH_DISCOVERED");
   ndef.addDataType("*/*");
   let intentFiltersArray = [ndef];

   //Key code const promise = new Promise((resolve, reject) => {
    plus.globalEvent.addEventListener('newintent', function() {
     // Polling call NFC
     // setTimeout(that.nfcRuning(resolve), 1000);
     setTimeout(() => {
         that.nfcRunning(resolve)
     }, 1000);
    });
   })

   nfcAdapter.enableForegroundDispatch(main, pendingIntent, intentFiltersArray, techListsArray);
   return promise
  } catch (e) {
  }
 },
 nfcRunning: function(resolve) {
  // console.log("--------------nfcRunning---------------")
  NdefRecord = plus.android.importClass("android.nfc.NdefRecord");
  NdefMessage = plus.android.importClass("android.nfc.NdefMessage");
  let main = plus.android.runtimeMainActivity();
  let intent = main.getIntent();
  let that = this;
  if (package_TECH_DISCOVERED == intent.getAction()) {
    if (readyRead) {
     //Here we get the NFC data through the read method const id = that.read(intent);
    // readyRead = false;
    //Return the data resolve(id)
   }
  }
 },

 read(intent) {
  // toast('Do not remove the label, data is being read');
  let that = this;
  // NFC id
  let bytesId = intent.getByteArrayExtra(NfcAdapter.EXTRA_ID);
  let nfc_id = that.byteArrayToHexString(bytesId);

  return nfc_id;
 },
 byteArrayToHexString: function(inarray) { // converts byte arrays to string
  let i, j, inn;
  let hex = ["0", "1", "2", "3", "4", "5", "6", "7", "8", "9", "A", "B", "C", "D", "E", "F"];
  let out = "";

  for (j = 0; j < inarray.length; ++j) {
   inn = inarray[j] & 0xff;
   i = (inn >>> 4) & 0x0f;
   out += hex[i];
   i = inn & 0x0f;
   out += hex[i];
  }
  return out;
 },

}

function toast(content) {
 uni.showToast({
  title: content,
  icon: 'none'
 })
}

2. Calling methods on pages using NFC

<view class="flex nfc-ewm">
  <view class="nfc-ewm-item" style="border-right: 1px solid #ccc;" @click="testNFC">
   <image src="@/assets/images/application/icon-nfc.png" alt=""></image>NFC sensing</view>
  <view class="nfc-ewm-item" @click="openScanCode">
   <image src="@/assets/images/application/icon-ewm.png" alt=""></image>QR code scanning</view>
</view>


import testtest from "../../../../../components/hexiii-nfc/hexiii-nfc.js"

 methods: {
  async testNFC() {
   //Here we use asynchronous method to get the read NFC data const nfcId = await testtest.listenNFCStatus();
   //console.log(nfcId )

   //The following data is my business logic code. If you only need to read the NFC data, the line of code above will suffice.
   const arr = []
   this.list2.forEach(e => {
    arr.push(e.code)
   })
   if(!nfcId) return
   if ( arr.indexOf(nfcId) === -1) {
    uni.showToast({
     icon: 'none',
     Title: 'No corresponding inspection point found!',
     duration: 2000
    });
   } else {
    uni.showToast({
     icon: 'none',
     title: 'Recognition successful!',
     duration: 2000
    });
    uni.navigateTo({
     url: `/pages/application/XunJianGuanLi/XunJianRenWu/KaiShiXunJian3/index?id=${this.id}&spotCode=${nfcId}&delta=${this.delta+1}`,
    });
   }
  },
}

3. Page renderings

4. Summary

The above is my implementation of reading NFC data. It automatically jumps to the corresponding check-in inspection point according to the data read by the user scanning NFC. The code needs to be improved, please give me more guidance. In the first part of the NFC method, because I only need to read the code, many redundant and unused codes have been deleted by me, leaving only the required code.

The above is the full content of this article. I hope it will be helpful for everyone’s study. I also hope that everyone will support 123WORDPRESS.COM.
