Tutorial on Installing Nginx-RTMP Streaming Server on Ubuntu 14

1. RTMP

RTMP streaming protocol is a real-time audio and video transmission protocol developed by Adobe;

2. Nginx-rtmp

nginx-rtmp is an RTMP service module based on nginx, open source, free

https://github.com/arut/nginx-rtmp-module

3: Installation process in Ubuntu server 14

1. First download and install nginx and nginx-rtmp compilation dependency tools

sudo apt-get install build-essential libpcre3 libpcre3-dev libssl-dev

2. Create a working directory and switch to it

mkdir ~/working
cd ~/working

3. Download nginx and nginx-rtmp source code

wget http://nginx.org/download/nginx-1.7.5.tar.gz
wget https://github.com/arut/nginx-rtmp-module/archive/master.zip

4. Install the unzip tool and decompress the downloaded installation package

sudo apt-get install unzip

5. Unzip the nginx and nginx-rtmp installation packages

tar -zxvf nginx-1.7.5.tar.gz
unzip master.zip

6. Switch to the nginx-directory

cd nginx-1.7.5

7. Add nginx-rtmp template to nginx

./configure --with-http_ssl_module --add-module=../nginx-rtmp-module-master

8. Compile and install

make
sudo make install

9. Install nginx init script

sudo wget https://raw.github.com/JasonGiedymin/nginx-init-ubuntu/master/nginx -O /etc/init.d/nginx
sudo chmod +x /etc/init.d/nginx
sudo update-rc.d nginx defaults

10. Start and stop the nginx service and generate the configuration file

sudo service nginx start
sudo service nginx stop

11. Install FFmpeg

sudo apt-add-repository ppa:jon-severinsson/ffmpeg
sudo apt-get update
sudo apt-get install ffmpeg

12. Configure nginx-rtmp server

Open /usr/local/nginx/conf/nginx.conf

Add the following configuration at the end

rtmp {
  server {
      listen 1935;
      chunk_size 4096;

      application live
          live on;
          record off;
          exec ffmpeg -i rtmp://localhost/live/$name -threads 1 -c:v libx264 -profile:v baseline -b:v 350K -s 640x360 -f flv -c:a aac -ac 1 -strict -2 -b:a 56k rtmp://localhost/live360p/$name;
      }
      application live360p
          live on;
          record off;
    }
  }
}

13. Save the above configuration file and restart the nginx service

sudo service nginx restart

14. If you use a firewall, please allow port tcp 1935

16: Use the client to collect video in real time using the rtmp protocol

Field 1: rtmp://your.vultr.ip/live/
Field 2: stream-key-your-set

For video capture, I use the iPhone5 capture program https://github.com/jgh-/VideoCore

[_session startRtmpSessionWithURL:@"rtmp://192.168.86.246/live/" andStreamKey:@"test"];

17. During the client acquisition process above, you can use the VLC player to open the RTMP real-time stream

rtmp://your.vultr.ip/live/stream-key-you-set

Open the above stream to test the real-time effect

18: More configuration about nginx-rtmp

https://github.com/arut/nginx-rtmp-module/wiki/Directives

Summarize
