Generate OpenSSL certificates in Linux environment

Generate OpenSSL certificates in Linux environment

1. Environment: CentOS7, Openssl1.1.1k.

2. Concept:

Root certificate: It is the basis for generating server certificates and client certificates. It can also be called a self-signed certificate, i.e. a CA certificate.

Server certificate: issued by the root certificate and configured on the server.

Client certificate: issued by the root certificate and configured on the client. It can also be configured on a web server and installed on a browser.

Symmetric encryption: A file is encrypted with a password, and then the same password is used to decrypt it.

Asymmetric encryption: one password is used for encryption and another set of passwords is used for decryption. This includes the following two situations:

When used to encrypt data: public key encryption, private key decryption

When used for file signing: private key signature, public key signature verification

3. Steps:

1. View the openssl configuration file openssl.cnf

vim /etc/pki/tls/openssl.cnf

2. Create the directory and files required for the root certificate CA

cd /etc/pki/CA

#Create the directories and files required in the configuration file information mkdir -pv {certs,crl,newcerts,private}

touch {serial,index.txt}

3. Indicate the starting number of the certificate

echo 01 >> serial

4. Generate root certificate

# Generate CA private key (ca.key)
openssl genrsa -des3 -out ca.key 2048
# Generate CA certificate signing request (ca.csr)
openssl req -new -key ca.key -out ca.csr
# Generate a self-signed CA certificate (ca.cert)
openssl x509 -req -days 3650 -in ca.csr -signkey ca.key -out ca.crt

5. Generate server certificate

# Generate server private key (server.key)
openssl genrsa -des3 -out server.key 2048
# Generate server certificate signing request (server.csr)
openssl req -new -key server.key -out server.csr
# Use the CA certificate to sign the server CSR to generate the server certificate (server.cert)
openssl ca -days 3650 -in server.csr -out server.crt -cert ca.crt -keyfile ca.key

6. Generate client certificate

# Generate client private key (client.key)
openssl genrsa -des3 -out client.key 2048
# Generate client certificate signing request (client.csr)
openssl req -new -key client.key -out client.csr
# Use the CA certificate to sign the client csr to generate the client certificate (client.cert)
openssl ca -days 3650 -in client.csr -out client.crt -cert ca.crt -keyfile ca.key

7. View the certificate content

openssl x509 -in server.crt -noout -text

8. Convert crt to pem

openssl x509 -in ca.crt -out ca.pem -outform PEM

openssl x509 -in server.crt -out server.pem -outform PEM

openssl x509 -in client.crt -out client.pem -outform PEM

9. Strip the password of the private key

openssl rsa -in server.key -out serverkey.pem

openssl rsa -in client.key -out clientkey.pem

The generated certificate list:
