Summary of Node.js service Docker container application practice

This article will not explain the use and installation of Docker commands, because the previous article, which teaches you how to get started with Docker from zero foundation to practice, has already explained it in detail. If you are not clear about it, you can click the link to go back and read it again. The focus of this article is to introduce how to use Docker containerization for Node.js projects and some practical optimizations, as well as some common problems. Of course, if you have other questions about use, you are welcome to leave a message in the comment area.

About the author: Wu Yuejun, Nodejs Developer, a post-90s youth who loves technology and likes to share, public account "Nodejs Technology Stack", Github open source project www.nodejs.red

What can you learn from this article?

• Learn how to containerize a Node.js service with Docker
• Dynamically set environment variables to build different versions with one Dockerfile
• How to authenticate Node.js private NPM packages when building images
• Issues that should be noted when using Docker containerization of Egg.js framework
• Optimizing Docker image size and build time

Dockerizing a Node.js application

In this article, we will start by creating a simple Node.js application, then create a Docker image for the application, and build and run it.

Creating a Node.js Project

First we need to create an app.js to start an HTTP service, and then we will use Docker to run this program.

const http = require('http');
const PORT = 30010;

const server = http.createServer((req, res) => {
 res.end('Hello Docker');
})

server.listen(PORT, () => {
 console.log('Running on http://localhost:', PORT, 'NODE_ENV', process.env.NODE_ENV);
});

Then we create a package.json file, which describes your application and the required dependencies. Students who have written Node.js should be very familiar with it. Here I added two commands, npm run dev and npm run pro , in scripts, because I want to introduce how to pass in parameters at build time to dynamically set environment variables.

{
 "name": "hello-docker",
 "version": "1.0.2",
 "description": "",
 "author": "May",
 "main": "app.js",
 "scripts": {
 "dev": "NODE_ENV=dev node app.js",
 "pro": "NODE_ENV=pro node app.js"
 }
}

Dockerfile

This is the information contained in a Dockerfile file. These commands are also explained in Getting Started with Docker and Practice.

FROM node:10.0-alpine

RUN apk --update add tzdata \
 && cp /usr/share/zoneinfo/Asia/Shanghai /etc/localtime \
 && echo "Asia/Shanghai" > /etc/timezone \
 && apk del tzdata

RUN mkdir -p /usr/src/nodejs/

WORKDIR /usr/src/nodejs/

# add npm package
COPY package.json /usr/src/nodejs/package.json
RUN cd /usr/src/nodejs/
RUN npm i

# copy code
COPY ./usr/src/nodejs/

EXPOSE 30010

CMD npm run dev

Create a .dockerignore file at the same level as the Dockerfile to avoid putting your local debug files, node_modules and other files into the Docker container

.git
node_modules
npm-debug.log

At this point, you can build a Docker image using the following command:

$ docker image build -t mayjun/hello-docker

Then you can run a Docker container through the docker run -d -p 30010:30010 mayjun/hello-docker command, but I have a question. I have a distinction between production and testing. According to the above CMD npm run dev , only one environment can be packaged. Of course, you can also create a file to implement it or some other methods.

Dynamically setting environment variables

To solve the above questions, my idea is to pass in parameters when building the image to dynamically set the environment variables and modify the Dockerfile file. See the following implementation:

EXPOSE 30010

ARG node_env # Newly added ENV NODE_ENV=$node_env # Newly added CMD npm run ${NODE_ENV} # Modify

The following is an explanation of the above code

• The ARG directive defines a variable that users can pass to the builder ARG node_env at build time using the --build-arg= flag of the docker build command
• Use ENV to reference this variable ENV NODE_ENV=$node_env in Dockerfile
• This step uses CMD npm run ${NODE_ENV}

All that remains is to dynamically pass in parameters when building the image.

$ docker image build --build-arg node_env=dev -t mayjun/hello-docker:1.0.2 . # Build a test environment $ docker image build --build-arg node_env=pro -t mayjun/hello-docker:1.0.2 . # Build a production environment

Running the container

$ docker run -d -p 30010:30010 mayjun/hello-docker:1.0.2
$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
2bc6e62cd0e8 mayjun/hello-docker:1.0.2 "/bin/sh -c 'npm run..." 3 minutes ago Up 3 minutes 0.0.0.0:30010->30010/tcp elastic_bouman

View container logs

docker logs -f 2bc6e62cd0e8

> [email protected] dev /usr/src/nodejs
> NODE_ENV=dev node app.js

Running on http://localhost:30010 NODE_ENV dev

I packaged the above code into a mirror mayjun/hello-docker:1.0.2, which can be pulled and viewed docker pull mayjun/hello-docker:1.0.2

Docker and Node.js private NPM packages

If you use private NPM packages in your project, an error of 404 will occur when installing the npm private package during the image building process of Docker. If it is outside the container, we can use npm login to log in to an account with NPM private package permissions to solve this problem, but this cannot be done in Docker.

Creating an Authentication Token

In order to install private packages, we need to " create authentication tokens " so that we can access our private NPM packages in the continuous integration environment and Docker container. For how to create them, please refer to https://docs.npmjs.com/creating-and-viewing-authentication-tokens

Implementation

We need to add the following two commands when creating the Dockerfile file:

# 528das62-e03e-4dc2-ba67-********** This Token is the authentication token created for you
RUN echo "//registry.npmjs.org/:_authToken=528das62-e03e-4dc2-ba67-**********" > /root/.npmrc
RUN cat /root/.npmrc

Egg framework Docker containerization

In Egg, if it is egg-scripts start --daemon , remove --daemon and just use egg-scripts start, otherwise the Docker container will fail to start.

See the following code example and modify package.json. The Dockerfile is the same as the first Dockerized Node.js application above.

package.json

{
 "scripts": {
 "start": "egg-scripts start" // remove --daemon
 }
}

You can also refer to Egg Issues "Docker container cannot be run, has anyone encountered this?" https://github.com/eggjs/egg/issues/1543

Docker image size and build time optimization

If an image is not optimized, its size will usually be very large. The following are some optimizations made in practice.

RUN/COPY Layering

Each instruction in the Dockerfile creates an image layer. Each image layer can be reused and cached without modifying the Dockerfile instructions or copied project files.

The following code can be found in the mayjun/hello-docker:latest image repository. In the following example, after the source code is changed, the NPM module will be reinstalled regardless of whether package.json has changed. This is obviously not good, so we need to improve it below.

# ...

WORKDIR /usr/src/nodejs/hello-docker
COPY . /usr/src/nodejs/hello-docker

RUN npm install

# ...

The improved code is as follows. We advance package.json. If package.json is not modified, the NPM package will not be reinstalled, which will also reduce the deployment time.

# ...

WORKDIR /usr/src/nodejs/

# add npm package
COPY package.json /usr/src/app/package.json
RUN cd /usr/src/app/
RUN npm i

# copy code
COPY . /usr/src/app/

# ...

Optimizing the Node.js Alpine image

mayjun/hello-docker:1.0.0 This image can also be searched in the Docker repository. It is about 688MB before optimization.

$ docker images REPOSITORY TAG IMAGE ID CREATED SIZE mayjun/hello-docker 1.0.0 7217fb3e9daa 5 seconds ago 688MB

Optimizing with Alpine

Alpine is a very small Linux distribution. If you want to significantly reduce the size of the image, choosing the Alpine version of Node.js is the easiest. In addition, the default time zone of alpine is not the domestic time zone, so the Dockerfile needs to configure the time zone.

FROM node:10.0-alpine

RUN apk --update add tzdata \
 && cp /usr/share/zoneinfo/Asia/Shanghai /etc/localtime \
 && echo "Asia/Shanghai" > /etc/timezone \
 && apk del tzdata

RUN echo "Asia/Shanghai" > /etc/timezone

RUN mkdir -p /usr/src/nodejs/

WORKDIR /usr/src/nodejs/

# add npm package
COPY package.json /usr/src/app/package.json
RUN cd /usr/src/app/
RUN npm i

# copy code
COPY . /usr/src/app/

EXPOSE 30010
CMD npm start

Repackaged a version mayjun/hello-docker:1.1.0 and checked the effect again. You can see that the image file has been reduced from 688MB to 85.3MB. This size optimization is still very large.

$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
mayjun/hello-docker 1.1.0 169e05b8197d 3 minutes ago 85.3MB

Do not package devDependencies in production environments

Some packages used in the test environment should not be included when mirroring the production environment, that is, the devDependencies object in the package.json file can be filtered by specifying the --production parameter after npm i

The improvements are as follows:

FROM node:10.0-alpine

# Omit...

# add npm package
COPY package.json /usr/src/app/package.json
RUN cd /usr/src/app/
RUN npm i --production # Changes here # Omitted...

Repackaged a version mayjun/hello-docker:1.2.0 and checked the effect again. You can see that the image file has been reduced from 85.3MB to 72.3MB

$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
mayjun/hello-docker 1.2.0 f018aa578711 3 seconds ago 72.3MB

Frequently asked questions

Question1

The following command reports the following error when deleting the image:

$ docker rmi 6b1c2775591e
Error response from daemon: conflict: unable to delete 6b1c2775591e (must be forced) - image is referenced in multiple repositories

If you are careful, you may find that the image ID 6b1c2775591e points to both the hello-docker and mayjun/hello-docker repositories, which is why the deletion failed.

$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
mysql 5.7 383867b75fd2 6 days ago 373MB
hello-docker latest 6b1c2775591e 7 days ago 675MB
mayjun/hello-docker latest 6b1c2775591e 7 days ago 675MB

Specify repository and tag to delete. After executing the delete command, check again and you will find that the mayjun/hello-docker repository is gone.

$ docker rmi mayjun/hello-docker
$ docker images
REPOSITORY TAG IMAGE ID CREATED SIZE
mysql 5.7 383867b75fd2 6 days ago 373MB
hello-docker latest 6b1c2775591e 7 days ago 675MB

Question2

The following error is reported when executing the delete image command:

$ docker rmi 9be467fd1285
Error response from daemon: conflict: unable to delete 9be467fd1285 (cannot be forced) - image is being used by running container 1febfb05b850

According to the prompt, there is a running container. You need to stop the container first, delete the container, and then delete the image.

$ docker container kill 1febfb05b850 # Stop the container $ docker rm 1febfb05b850 # Delete the container $ docker rmi 9be467fd1285 # Delete the image

Question 3

The working directory (WORKDIR) set should be consistent with the following

...
WORKDIR /usr/src/nodejs/

# add npm package
COPY package.json /usr/src/node/package.json # Directory inconsistency RUN cd /usr/src/node/ # Directory inconsistency RUN npm i
...

For example, if the above configuration is inconsistent with the working directory and the actual COPY directory, the following error will be reported:

Then change it to the same as follows

...
WORKDIR /usr/src/nodejs/

# add npm package
COPY package.json /usr/src/nodejs/package.json # Change to the same RUN cd /usr/src/nodejs/ # Change to the same RUN npm i
...
