Example code for realizing charging effect of B station with css+svg

Example code for realizing charging effect of B station with css+svg

difficulty

Two mask creation of svg graphics

First, the code

This is the content of the pink box on the left

There's nothing good to say about this.

<div id="con">
    <div id="TA-con">
      <div id="text-con">
        <div id="linght"></div>
        <div id="TA">Charge TA</div>
      </div>
    </div>
body {
      margin: 0;
      padding: 0;
      background-color: #eee;
    }
    /* Set the white container */
    #con {
      width: 350px;
      height: 85px;
      background-color: #fff;
      position: relative;
      border-radius: 4px;
      margin:50px auto;
    }
#TA-con
      width: 157px;
      height: 50px;
      background-color: #f25d8e;
      box-shadow: 0 4px 4px rgba(255, 112, 159, .3);
      position: absolute;
      top: 50%;
      left: 5%;
      transform: translateY(-50%);
      border-radius: 4px;
      cursor: pointer;
    }
    /* Set the text to center in the container */
    #text-con {
      width: 100px;
      height: 100%;
      margin: 0 auto;
      position: relative;
    }
    /* Make a small lightning */
    #linght {
      width: 0;
      height: 0;
      position: absolute;
      top: 36%;
      left: 4px;
      border-color: transparent;
      border-style: solid;
      border-width: 10px;
      border-top: 10px solid #fff;
      border-radius: 4px;
      transform: rotate(-55deg);
    }
    #linght::after {
      position: absolute;
      top: -13px;
      left: -11px;
      content: "";
      width: 0;
      height: 0;
      border-color: transparent;
      border-style: solid;
      border-width: 10px;
      border-top: 10px solid #fff;
      transform: rotate(180deg);
      border-radius: 4px;
    }
    /* text*/
    #TA {
      float: right;
      line-height: 50px;
      font-size: 15px;
      color: #fff;
    }
    #TA-con:hover {
      background-color: #ff6b9a;
    }

What we are doing here is to create an SVG graphic with a gray background. It looks a lot and complicated. Don’t worry, I didn’t write it.

 <div id="tube-con">
      <svg viewBox="0 0 1028 385" fill="none" xmlns="http://www.w3.org/2000/svg">
        <path d="M1 77H234.226L307.006 24H790" stroke="#e5e9ef" stroke-width="20" />
        <path d="M0 140H233.035L329.72 71H1028" stroke="#e5e9ef" stroke-width="20" />
        <path d="M1 255H234.226L307.006 307H790" stroke="#e5e9ef" stroke-width="20" />
        <path d="M0 305H233.035L329.72 375H1028" stroke="#e5e9ef" stroke-width="20" />
        <rect y="186" width="236" height="24" fill="#e5e9ef" />
        <ellipse cx="790" cy="25.5" rx="25" ry="25.5" fill="#e5e9ef" />
        <circle r="14" transform="matrix(1 0 0 -1 790 25)" fill="white" />
        <ellipse cx="790" cy="307.5" rx="25" ry="25.5" fill="#e5e9ef" />
        <circle r="14" transform="matrix(1 0 0 -1 790 308)" fill="white" />
      </svg>

I used this thing, the web version is online. After drawing, you can right-click to copy the code. It’s simple, isn’t it! www.figma.com/

Now that the SVG drawing is ready, we need to think about how to complete it

Things Needed:
1: SVG image with gray background color;
2: A pink SVG image. When I hover the mouse to the pink box on the left, the pink SVG image is fully expanded and the initial value is 0;
3: A small yellow square that moves quickly;

The gray background is ready, but the pink and yellow SVG images are missing.

Mask is used to make a pink SVG mask

<div id="mask">

There is no difference with the gray svg, just change the color

<svg viewBox="0 0 1028 385" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M1 77H234.226L307.006 24H790" stroke="#f25d8e" stroke-width="20" />
<path d="M0 140H233.035L329.72 71H1028" stroke="#f25d8e" stroke-width="20" />
<path d="M1 255H234.226L307.006 307H790" stroke="#f25d8e" stroke-width="20" />
<path d="M0 305H233.035L329.72 375H1028" stroke="#f25d8e" stroke-width="20" />
<rect y="186" width="236" height="24" fill="#f25d8e" />
<ellipse cx="790" cy="25.5" rx="25" ry="25.5" fill="#f25d8e" />
<circle r="14" transform="matrix(1 0 0 -1 790 25)" fill="white" />
<ellipse cx="790" cy="307.5" rx="25" ry="25.5" fill="#f25d8e" />
<circle r="14" transform="matrix(1 0 0 -1 790 308)" fill="white" />
</svg>
</div>

orange-mask is used to make a mask for yellow svg

<div id="orange-mask" >

There is no difference with the gray svg, just change the color

<svg viewBox="0 0 1028 385" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M1 77H234.226L307.006 24H790" stroke="#ffd52b" stroke-width="20" />
<path d="M0 140H233.035L329.72 71H1028" stroke="#ffd52b" stroke-width="20" />
<path d="M1 255H234.226L307.006 307H790" stroke="#ffd52b" stroke-width="20" />
<path d="M0 305H233.035L329.72 375H1028" stroke="#ffd52b" stroke-width="20" />
<rect y="186" width="236" height="24" fill="#ffd52b" />
<ellipse cx="790" cy="25.5" rx="25" ry="25.5" fill="#ffd52b" />
<circle r="14" transform="matrix(1 0 0 -1 790 25)" fill="white" />
<ellipse cx="790" cy="307.5" rx="25" ry="25.5" fill="#ffd52b" />
<circle r="14" transform="matrix(1 0 0 -1 790 308)" fill="white" />
</svg>
</div>
<p id="people">Total <b>0</b> people</p>
</div>
</div>

CSS Code

/* Create a graphics container */
    #tube-con {
      width: 157px;
      height: 55px;
      position: absolute;
      right: -5px;
      top: 15px;
    }
    /* Set the width and height of the svg graphic*/
    svg {
      width: 100%;
      height: 100%;
    }
    /* Create a mask with a width of 0. When I hover the charging box, the width expands*/
    #mask {
      width: 0px;
      height: 100%;
      overflow: hidden;
      position: absolute;
      top: 0;
      left: 0;
      transition:all 0.5s;
    }
    /* Set the width and height of the masked sbg separately to ensure that the width and height have a fixed value instead of a percentage*/
    #mask svg {
      width: 157px;
      height: 55px;
    }
    /* Start the animation when hovering over the charging frame and spread the pink line*/
    #TA-con:hover+#tube-con>#mask{
      width:157px;
    }
    /* Start the animation when the charging frame is hovered, add a yellow fast-moving animation*/
    #TA-con:hover+#tube-con>#orange-mask{
      animation: move1 0.5s linear 0.2s infinite;
    }
    #TA-con:hover+#tube-con>#orange-mask svg{
      animation: movetwo 0.5s linear 0.2s infinite;
    }
    /* Create a yellow moving mask */
    #orange-mask{
      width: 18px;
      height: 100%;
      overflow: hidden;
      position:absolute;
      left:-15px;
      top:0px;
    }
    /* Create yellow moving content */
    #orange-mask svg {
      position: absolute;
      top:0;
      left:15px;
      width: 157px;
      height: 55px;
    }
    @keyframes move1 {
      0%{
        left:-15px;
      }
      100%{
        left:140px;
      }
    }
    @keyframes movetwo {
      0%{
        left:15px;
      }
      100%{
        left:-140px;
      }
    }
    #people{
      position:absolute;
      right:10px;
      top:8px;
      font-size:12px;
      font-family:"YaHei";
      color:#aaa;
    }
    #people>b{
      color:#777;
    }

The most difficult part of CSS processing is the yellow SVG and the yellow SVG mask.

Because we need to ensure that the yellow SVG mask moves from left to right, and the position of the yellow SVG remains unchanged;
The mask is the parent element, and the yellow svg is the child element.
After the parent element is positioned, the child element will move with it when the parent element moves.
If the child element is positioned, but the parent element is not positioned or the parent element is positioned normally, the child element is positioned as fixed.
This will cause the parent element mask to not hide the overflowing part of the child element. I was struggling with this for a long time! ! ! Then I suddenly realized that no matter how fast or far the parent element moves, as long as the child element moves the opposite distance at the same speed,
The child elements can be guaranteed to remain in the same position! ! ! The child elements are static relative to the body! !

move1 is the mask of the parent element, movetwo is the yellow svg graphic, please don't complain about the naming. . . .

How far move1 moves, movetwo moves the opposite distance

 @keyframes move1 {
      0%{
        left:-15px;
      }
      100%{
        left:140px;
      }
    }
    @keyframes movetwo {
      0%{
        left:15px;
      }
      100%{
        left:-140px;
      }
    }

All the code

<!DOCTYPE html>
<html lang="en">

<head>
  <meta charset="UTF-8">
  <meta name="viewport" content="width=device-width, initial-scale=1.0">
  <title>Document</title>
  <style>
    body {
      margin: 0;
      padding: 0;
      background-color: #eee;
    }
    /* Set the white container */
    #con {
      width: 350px;
      height: 85px;
      background-color: #fff;
      position: relative;
      border-radius: 4px;
      margin:50px auto;
    }
    /* Set the text content container */
    #TA-con
      width: 157px;
      height: 50px;
      background-color: #f25d8e;
      box-shadow: 0 4px 4px rgba(255, 112, 159, .3);
      position: absolute;
      top: 50%;
      left: 5%;
      transform: translateY(-50%);
      border-radius: 4px;
      cursor: pointer;
    }
    /* Set the text to center in the container */
    #text-con {
      width: 100px;
      height: 100%;
      margin: 0 auto;
      position: relative;
    }
    /* Make a small lightning */
    #linght {
      width: 0;
      height: 0;
      position: absolute;
      top: 36%;
      left: 4px;
      border-color: transparent;
      border-style: solid;
      border-width: 10px;
      border-top: 10px solid #fff;
      border-radius: 4px;
      transform: rotate(-55deg);
    }
    #linght::after {
      position: absolute;
      top: -13px;
      left: -11px;
      content: "";
      width: 0;
      height: 0;
      border-color: transparent;
      border-style: solid;
      border-width: 10px;
      border-top: 10px solid #fff;
      transform: rotate(180deg);
      border-radius: 4px;
    }
    /* text*/
    #TA {
      float: right;
      line-height: 50px;
      font-size: 15px;
      color: #fff;
    }
    #TA-con:hover {
      background-color: #ff6b9a;
    }

    /* Create a graphics container */
    #tube-con {
      width: 157px;
      height: 55px;
      position: absolute;
      right: -5px;
      top: 15px;
    }
    /* Set the width and height of the svg graphic*/
    svg {
      width: 100%;
      height: 100%;
    }
    /* Create a mask with a width of 0. When I hover the charging box, the width expands*/
    #mask {
      width: 0px;
      height: 100%;
      overflow: hidden;
      position: absolute;
      top: 0;
      left: 0;
      transition:all 0.5s;
    }
    /* Set the width and height of the masked sbg separately to ensure that the width and height have a fixed value instead of a percentage*/
    #mask svg {
      width: 157px;
      height: 55px;
    }
    /* Start the animation when hovering over the charging frame and spread the pink line*/
    #TA-con:hover+#tube-con>#mask{
      width:157px;
    }
    /* Start the animation when the charging frame is hovered, add a yellow fast-moving animation*/
    #TA-con:hover+#tube-con>#orange-mask{
      animation: move1 0.5s linear 0.2s infinite;
    }
    #TA-con:hover+#tube-con>#orange-mask svg{
      animation: movetwo 0.5s linear 0.2s infinite;
    }
    /* Create a yellow moving mask */
    #orange-mask{
      width: 18px;
      height: 100%;
      overflow: hidden;
      position:absolute;
      left:-15px;
      top:0px;
    }
    /* Create yellow moving content */
    #orange-mask svg {
      position: absolute;
      top:0;
      left:15px;
      width: 157px;
      height: 55px;
    }
    @keyframes move1 {
      0%{
        left:-15px;
      }
      100%{
        left:140px;
      }
    }
    @keyframes movetwo {
      0%{
        left:15px;
      }
      100%{
        left:-140px;
      }
    }
    #people{
      position:absolute;
      right:10px;
      top:8px;
      font-size:12px;
      font-family:"YaHei";
      color:#aaa;
    }
    #people>b{
      color:#777;
    }
  </style>
</head>

<body>
  <div id="con">
    <div id="TA-con">
      <div id="text-con">
        <div id="linght"></div>
        <div id="TA">Charge TA</div>
      </div>
    </div>
    <div id="tube-con">
      <svg viewBox="0 0 1028 385" fill="none" xmlns="http://www.w3.org/2000/svg">
        <path d="M1 77H234.226L307.006 24H790" stroke="#e5e9ef" stroke-width="20" />
        <path d="M0 140H233.035L329.72 71H1028" stroke="#e5e9ef" stroke-width="20" />
        <path d="M1 255H234.226L307.006 307H790" stroke="#e5e9ef" stroke-width="20" />
        <path d="M0 305H233.035L329.72 375H1028" stroke="#e5e9ef" stroke-width="20" />
        <rect y="186" width="236" height="24" fill="#e5e9ef" />
        <ellipse cx="790" cy="25.5" rx="25" ry="25.5" fill="#e5e9ef" />
        <circle r="14" transform="matrix(1 0 0 -1 790 25)" fill="white" />
        <ellipse cx="790" cy="307.5" rx="25" ry="25.5" fill="#e5e9ef" />
        <circle r="14" transform="matrix(1 0 0 -1 790 308)" fill="white" />
      </svg>
      <div id="mask">
        <svg viewBox="0 0 1028 385" fill="none" xmlns="http://www.w3.org/2000/svg">
          <path d="M1 77H234.226L307.006 24H790" stroke="#f25d8e" stroke-width="20" />
          <path d="M0 140H233.035L329.72 71H1028" stroke="#f25d8e" stroke-width="20" />
          <path d="M1 255H234.226L307.006 307H790" stroke="#f25d8e" stroke-width="20" />
          <path d="M0 305H233.035L329.72 375H1028" stroke="#f25d8e" stroke-width="20" />
          <rect y="186" width="236" height="24" fill="#f25d8e" />
          <ellipse cx="790" cy="25.5" rx="25" ry="25.5" fill="#f25d8e" />
          <circle r="14" transform="matrix(1 0 0 -1 790 25)" fill="white" />
          <ellipse cx="790" cy="307.5" rx="25" ry="25.5" fill="#f25d8e" />
          <circle r="14" transform="matrix(1 0 0 -1 790 308)" fill="white" />
        </svg>
      </div>
      <div id="orange-mask" >
        <svg viewBox="0 0 1028 385" fill="none" xmlns="http://www.w3.org/2000/svg">
          <path d="M1 77H234.226L307.006 24H790" stroke="#ffd52b" stroke-width="20" />
          <path d="M0 140H233.035L329.72 71H1028" stroke="#ffd52b" stroke-width="20" />
          <path d="M1 255H234.226L307.006 307H790" stroke="#ffd52b" stroke-width="20" />
          <path d="M0 305H233.035L329.72 375H1028" stroke="#ffd52b" stroke-width="20" />
          <rect y="186" width="236" height="24" fill="#ffd52b" />
          <ellipse cx="790" cy="25.5" rx="25" ry="25.5" fill="#ffd52b" />
          <circle r="14" transform="matrix(1 0 0 -1 790 25)" fill="white" />
          <ellipse cx="790" cy="307.5" rx="25" ry="25.5" fill="#ffd52b" />
          <circle r="14" transform="matrix(1 0 0 -1 790 308)" fill="white" />
        </svg>
      </div>
      <p id="people">Total <b>0</b> people</p>
    </div>
  </div>
</body>

</html>

This concludes this article about the sample code for using CSS+SVG to achieve the B-station charging effect. For more relevant CSS B-station charging content, please search 123WORDPRESS.COM's previous articles or continue to browse the following related articles. I hope everyone will support 123WORDPRESS.COM in the future!

<<:  Getting Started with Nginx Reverse Proxy

>>:  How to implement line breaks in textarea text input area

Recommend

JS canvas realizes the functions of drawing board and signature board

This article shares the specific code of JS canva...

Installation process of MySQL5.7.22 on Mac

1. Use the installation package to install MySQL ...

Building a Redis cluster on Docker

Table of contents 1. Pull the image 2. Create a R...

HTML meta viewport attribute detailed description

What is a Viewport Mobile browsers place web pages...

Detailed explanation of the difference between adaptive and responsive analysis in vernacular

Based on daily development experience and relevan...

Implementation of nginx flow control and access control

nginx traffic control Rate-limiting is a very use...

Detailed explanation of how to monitor MySQL statements

Quick Reading Why do we need to monitor SQL state...

Detailed explanation of Vue Notepad example

This article example shares the specific code of ...

Vue uses rules to implement form field validation

There are many ways to write and validate form fi...

MySQL query optimization: causes and solutions for slow queries

Friends who are doing development, especially tho...

Nginx Layer 4 Load Balancing Configuration Guide

1. Introduction to Layer 4 Load Balancing What is...

Vue sample code for easily implementing virtual scrolling

Table of contents Preface Rolling principle accom...

A complete guide to clearing floats in CSS (summary)

1. Parent div defines pseudo-classes: after and z...

Pricing table implemented with CSS3

Result: Implementation Code html <div id="...

HTML 5 Reset Stylesheet

This CSS reset is modified based on Eric Meyers...
