Detailed analysis of compiling and installing vsFTP 3.0.3

Vulnerability Details

VSFTP is a set of FTP server software used on Unix-like systems released based on GPL. The software supports virtual users, two authentication methods (PAP or xinetd/tcp_wrappers), bandwidth limitation, etc.

A security vulnerability exists in VSFTP because the program does not properly handle the 'deny_file' option. A remote attacker could exploit this vulnerability to bypass access restrictions.

The following products and versions are affected: VSFTP 3.0.2 and earlier versions, OpenSUSE 13.1 and 13.2 versions.

Affected Products

Vsftpd Vsftpd 3.0.2

• There are generally three ways to log in to FTP:
• Anonymous user mode: In the default installation, the system only provides anonymous user access. You only need to enter the user anonymous/ftp and use your email as the password to log in.
• Local user mode: The user name in /etc/passwd is used as the authentication method.
• Virtual user mode: supports saving user names and passwords in files or databases, and mapping logged-in users to specified system accounts (/sbin/nologin) to access resources. These virtual users are FTP users.
• Experimental environment: CentOS 7.5 192.168.2.3
• Firewalld, iptables and SElinux are all disabled
• The following experiment uses a virtual user based on PAM. You need to use yum to install the PAM components first:
• Need to use epel source
• yum -y install epel-release && yum -y install pam pam-devel db4-utils
• In the default configuration, vsftpd needs to use the nobody user.
• Download from the official website https://www.linuxfromscratch.org/blfs/view/svn/server/vsftpd.html
• wget https://security.appspot.com/downloads/vsftpd-3.0.3.tar.gz
• tar xf vsftpd-3.0.3.tar.gz
• cd vsftpd-3.0.3/

• There is no configure file in the source package of vsftpd, so compile and install it directly
• make clean && make -j 4 && make install
• If an error occurs during compilation
• /usr/bin/ld: cannot find -lcap
• Find the .so file
• find / -name "*libcap.so*"
• /usr/lib64/libcap.so.2.22
• /usr/lib64/libcap.so.2
• ln -sv /usr/lib64/libcap.so.2 /usr/lib64/libcap.so

• Default configuration:
• Default configuration:
• Main program file: /usr/local/sbin/vsftpd
• Main configuration file: /etc/vsfptd.conf
• PAM authentication file: /etc/pam.d/vsftpd
• Anonymous user home directory: /var/ftp
• Download directory for anonymous users: /var/ftp/pub
• There are two main security principles of vsftpd:
• Only virtual users are allowed to log in, and local users and anonymous users are disabled.
• Running with root privileges is not allowed.
• Create a directory to store configuration files
• mkdir /etc/vsftpd
• Copy the new configuration file to the /etc/vsftpd directory

Create users and shared directories and directory permissions

• Create a plain text file for the virtual user password and use the db4-utils component installed earlier to generate a password authentication file:
• vim /etc/vsftpd/access.txt


zhangsan #Username
123456 #password
lisi
123456 usage

• The db4-utils component installed earlier generates the password authentication file:
• db_load -T -t hash -f /etc/vsftpd/access.txt /etc/vsftpd/access.db

• Edit the PAM authentication file for vsftpd:
• vim /etc/pam.d/vsftpd


auth required /lib64/security/pam_userdb.so db=/etc/vsftpd/access
account required /lib64/security/pam_userdb.so db=/etc/vsftpd/access

• Edit the main configuration file /etc/vsftpd/vsftpd.conf
• cp /etc/vsftpd/vsftpd.conf{,.bak}
• vim /etc/vsftpd/vsftpd.conf
• #Disallow anonymous users

anonymous_enable=NO
local_enable=YES
write_enable=YES

#Do not start the lock user list. All users will be locked and not allowed to access the parent directory. They are only allowed to access their home directory. chroot_local_user=YES
chroot_list_enable=NO

#Start log
xferlog_enable=YES
xferlog_std_format=YES
xferlog_file=/etc/vsftpd/vsftpd.log

# Enable virtual user guest_enable=YES
#FTP virtual user corresponding to the system user guest_username = vsftpd
#PAM authentication file /etc/pam.d/vsftpd
pam_service_name=vsftpd

virtual_use_local_privs=YES

Write the vsftpd startup script: /etc/init.d/vsftpd

#!/bin/bash
#
# vsftpd This shell script takes care of starting and stopping
# standalone vsftpd.
#
# chkconfig: -60 50
# description: Vsftpd is a ftp daemon, which is the program
# that answers incoming ftp service requests.
# processname: vsftpd
# config: /etc/vsftpd/vsftpd.conf
# Source function library.
. /etc/rc.d/init.d/functions
# Source networking configuration.
. /etc/sysconfig/network
# Check that networking is up.
[ ${NETWORKING} = "no" ] && exit 0
[ -x /usr/local/sbin/vsftpd ] || exit 0
RETVAL=0
prog="vsftpd"
start() {
        # Start daemons.
        if [ -d /etc/vsftpd ] ; then
                for i in `ls /etc/vsftpd/*.conf`; do
                        site=`basename $i .conf`
                        echo -n $"Starting $prog for $site: "
                        /usr/local/sbin/vsftpd $i &
                        RETVAL=$?
                        [ $RETVAL -eq 0 ] && {
                           touch /var/lock/subsys/$prog
                           success $"$prog $site"
                        }
                        echo
                done
        else
                RETVAL=1
        fi
        return $RETVAL
}
stop() {
        # Stop daemons.
        echo -n $"Shutting down $prog: "
        killproc $prog
        RETVAL=$?
        echo
        [ $RETVAL -eq 0 ] && rm -f /var/lock/subsys/$prog
        return $RETVAL
}
# See how we were called.
case "$1" in
  start)
        start
        ;;
  stop)
        stop
        ;;
  restart|reload)
        stop
        start
        RETVAL=$?
        ;;
  condrestart)
        if [ -f /var/lock/subsys/$prog ]; then
            stop
            start
            RETVAL=$?
        fi
        ;;
  status)
        status $prog
        RETVAL=$?
        ;;
  *)
        echo $"Usage: $0 {start|stop|restart|condrestart|status}"
        exit 1
esac
exit $RETVAL

Add execution permissions

• Modify the file /etc/xinetd.d/vsftpd to start vsftpd without using the xinetd daemon
• sed -in 's/disable.*=.*/disable = yes/g' /etc/xinetd.d/vsftpd
• sed -in 's/disable.*=.*/disable = yes/g' /etc/xinetd.d/vsftpdn

• Start vsftpd
• servicevsftpd start

Login test

• Start the machine and restart the test
• chkconfig vsftpd on
