Pure CSS3 code to implement a running clock

Pure CSS3 code to implement a running clock

Operation effect

Code Implementation

html

<div id="watch">
  <div class="frame-face"></div>
  <ul class="minute-marks">
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
    <li></li><li></li><li></li><li></li><li></li><li></li>
  </ul>
  <div class="digital-wrap">
    <ul class="digit-hours">
      <li>23</li>
      <li>00</li><li>01</li><li>02</li><li>03</li><li>04</li><li>05</li>
      <li>06</li><li>07</li><li>08</li><li>09</li><li>10</li><li>11</li>
      <li>12</li><li>13</li><li>14</li><li>15</li><li>16</li><li>17</li>
      <li>18</li><li>19</li><li>20</li><li>21</li><li>22</li>
    </ul>
    <ul class="digit-minutes">
      <li>10</li><li>11</li>
      <li>12</li><li>13</li><li>14</li><li>15</li><li>16</li><li>17</li>
      <li>18</li><li>19</li><li>20</li><li>21</li><li>22</li><li>23</li>
      <li>24</li><li>25</li><li>26</li><li>27</li><li>28</li><li>29</li>
      <li>30</li><li>31</li><li>32</li><li>33</li><li>34</li><li>35</li>
      <li>36</li><li>37</li><li>38</li><li>39</li><li>40</li><li>41</li>
      <li>42</li><li>43</li><li>44</li><li>45</li><li>46</li><li>47</li>
      <li>48</li><li>49</li><li>50</li><li>51</li><li>52</li><li>53</li>
      <li>54</li><li>55</li><li>56</li><li>57</li><li>58</li><li>59</li>
      <li>00</li><li>01</li><li>02</li><li>03</li><li>04</li><li>05</li>
      <li>06</li><li>07</li><li>08</li><li>09</li>
    </ul>
    <ul class="digit-seconds">
      <li>20</li><li>21</li><li>22</li><li>23</li>
      <li>24</li><li>25</li><li>26</li><li>27</li><li>28</li><li>29</li>
      <li>30</li><li>31</li><li>32</li><li>33</li><li>34</li><li>35</li>
      <li>36</li><li>37</li><li>38</li><li>39</li><li>40</li><li>41</li>
      <li>42</li><li>43</li><li>44</li><li>45</li><li>46</li><li>47</li>
      <li>48</li><li>49</li><li>50</li><li>51</li><li>52</li><li>53</li>
      <li>54</li><li>55</li><li>56</li><li>57</li><li>58</li><li>59</li>
      <li>00</li><li>01</li><li>02</li><li>03</li><li>04</li><li>05</li>
      <li>06</li><li>07</li><li>08</li><li>09</li><li>10</li><li>11</li>
      <li>12</li><li>13</li><li>14</li><li>15</li><li>16</li><li>17</li>
      <li>18</li><li>19</li>
    </ul>
  </div>
  <ul class="digits">
    <li>1</li><li>2</li><li>3</li><li>4</li><li>5</li><li>6</li>
    <li>7</li><li>8</li><li>9</li><li>10</li><li>11</li><li>12</li>
  </ul>
  <div class="hours-hand"></div>
  <div class="minutes-hand"></div>
  <div class="seconds-hand"></div>
</div>

CSS3

body { font-size:62.5%; margin:1em; background:#232425 }
ul { list-style:none; margin:0; padding:0 }
#watch { font-size:1em; position:relative }
#watch .frame-face {
  position:relative;
  width:30em;
  height:30em;
  margin:2em auto;
  border-radius:15em;
  background:-webkit-linear-gradient(top, #f9f9f9,#666);
  background:-moz-linear-gradient(top, #f9f9f9,#666);
  background: linear-gradient(to bottom, #f9f9f9,#666);
  box-shadow:rgba(0,0,0,.8) .5em .5em 4em;
}
#watch .frame-face:before {
  content:'';
  width:29.4em;
  height:29.4em;
  border-radius:14.7em;
  position:absolute;
  top:.3em; left:.3em;
  background:
    -webkit-linear-gradient(135deg, rgba(246,248,249,0) 0%,rgba(229,235,238,1) 50%,rgba(205,212,217,1) 51%,rgba(245,247,249,0) 100%),
    -webkit-radial-gradient(center, ellipse cover, rgba(246,248,249,1) 0%,rgba(229,235,238,1) 65%,rgba(205,212,217,1) 66%,rgba(245,247,249,1) 100%);
  background:
    -moz-linear-gradient(135deg, rgba(246,248,249,0) 0%,rgba(229,235,238,1) 50%,rgba(205,212,217,1) 51%,rgba(245,247,249,0) 100%),
    -moz-radial-gradient(center, ellipse cover, rgba(246,248,249,1) 0%,rgba(229,235,238,1) 65%,rgba(205,212,217,1) 66%,rgba(245,247,249,1) 100%);
  background:
    linear-gradient(135deg, rgba(246,248,249,0) 0%,rgba(229,235,238,1) 50%,rgba(205,212,217,1) 51%,rgba(245,247,249,0) 100%),
    radial-gradient(ellipse at center, rgba(246,248,249,1) 0%,rgba(229,235,238,1) 65%,rgba(205,212,217,1) 66%,rgba(245,247,249,1) 100%);
}
#watch .frame-face:after {
  content:'';
  width:28em;
  height:28em;
  border-radius:14.2em;
  position:absolute;
  top:.9em; left:.9em;
  box-shadow:inset rgba(0,0,0,.2) .2em .2em 1em;
  border:.1em solid rgba(0,0,0,.2);
  background:-webkit-linear-gradient(top, #fff, #ccc);
  background:-moz-linear-gradient(top, #fff, #ccc);
  background: linear-gradient(to bottom, #fff, #ccc);
}
#watch .minute-marks li {
  display:block;
  width:.2em;
  height:.6em;
  background:#929394;
  position:absolute;
  top:50%; left:50%;
  margin:-.4em 0 0 -.1em;
}
#watch .minute-marks li:first-child {transform:rotate(6deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(2) {transform:rotate(12deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(3) {transform:rotate(18deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(4) {transform:rotate(24deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(5) {transform:rotate(36deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(6) {transform:rotate(42deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(7) {transform:rotate(48deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(8) {transform:rotate(54deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(9) {transform:rotate(66deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(10) {transform:rotate(72deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(11) {transform:rotate(78deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(12) {transform:rotate(84deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(13) {transform:rotate(96deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(14) {transform:rotate(102deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(15) {transform:rotate(108deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(16) {transform:rotate(114deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(17) {transform:rotate(126deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(18) {transform:rotate(132deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(19) {transform:rotate(138deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(20) {transform:rotate(144deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(21) {transform:rotate(156deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(22) {transform:rotate(162deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(23) {transform:rotate(168deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(24) {transform:rotate(174deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(25) {transform:rotate(186deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(26) {transform:rotate(192deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(27) {transform:rotate(198deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(28) {transform:rotate(204deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(29) {transform:rotate(216deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(30) {transform:rotate(222deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(31) {transform:rotate(228deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(32) {transform:rotate(234deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(33) {transform:rotate(246deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(34) {transform:rotate(252deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(35) {transform:rotate(258deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(36) {transform:rotate(264deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(37) {transform:rotate(276deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(38) {transform:rotate(282deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(39) {transform:rotate(288deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(40) {transform:rotate(294deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(41) {transform:rotate(306deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(42) {transform:rotate(312deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(43) {transform:rotate(318deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(44) {transform:rotate(324deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(45) {transform:rotate(336deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(46) {transform:rotate(342deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(47) {transform:rotate(348deg) translateY(-12.7em)}
#watch .minute-marks li:nth-child(48) {transform:rotate(354deg) translateY(-12.7em)}
#watch .digits {
  width:30em;
  height:30em;
  border-radius:15em;
  position:absolute;
  top:0; left:50%;
  margin-left:-15em;
}
#watch .digits li {
  font-size:1.6em;
  display:block;
  width:1.6em;
  height:1.6em;
  position:absolute;
  top:50%; left:50%;
  line-height:1.6em;
  text-align:center;
  margin:-.8em 0 0 -.8em;
  font-weight:bold;
}
#watch .digits li:nth-child(1) { transform:translate(3.9em, -6.9em) }
#watch .digits li:nth-child(2) { transform:translate(6.9em, -4em) }
#watch .digits li:nth-child(3) { transform:translate(8em, 0) }
#watch .digits li:nth-child(4) { transform:translate(6.8em, 4em) }
#watch .digits li:nth-child(5) { transform:translate(3.9em, 6.9em) }
#watch .digits li:nth-child(6) { transform:translate(0, 8em) }
#watch .digits li:nth-child(7) { transform:translate(-3.9em, 6.9em) }
#watch .digits li:nth-child(8) { transform:translate(-6.8em, 4em) }
#watch .digits li:nth-child(9) { transform:translate(-8em, 0) }
#watch .digits li:nth-child(10) { transform:translate(-6.9em, -4em) }
#watch .digits li:nth-child(11) { transform:translate(-3.9em, -6.9em) }
#watch .digits li:nth-child(12) { transform:translate(0, -8em) }
#watch .digits:before {
  content:'';
  width:1.6em;
  height:1.6em;
  border-radius:.8em;
  position:absolute;
  top:50%; left:50%;
  margin:-.8em 0 0 -.8em;
  background:#121314;
}
#watch .digits:after {
  content:'';
  width:4em;
  height:4em;
  border-radius:2.2em;
  position:absolute;
  top:50%; left:50%;
  margin:-2.1em 0 0 -2.1em;
  border:.1em solid #c6c6c6;
  background:-webkit-radial-gradient(center, ellipse cover, rgba(200,200,200,0), rgba(190,190,190,1) 90%, rgba(130,130,130,1) 100%);
  background:-moz-radial-gradient(center, ellipse cover, rgba(200,200,200,0), rgba(190,190,190,1) 90%, rgba(130,130,130,1) 100%);
  background:radial-gradient(ellipse at center, rgba(200,200,200,0), rgba(190,190,190,1) 90%, rgba(130,130,130,1) 100%);
}
@keyframes hours { to {transform:rotate(335deg)} }
#watch .hours-hand {
  width:.8em;
  height:7em;
  border-radius:0 0 .9em .9em;
  background:#232425;
  position:absolute;
  bottom:50%; left:50%;
  margin:0 0 -.8em -.4em;
  box-shadow:#232425 0 0 2px;
  transform-origin:0.4em 6.2em;
  transform:rotate(-25deg);
  animation:hours 43200s linear 0s infinite;
}
#watch .hours-hand:before {
  content:'';
  background:inherit;
  width:1.8em;
  height:.8em;
  border-radius:0 0 .8em .8em;
  box-shadow:#232425 0 0 1px;
  position:absolute;
  top:-.7em; left:-.5em;
}
#watch .hours-hand:after {
  content:'';
  width:0; height:0;
  border:.9em solid #232425;
  border-width:0 .9em 2.4em .9em;
  border-left-color:transparent;
  border-right-color:transparent;
  position:absolute;
  top:-3.1em; left:-.5em;
}
@keyframes minutes { to {transform:rotate(422deg)} }
#watch .minutes-hand {
  width:.8em;
  height:12.5em;
  border-radius:.5em;
  background:#343536;
  position:absolute;
  bottom:50%; left:50%;
  margin:0 0 -1.5em -.4em;
  box-shadow:#343536 0 0 2px;
  transform-origin:0.4em 11em;
  transform:rotate(62deg);
  animation:minutes 3600s linear 0s infinite;
}
@keyframes seconds { to {transform:rotate(480deg)} }
#watch .seconds-hand {
  width:.2em;
  height:14em;
  border-radius:.1em .1em 0 0/10em 10em 0 0;
  background:#c00;
  position:absolute;
  bottom:50%; left:50%;
  margin:0 0 -2em -.1em;
  box-shadow:rgba(0,0,0,.8) 0 0 .2em;
  transform-origin:0.1em 12em;
  transform:rotate(120deg);
  animation:seconds 60s steps(60, end) 0s infinite;
}
#watch .seconds-hand:after {
  content:'';
  width:1.4em;
  height:1.4em;
  border-radius:.7em;
  background:inherit;
  position:absolute;
  left:-.65em; bottom:1.35em;
}
#watch .seconds-hand:before {
  content:'';
  width:.8em;
  height:3em;
  border-radius:.2em .2em .4em .4em/.2em .2em 2em 2em;
  box-shadow:rgba(0,0,0,.8) 0 0 .2em;
  background:inherit;
  position:absolute;
  left:-.35em; bottom:-3em;
}
#watch .digital-wrap {
  width:9em;
  height:3em;
  border:.1em solid #222;
  border-radius:.2em;
  position:absolute;
  top:50%; left:50%;
  margin:3em 0 0 -4.5em;
  overflow:hidden;
  background:#4c4c4c;
  background:-webkit-linear-gradient(top, #4c4c4c 0%,#0f0f0f 100%);
  background:-moz-linear-gradient(top, #4c4c4c 0%, #0f0f0f 100%);
  background:-ms-linear-gradient(top, #4c4c4c 0%,#0f0f0f 100%);
  background:-o-linear-gradient(top, #4c4c4c 0%,#0f0f0f 100%);
  background:linear-gradient(to bottom, #4c4c4c 0%,#0f0f0f 100%);
}
#watch .digital-wrap ul {
  float:left;
  width:2.85em;
  height:3em;
  border-right:.1em solid #000;
  color:#ddd;
  font-family:Consolas, monaco, monospace;
}
#watch .digital-wrap ul:last-child { border:none }
#watch .digital-wrap li {
  font-size:1.5em;
  line-height:2;
  letter-spacing:2px;
  text-align:center;
  position:relative;
  left:1px;
}
#watch .digit-minutes li {
  animation:dsm 3600s steps(60, end) 0s infinite;
}
#watch .digit-seconds li {
  animation:dsm 60s steps(60, end) 0s infinite;
}
@keyframes dsm {
  to { transform:translateY(-120em) }
}

The above is the details of the clock implemented in pure CSS3. For more information about CSS3 clock, please pay attention to other related articles on 123WORDPRESS.COM!

<<:  Vue3 slot usage summary

>>:  Install Centos7 using Hyper-v virtual machine

Recommend

Html easily implements rounded rectangle

Question: How to achieve a rounded rectangle usin...

How to completely uninstall Docker Toolbox

Docker Toolbox is a solution for installing Docke...

Several ways to vertically and horizontally center in CSS3 with indefinite height and width

1. Flex layout .father { display: flex; justify-c...

CSS3 realizes particle animation effect when matching kings

When coding, you will find that many things have ...

MySql5.7.21 installation points record notes

The downloaded version is the Zip decompression v...

HTML table border control implementation code

Generally, when we use a table, we always give it...

Create a new user in Linux and grant permissions to the specified directory

1 Create a user and specify the user's root p...

Vue implements the operation code of clicking a button to download a file (backend Java)

In the previous article, I introduced the functio...

How to connect to MySQL database using Node-Red

To connect Node-red to the database (mysql), you ...

Solution to the problem of the entire page not being centered when using margin:0 auto in HTML

I wrote a jsp page today. I tried to adjust <di...

Linux common commands chmod to modify file permissions 777 and 754

The following command is often used: chmod 777 文件...

JS Easy to understand Function and Constructor

Table of contents 1. Overview 1.1 Creating a func...

The easiest way to debug stored procedures in Mysql

A colleague once told me to use a temporary table...

Sample code for implementing two-way authentication with Nginx+SSL

First create a directory cd /etc/nginx mkdir ssl ...

Five ways to implement inheritance in js

Borrowing Constructors The basic idea of ​​this t...
