A brief understanding of the three principles of adding MySQL indexes

//Prepare two test tablesmysql> CREATE TABLE `test_t` (
-> `id` int(11) NOT NULL auto_increment,
-> `num` int(11) NOT NULL default '0',
-> `d_num` varchar(30) NOT NULL default '0',
-> PRIMARY KEY (`id`)
-> ) ENGINE=MyISAM DEFAULT CHARSET=utf8 AUTO_INCREMENT=1 ;
Query OK, 0 rows affected (0.05 sec)
mysql> CREATE TABLE `test_test` (
-> `id` int(11) NOT NULL auto_increment,
-> `num` int(11) NOT NULL default '0',
-> PRIMARY KEY (`id`)
-> ) ENGINE=MyISAM DEFAULT CHARSET=utf8 AUTO_INCREMENT=1 ;
Query OK, 0 rows affected (0.05 sec)
//Create a stored procedure to facilitate data insertionmysql> delimiter |
mysql> create procedure i_test(pa int(11),tab varchar(30))
-> begin
-> declare max_num int(11) default 100000;
-> declare i int default 0;
-> declare rand_num int;
-> declare double_num char;
->
-> if tab != 'test_test' then
-> select count(id) into max_num from test_t;
-> while i < pa do
-> if max_num < 100000 then
-> select cast(rand()*100 as unsigned) into rand_num;
-> select concat(rand_num,rand_num) into double_num;
-> insert into test_t(num,d_num)values(rand_num,double_num);
-> end if;
-> set i = i +1;
-> end while;
-> else
-> select count(id) into max_num from test_test;
-> while i < pa do
-> if max_num < 100000 then
-> select cast(rand()*100 as unsigned) into rand_num;
-> insert into test_test(num)values(rand_num);
-> end if;
-> set i = i +1;
-> end while;
-> end if;
-> end|
Query OK, 0 rows affected (0.00 sec)
mysql> delimiter;
mysql> show variables like "%pro%"; // Check whether profiling is enabled. It is disabled by default. +---------------------------+-------+
| Variable_name | Value |
+---------------------------+-------+
| profiling | OFF |
| profiling_history_size | 15 |
| protocol_version | 10 |
| slave_compressed_protocol | OFF |
+---------------------------+-------+
4 rows in set (0.00 sec)
mysql> set profiling=1; //After turning it on, it is to compare the execution time after adding the index. Query OK, 0 rows affected (0.00 sec)

mysql> call i_test(10,'test_t'); //Insert 10 conditions into the test_t table Query OK, 1 row affected (0.02 sec)
mysql> select num from test_t where num!=0;
mysql> explain select num from test_t where num!=0\G;
*************************** 1. row ***************************
id: 1
select_type: SIMPLE
table: test_t
type: ALL
possible_keys: NULL
key: NULL
key_len: NULL
ref: NULL
rows: 10
Extra: Using where
1 row in set (0.00 sec)
ERROR:
No query specified
mysql> create index num_2 on test_t (num);
Query OK, 10 rows affected (0.19 sec)
Records: 10 Duplicates: 0 Warnings: 0
mysql> select num from test_t where num!=0;
mysql> explain select num from test_t where num!=0\G;
*************************** 1. row ***************************
id: 1
select_type: SIMPLE
table: test_t
type: index
possible_keys: num_2
key: num_2
key_len: 4
ref: NULL
rows: 10
Extra: Using where; Using index
1 row in set (0.00 sec)
ERROR:
No query specified
mysql> show profiles;
+----------+------------+---------------------------------------------+
| Query_ID | Duration | Query |
+----------+------------+---------------------------------------------+
| 1 | 0.00286325 | call i_test(10,'test_t') | //Insert ten records | 2 | 0.00026350 | select num from test_t where num!=0 |
| 3 | 0.00022250 | explain select num from test_t where num!=0 |
| 4 | 0.18385400 | create index num_2 on test_t (num) | //Create index| 5 | 0.00127525 | select num from test_t where num!=0 | //After using the index, it is almost 0.2 times that of not using the index| 6 | 0.00024375 | explain select num from test_t where num!=0 |
+----------+------------+---------------------------------------------+
6 rows in set (0.00 sec)

mysql> call i_test(10,'test_test'); //Insert 10 records into the test_test table Query OK, 1 row affected (0.02 sec)
mysql> explain select a.num as num1,b.num as num2 from test_t as a left join tes
t_test as b on a.num=b.num\G;
*************************** 1. row ***************************
id: 1
select_type: SIMPLE
table: a
type: index
possible_keys: NULL
key: num_2
key_len: 4
ref: NULL
rows: 10
Extra: Using index
*************************** 2. row ***************************
id: 1
select_type: SIMPLE
table: b
type: ref
possible_keys: num_1
key: num_1
key_len: 4
ref: bak_test.a.num //bak_test is the database name, a.num is a field of test_t rows: 1080
Extra: Using index
2 rows in set (0.01 sec)
ERROR:
No query specified
