Tutorial on installing MySQL database and using Navicat for MySQL

MySQL is a relational database management system developed by the Swedish company MySQL AB and currently owned by Oracle.

MySQL is the most popular relational database management system. In terms of WEB applications, MySQL is one of the best RDBMS (Relational Database Management System) application software.

It has the characteristics of small size, high speed, low cost and open source code.

MySQL download address: http://dev.mysql.com/downloads/installer/

Double-click to enter the installation guide interface, click Next, check that you have read the relevant information, and click Next

Then you will enter the type selection interface, where there are 3 types: Typical, Complete, and Custom.

Here we recommend choosing "Custom" installation, so that you can customize the MySQL installation directory, and then click "Next" to display the custom installation interface.

For the sake of data security, it is not recommended to install MySQL in the C directory of the system disk.

Click Next to start the installation.

After the installation is complete, the MySQL configuration guide interface will appear. Click Next

There is an option to guide the configuration of MySQL (Luanch the MySQL Instance Configuration Wizard). It is recommended to check the option to configure your MySQL immediately.

Click Next to configure MySQL.

You can choose two configuration types: Detailed Configuration and Standard Configuration. Select Detailed Configuration and click Next.

Configure MySQL MySQL server type

There are 3 server types to choose from

Developer Machine : This option represents a typical personal desktop workstation. Assume that there are multiple desktop applications running on the machine. Configure the MySQL server to use the fewest system resources.

Server Machine : This option represents the server. The MySQL server can run along with other applications, such as FTP, email, and web servers. The MySQL server is configured to use an appropriate proportion of system resources.

Dedicated MySQL Server Machine : This option represents a server that only runs the MySQL service. Assume that no other applications are running. The MySQL server is configured to use all available system resources.

Here I chose Developer Machine, mainly for daily development needs.

Next, select the database purpose

Multifunctional Database : If you select this option, you will use both InnoDB and MyISAM storage engines and distribute resources evenly between the two engines. This option is recommended for users who frequently use two storage engines.

Transactional Database Only : This option uses both InnoDB and MyISAM storage engines, but assigns most server resources to the InnoDB storage engine. This option is recommended for users who mainly use InnoDB and only occasionally use MyISAM.

Non-Transactional Database Only : This option completely disables the InnoDB storage engine and assigns all server resources to the MyISAM storage engine. It is recommended that users who do not use InnoDB select this option.

I chose Multifunctional Database.

The following is the default location for data storage.

Select the maximum number of connections allowed by MySQL. The first one is a maximum of 20 concurrent connections, the second one is a maximum of 500 concurrent connections, and the last one is custom. You can choose according to your needs

The following is to select the port that the database monitors. The default is 3306. If you change it to another port, you must remember the modified port when you connect to the database in the future. Otherwise, you will not be able to connect to the MySQL database, which is troublesome. No changes will be made here.

Use the default port of MySQL: 3306.

Configure the MySQL character set and click Next

Configure MySQL service options to install the MySQL server as a service. Install it as a service, and you can automatically start the MySQL server when the system starts

Configuring MySQL security options

Set and remember the super user password. New root password (enter password) Confirm (confirm password) is recommended.

There is a checkbox below to select whether to allow remote machines to connect to your MySQL server as root user. If you have this requirement, please check it.

Click Execute to complete the installation and open a command line window

Enter the password and press Enter

Database Information

Press Enter and you will see the database information. You can operate the database here, including adding, modifying and checking. I will not go into details.

Next, desktop tools can be used to operate the database without writing code.

Client tool: Navicat for MySQL

Green version download address: http://www.cr173.com/soft/38153.html

Official website download address: https://www.navicat.com

After registration is completed, open the interface, click Connect, and enter relevant information.

Connection successful, OK

In this way, you can operate the database manually, import SQL files for execution, or write code. It is very convenient.

Summarize

The above is the tutorial on MySQL database installation and Navicat for MySQL usage introduced by the editor. I hope it will be helpful to everyone. If you have any questions, please leave me a message and the editor will reply to you in time!
