JS implements a simple brick-breaking pinball game

This article shares the specific code of JS to implement the brick-breaking pinball game for your reference. The specific content is as follows

Written in native JS, there are still some flaws. The code can be used directly by copying it into HTML

The speed is random because it involves horizontal and vertical speeds, so the speed value of the ball displayed is their sum (cube and square root).
Press Enter or left-click on the slider to start the game. Use the mouse to slide or keyboard A (left) or D (right) to control the direction of the slider to catch the ball.
The purpose of this small demo is mainly to exercise logical ability:

<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8">
<title>document</title>
<style>
.container{
    width: 500px;
    height: 500px;
    border:1px solid #000;
    margin:auto;
    position:relative;
}
.brickBox{
    width: 500px;
    height: 300px;
    /* background-color: yellowgreen; */
    position:absolute;
    left: 0;
    top: 0;
}
.ball{
    width: 15px;
    height: 15px;
    background-color:purple;
    border-radius:50%;
    position:absolute;
    bottom:30px;
    left:235px;
    /* margin-left:-15px; */
}
.slider{
    width: 150px;
    height: 30px;
    background-color: #00f;
    position:absolute;
    /* left:50%; */
    left:175px;
    /* margin-left:-75px; */
    bottom:0;
}
</style>
</head>
<body>
<div class="container">
    <div class="brickBox"></div>
    <div class="ball"></div>
    <div class="slider"></div>
</div>
<div style="margin-left: 40%;font-size: 25px;">Current speed: <span id="speed"></span> </div>
<div style="margin-left: 40% ;font-size: 25px;">Current number of blocks destroyed: <span id="count"></span> </div>

</body>
<script>
// Get all current tags var container = document.querySelector('.container')
var brickBox = container.querySelector('.brickBox')
var ball = container.querySelector('.ball')
var slider = container.querySelector('.slider')
// Dynamically create bricks // Define brick size var brickWidth = 50;
var brickHeight = 15;
// Calculate the number of bricks var brickNum = brickBox.clientWidth * brickBox.clientHeight / (brickWidth * brickHeight)
// console.log(brickNum);
var brickColNum = brickBox.clientWidth / brickWidth
// Create according to quantity for(var i=0;i<brickNum;i++){
    var div = document.createElement('div')
    setStyle(div,{
        width:brickWidth + "px",
        height:brickHeight + "px",
        backgroundColor:getColor(true),
        position:'absolute',
        top:parseInt(i/brickColNum)*brickHeight + 'px',
        left:(i%brickColNum)*brickWidth + 'px'
    })
    brickBox.appendChild(div)
}


// Click the slider to make the ball start moving // Define the horizontal and vertical movement values var speedX = getRandom(1,8);
var speedY = getRandom(1,8);
document.querySelector("#speed").innerHTML = Math.sqrt(Math.pow(speedX,2)+Math.pow(speedY,2))
var timer;
//Click to move slider.onclick = move;
//Enter key starts the pop-up function move(){
    var count=0;
    clearInterval(timer)
    timer = setInterval(function(){
        // Start moving // Get the left and top of the ball
        let left = ball.offsetLeft;
        let top = ball.offsetTop;

        // Let left and top increase speed // The ball collides with the slider if (boom (slider, ball)) {
            speedY = -speedY
        }
        // The small ball collides with the big box if(left<=0 || left>=container.clientWidth - ball.offsetWidth){
            speedX = -speedX
        }
        if(top<=0){
            speedY = -speedY
        }
        // Check if all bricks and balls collide for(let i=0;i<brickBox.children.length;i++){
            if(boom(brickBox.children[i],ball)){

                speedY = -speedY
                brickBox.removeChild(brickBox.children[i]);
                count++;
            }


        }
        console.log(count)
        document.querySelector("#count").innerHTML=count
        // GAME OVER
        if(top>=container.clientHeight-ball.offsetHeight){
            clearInterval(timer)
            if(confirm("GAME OVER, whether to play again")){
   location.reload();
  }else{alert('your final score'+count)}
        }
        left += speedX
        top += speedY
        // Set the left and top of the ball
        ball.style.left = left + "px"
        ball.style.top = top + "px"
    },20)
}

// Let the slider follow the mouse movement slider.onmouseover = function(){
    document.onmousemove = function(e){
        var e = e || window.event;
        var x = e.pageX;
        var l = x - container.offsetLeft - 1 - slider.offsetWidth / 2
        if(l<0){
            l = 0
        }
        if (l > container.clientWidth - slider.offsetWidth) {
            l = container.clientWidth - slider.offsetWidth
        }
        slider.style.left = l + "px"
    }
}
//Let the slider move with the left and right keyboards window.onload = function(){
    document.onkeydown = e=>{
        var e = e || window.event;
        var keycode = e.keyCode || e.which;
        var keyword = String.fromCharCode(keycode).toLowerCase();
        if(keycode==13){
            move();
        }
       if(keyword=='a'){
           console.log("1111")
        slider.style.left = slider.offsetLeft-15+"px"
       }else if(keyword=='d'){
        console.log("222")
           slider.style.left=slider.offsetLeft+15+"px"
       }
       console.log(slider.offsetLeft)


    }

}
// Encapsulate the collision detection function function boom(node1,node2){
    // There are only 4 possibilities for not colliding if(node1.offsetLeft+node1.offsetWidth<node2.offsetLeft || node1.offsetTop+node1.offsetHeight<node2.offsetTop || node2.offsetLeft+node2.offsetWidth<node1.offsetLeft || node2.offsetTop+node2.offsetHeight<node1.offsetTop){
        return false;
    }else{
        return true;
    }
}
// Encapsulate the function of getting random color function getColor(hex=true){
    if(hex){
        var color = '#'
        for(var i=0;i<3;i++){
            var rgb = getRandom(256).toString(16);
            rgb = rgb.length===1?'0'+rgb:rgb;
            color += rgb
        }
        return color;
    }
    return `rgb(${getRandom(256)},${getRandom(256)},${getRandom(256)})`
}
// Encapsulate the function of setting style function setStyle(ele,styleObj){
    for(var attr in styleObj){
            ele.style[attr] = styleObj[attr]
    }
}
// Encapsulate the function of getting random numbers function getRandom(a,b=0){
    var max = Math.max(a,b);
    var min = Math.min(a,b)
    return Math.floor(Math.random() * (max-min)) + min
}
</script>
</html>

The effect diagram is shown in the figure

The style is a little ugly without the plug-in.
Then there is a bug that the left and right arrow keys do not have an end value set. Occasionally there will be a loss of positional precision causing the ball to twitch on the slider.
