How to build svn server in linux

1: Install SVN

yum install -y subversion

2. Create a warehouse

1: Create a warehouse directory

mkdir -p /var/project/test

2: Create a warehouse

svnadmin create /var/project/test

After successful creation, the following directories are created under the /var/project/test directory:

drwxr-xr-x. 2 root root 51 January 30 13:26 conf
drwxr-sr-x. 6 root root 4096 January 30 13:26 db
-r--r--r--. 1 root root 2 January 30 13:26 format
drwxr-xr-x. 2 root root 4096 January 30 13:26 hooks
drwxr-xr-x. 2 root root 39 January 30 13:26 locks
-rw-r--r--. 1 root root 229 January 30 13:26 README.txt

The conf directory is the svn configuration directory, which includes:

-rw-r--r--. 1 root root 1080 January 30 13:26 authz #Permission control -rw-r--r--. 1 root root 309 January 30 13:26 passwd #Password management -rw-r--r--. 1 root root 3090 January 30 13:26 svnserve.conf #SVN service process configuration

Three: SVN configuration

1: Permission configuration (/var/project/test/conf/authz)

#User grouping (admin->administrator, development->developerother->other)
[groups]
admin = test1 #Administrator user test1
development = test2,test3 #Development users test2, test3
other = test4,test5,test6 #other users test4,,test5,test6
#Permission configuration[/]
@admin = rw #Administrator read and write permissions @development = rw #Development read and write permissions @other = r #Other read permissions test7 = rw #test7 user read and write permissions

2: Password configuration (/var/project/test/conf/passwd)

#Password configuration, the format is username=password, the password is plain text [users]
test1 = test1
test2 = test2
test3 = test3
test4 = test4
test5 = test5
test6 = test6
test7 = test7

3: SVN service process configuration (/var/project/test/conf/svnserve.conf)

[general]
anon-access = none #Anonymous users have no access auth-access = write #Authenticated users can read and write password-db = passwd #Specify user authentication password file authz-db = authz #Specify permission configuration file

4: Start the SVN service (default port number 3690)

Start SVN by specifying the port

svnserve -d -r /var/project --listen-port 3691

5. Close the firewall or open the specified port number

1: Turn off the firewall

systemctl stop firewalld

2: Open the specified firewall

#Open port 3690 firewall-cmd --zone=public --add-port=3690/tcp --permanent
#Refresh configuration firewall-cmd --reload

6: Client connects and uploads files

Connecting SVN on Windows

1: Create a new directory, right-click and select svn checkout

2: Fill in the Linux SVN address svn://ip:3690/warehouse name on the version library (the warehouse name here is not /var/project/test but /test)

2: Fill in the username and password

At this time, we can see that a .svn file is generated in this directory, indicating that we have connected to the svn server on Linux.

3: Upload files

Now let's create a new test.txt file and fill in some information

(1) Right-click and select add

Then select the test.txt file and click OK. At this time, we will see a plus sign on the test.txt file.

(2): Upload

Right click and select Submit

Fill in the remarks, select the file to upload and click OK

At this time, we can see that the plus sign on the test.txt file will turn into a green check mark, indicating that the upload is successful.

But at this time we found that we did not find the files we uploaded in the /var/project/test directory. Why is this? Didn't we upload successfully?
This is because after uploading the file to the SVN repository, the uploaded file is no longer stored in the original format of the file, but is compressed into repository data in a custom format by SVN and stored in the repository. The SVN server repository has two formats, one is FSFS and the other is BDB.
At this time we need to implement the checkout in Linux

4: Check out

svn checkout svn://192.168.11.201/test /data/test #svn://192.168.11.201/test indicates the warehouse address to be checked out /data/test indicates the directory to which the data needs to be checked out

This is because we can see the files we uploaded on the client before in the /data/test directory, but now the problem comes again. After we upload the files on the client, it is impossible to check them out on the server every time, so how can we check them out automatically?

5: Automatically check out configuration

Create a post-commit file in the /var/project/test/hooks directory and add the following content to the post-commit file:

#!/bin/sh
REPOS="$1" #Warehouse REV="$2" #Version number export.UTF-8 #Encoding SVN=/usr/bin/svn #svn address WEB=/data/test #Project directory to be updated $SVN update $WEB --username test1 --password test1 #--username test1 means setting the username --password test1 means setting the password

Set post-commit to be executable

chmod +x /var/project/test/hooks/post-commit

The automatic checkout configuration is now complete, but please note that you need to manually check out the first time, and you don't need to do it later. This completes the svn server setup on Linux
