Jenkins+tomcat automatic hot deployment/restart and solutions to problems encountered (recommended)

1. Background

The company's projects have always been manually packaged with Maven, uploaded to the server, and closed/opened Tomcat. The whole process is time-consuming and labor-intensive. Although all processes can be solved at one time through shell scripts, it would be more time-saving and labor-saving if the Jenkins plug-in of idea could be used for automatic deployment with one click.

The following is a simple shell script for publishing tomcat. The prerequisite for executing the following script is to install git and maven on the server.

# First shut down the tomcat process kill -9 `ps aux|grep tomcat|grep -v 'grep'| awk 'NR==1{print $2}'`
# Switch to the project storage location cd nxyyProjectSource/NXYY
# git pull the latest code git pull xxxx
# Switch to the code storage location under the project cd nxyy
# Maven packaging mvn clean
mvn install -DskipTests
# Put the war package into tomcat cd
cp nxyyProjectSource/NXYY/nxyy/target/nxyy.war /home/tomcat/webapps
# Start tomcat
cd /home/tomcat/bin
./startup.sh
# View the log tail -f ../logs/catalina.out

Each time you pull a git, you will need a password. After the following configuration, you only need to enter the password for the first time and it will be permanently saved to the server. You will not need to enter the password the next time you copy/pull a git:

git config --global credential.helper store

If you want to clear your account and password, enter:

git config --global credential.helper reset

If you want temporary storage (default 15 minutes), enter:

git config --global credential.helper cache

To exempt a project from password, add username:password to the https link.

git remote add origin https://username:[email protected]

The above configurations are saved in .git/config .

2. Jenkins installation/configuration/hot deployment/script tomcat restart

Download the installation package jenkins.war; in the root path of the installation package, run the command java -jar jenkins.war --httpPort=8080（linux環境、Windows環境都一樣），運行后有一個密碼，需要登錄時使用：

Open the browser and go to the link http://ip:8080, enter the plug-in installation selection. It is recommended to select the recommended plug-ins to ensure that the basic commonly used functions can be used; after selecting, enter the plug-in installation page. If some plug-ins fail to install, you can click to install again:

Set the initial user and password for next login:

Enter the system and the installation is complete:

Note: If you still cannot enter the system, you need to wait for a while or refresh the page. If you still cannot enter, you need to restart the Jenkins server. Just add restart after the startup homepage URL [Restart: http://ip:8080/restart ]; If you enter the default password and keep getting stuck:

In the $JENKINS_HOME/hudson.model.UpdateCenter.xml file, the default content is as follows:

<?xml version='1.0' encoding='UTF-8'?>
 <sites>
 <site>
 <id>default</id>
 <url>http://updates.jenkins-ci.org/update-center.json</url>
 </site>
</sites>

This address is on a foreign server. Because of the firewall, the plug-in required for the initialization interface cannot be downloaded, so it has been in a waiting state. Changing the URL to http://mirror.xmission.com/jenkins/updates/update-center.json就解決了the system configuration and sets the access path of Jenkins. Of course, this path will appear after creating a username:

Set the plugin installation source: Plugin Management -> Advanced, http://mirror.xmission.com/jenkins/updates/current/update-center.json

Perform global tool configuration for system management, including Maven, JDK, and Git configuration:

After configuration, build the project and select New Task:

Before configuring the project information, you need some credentials, such as the username and password of git and the username and password of tomcat user: System Management -> Manage Credentials

The tomcat username and password are required so that Jenkins can remotely publish tomcat. They are configured in tomcat-users.xml under tomcat's conf: tomcat remote publishing requires modifying tomcat-users.xml, context.xml (the pitfall encountered in the following construction, point 5), and manager.xml (the pitfall encountered in the following construction, point 6).

<tomcat-users xmlns="http://tomcat.apache.org/xml"

    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"

    xsi:schemaLocation="http://tomcat.apache.org/xml tomcat-users.xsd"

    version="1.0">

 <role rolename="manager-gui"/>
 <role rolename="manager-script"/>
 <role rolename="manager-jmx"/>
 <role rolename="manager-status"/>
 <role rolename="admin-gui"/>
 <user username="username" password="password" roles="manager-gui,manager-script,manager-jmx,manager-status,admin-gui"/>
</tomcat-users>

Configure the project information and build it after configuration. Tomcat must be started in the server:

The above is Tomcat hot deployment. The following is Tomcat restart execution project: first install the plug-in Publish Over SSH, and configure the information: System Management -> Information Configuration -> Publish over SSH

Before building the configuration, you need to create a script to restart Tomcat: vi tomcat.sh, and then grant execution permissions chmod 777 tomcat.sh

#The JAVA_HOME configuration needs to be added here. Although it has been configured in the local environment variables, it still needs to be configured when calling remotely, otherwise the script execution will fail.
export JAVA_HOME=/usr/java/jdk1.8.0_141-cloudera
# Location of tomcat
tomcat_home=/home/tomcat-dev
#【3.1】 Stop tomcat variables
SHUTDOWN=$tomcat_home/bin/shutdown.sh
#【3.2】 Start tomcat variables
STARTTOMCAT=$tomcat_home/bin/startup.sh
#【3.3】 Delete all project files including war package and war decompressed files. If it is a partial release, this sentence is not needed. This is just for Jenkins to publish the entire war.
rm -rf /home/tomcat-dev/webapps/TSISAPP*

#Get the process ID. This can also be abbreviated. If you can get the PID by using ps -ef|grep the project name, you can write it directly like this:
#Why was it written so long before? Because when Jenkins calls the script, it will also bring out the process of Jenkins calling the script. So kill -9 will kill the Jenkins process and cause the first construction release to be interrupted.
#So here we have been writing to the conf folder directory
#If you don't need to use Jenkins, you can use the following concise version to get the PID command
#PID=`ps -ef |grep project name |grep -v grep | awk '{print $2}'`
#【3.4】 Get the process ID
PID=`ps -ef |grep /home/tomcat-dev/conf |grep -v grep | awk '{print $2}'`
if [ ! "$PID" ];then # Here we determine whether the TOMCAT process exists
echo "process does not exist"
else
echo "The process exists and kills the process PID: $PID"
kill -9 $PID
fi

#【3.5】Start the project
$STARTTOMCAT
echo "Start Project"

Build: Select Send files or execute commands over SSH in Post Steps. The following post-build operation -> Deploy war/ear to a container is no longer needed:

3. Pitfalls encountered in construction

If you don't have a Maven project built, install it by searching for the plugin: Maven Integration plugin

If there is no Deploy war/ear to a container after building, search in the plugin and install it: Deploy to container Plugin

The following error occurs:

[ERROR] No goals have been specified for this build. You must specify a valid lifecycle phase or a goal in the format <plugin-prefix>:<goal> or <plugin-group-id>:<plugin-artifact-id>[:<plugin-version>]:<goal>. Available lifecycle phases are: validate, initialize, generate-sources, process-sources, generate-resources, process-resources, compile, process-classes, generate-test-sources, process-test-sources, generate-test-resources, process-test-resources, test-compile, process-test-classes, test, prepare-package, package, pre-integration-test, integration-test, post-integration-test, verify, install, deploy, pre-clean, clean, post-clean, pre-site, site, post-site, site-deploy. -> [Help 1]

Solution: Add <defaultGoal>install</defaultGoal> to the <build> tag in pom.xml

The following error occurs: org.codehaus.cargo.container.ContainerException: Failed to deploy or org.codehaus.cargo.container.ContainerException: The [cargo.remote.username] and [cargo.remote.password] properties are mandatory and need to be defined in your configuration

Solution: Add in <plugins> in the <build> tag of pom.xml

<plugin>
    <groupId>org.codehaus.cargo</groupId>
    <artifactId>cargo-maven2-plugin</artifactId>
    <version>1.4.9</version>
    <configuration>
     <container>
      <!-- Container version name -->
      <containerId>Tomcat 9.x</containerId>
      <type>remote</type>
     </container>
     <configuration>
      <type>runtime</type>
      <properties>
       <!-- tomcat management interface -->
       <cargo.remote.uri>http://ip:8888/manager/text</cargo.remote.uri>
       <!-- Tomcat management interface username and password -->
       <cargo.remote.username>Username</cargo.remote.username>
       <cargo.remote.password>password</cargo.remote.password>
      </properties>
     </configuration>
    </configuration>
   </plugin>

The following problem occurs: Caused by: org.codehaus.cargo.container.tomcat.internal.TomcatManagerException: The username you provided is not allowed to use the text-based Tomcat Manager
Solution: Go to tomcat's /webapps/manager/META_INF/context.xml file and comment out the restricted source settings in the file.

<Context antiResourceLocking="false" privileged="true" >
<!--
 <Valve className="org.apache.catalina.valves.RemoteAddrValve"
   allow="127\.\d+\.\d+\.\d+|::1|0:0:0:0:0:0:0:1" />
--> //Comment it out <Manager sessionAttributeValueClassNameFilter="java\.lang\.(?:Boolean|Integer|Long|Number|String)|org\.apache\.catalina\.filters\.CsrfPreventionFilter\$LruCache(?:\$1)?|java\.util\.(?:Linked)?HashMap"/>
</Context>

Tomcat remote connection appears 403 rejection, add manager.xml under conf/Catalina/localhost

<?xml version="1.0" encoding="UTF-8"?>
<Context privileged="true" antiResourceLocking="false"
   docBase="${catalina.home}/webapps/manager">
    <Valve className="org.apache.catalina.valves.RemoteAddrValve" allow="^.*$" />
</Context>

Idea is combined with the Jenkins plug-in for remote publishing. When Crumb Data is obtained and filled in through http://ip:8080/crumbIssuer/api/xml?tree=crumb#, CSRF enabled -> Missing or bad crumb data appears

By searching for solutions online, most of them say to enable CSRF service.

But the problem still cannot be solved. The solution is: click username -> Settings -> API Token -> Current Token, generate a token by token name, replace the username and password above, and finally succeeded
