Vue+elementUI component recursively implements foldable dynamic rendering multi-level sidebar navigation

Vue+elementUI component recursively implements foldable dynamic rendering multi-level sidebar navigation

The function has been implemented a long time ago, but I found that when I clicked it, the background color of the selected menu item would turn white. I carefully observed it on Friday and found that it was not a problem of adjusting the style, but that the option was not selected. So I studied the component recursion carefully and summarized and recorded my thoughts.

1. Concept

Recursion: To put it simply, recursion is to call itself, just like nesting dolls. When I was a child, I played a game called Tower of Hanoi, which used the recursive principle:

insert image description here

Function recursion: The function uses the function name to call its own component recursion: Therefore, component recursion is implemented by using the name attribute in the vue component

2. Demand

Implement foldable dynamic rendering of multi-level sidebar navigation

Analysis

insert image description here

1. Observe that the sidebar navigation is one level at a time, and the second level is equivalent to repeating the first level. 2. There is a feature that some menus have lower levels, while some do not. 3. Dynamic rendering means that the tree type data is obtained from the background interface and dynamically rendered. 4. Code implementation 1. First, execute the demo in the document to try it out:

Documentation: element documentation

2. Change it to the style you need. This is how it was written for the first time.

Parent component SideBar

<template>
  <el-menu class="menu-wrap" :default-active="menuActiveName || 'home'" :active="menuActiveName || 'home'"
           :collapse="sidebarFold" :collapseTransition="false" :unique-opened="true" @select="selectItem">
    <template>
      <el-menu-item @click="sidebarFold = !sidebarFold">
        <i v-show="!sidebarFold" class="el-icon-s-fold"></i>
        <i v-show="sidebarFold" class="el-icon-s-unfold"></i>
        <span slot="title" class="sidebar-one">Navigation List</span>
      </el-menu-item>
    </template>
<!-- <side-bar-item :list="menuList"></side-bar-item>-->
    <template v-for="(item,index) in menuList" class="menu">
      <!-- Title -->
      <template v-if="item.children.length" >
        <el-submenu :key="index" :index="item.id" class="sub-menu-item">
          <template :index="item.index" slot="title">
            <!-- <i :class="item.icon"></i>-->
            <i class="iconfont icon-danganjianying"></i>
            <span>{{item.name}}</span>
          </template>
          <el-menu-item-group class="menu-item-group">
            <side-bar-item :list="item.children"></side-bar-item>
          </el-menu-item-group>
        </el-submenu>
      </template>
      <!-- Options -->
      <template v-else>
        <el-menu-item :key="index" :index="item.id" class="menu-item">
          <!-- <i :class="item.icon"></i>-->
          <i class="iconfont icon-danganjianying"></i>
          <span>{{item.name}}</span>
        </el-menu-item>
      </template>
    </template>
  </el-menu>
</template>

<script>

export default {
  name: 'SideBar',
  components:
    SideBarItem: () => import('@/components/common/SideBarItem')
  },
  data () {
    return {

    }
  },
  mounted () {
  },
  methods: {
    selectItem(name, path){
      // alert(name)
      this.$router.push(path)
      this.$store.commit('common/updateMenuActiveName', name)
    }
  },
  computed: {
    menuList: {
      get () {
        return this.$store.state.common.menuList
      },
      set (val) {
        this.$store.commit('common/updateMenuList', val)
      }
    },
    menuActiveName: {
      get () { return this.$store.state.common.menuActiveName },
      set (val) { this.$store.commit('common/updateMenuActiveName', val) }
    },
    sidebarFold: {
      get() {return this.$store.state.common.sidebarFold;},
      set(val) {this.$store.commit("common/updateSidebarFold", val);}
    },
  },
}
</script>
<style lang="less" scoped>
.menu-wrap{
  width: 200px;
  min-height: 1020px;
  background: url('../../assets/img/sidebar_bg.png') no-repeat;
  background-size: 100% 100%;
}

/deep/ .el-menu{
  background-color: transparent !important;
  .iconfont {
    font-size: 18px;
    vertical-align: sub;
    margin-right: 5px;
    display: inline-block;
    width: 20px;
    text-align: center;
  }
}

/deep/ .el-menu-item,
/deep/ .el-submenu__title{
  color: #fff;

  .iconfont{
    color: #fff;
  }
}

/deep/ .el-menu-item span,
/deep/ .el-submenu__title span{
  padding-left: 10px;
}

/deep/ .el-menu-item.is-active {
  -webkit-box-shadow: inset 5px 100px 0px -2px #0064B6;
  box-shadow: inset 5px 100px 0px -2px #0064B6;
}

/deep/ .el-submenu__title:hover,
/deep/ .el-menu-item:hover{
  background: #0064B6;
}

/deep/ .el-menu-item-group__title{
  padding: 0;
}

</style>

Subcomponent SideBarItem

<template>
  <div class="menu">
    <template v-for="(item,index) in list">
      <!-- Title -->
      <template v-if="item.children.length" >
        <el-submenu :key="index" :index="item.id" class="sub-menu-item">
          <template :index="item.index" slot="title">
<!-- <i :class="item.icon"></i>-->
            <i class="iconfont icon-danganjianying"></i>
            <span>{{item.name}}</span>
          </template>
          <el-menu-item-group class="menu-item-group">
            <side-bar-item :list="item.children"></side-bar-item>
          </el-menu-item-group>
        </el-submenu>
      </template>
      <!-- Options -->
      <template v-else>
        <el-menu-item :key="index" :index="item.id" class="menu-item" @click="selectItem(item.name, item.path)">
<!-- <i :class="item.icon"></i>-->
          <i class="iconfont icon-danganjianying"></i>
          <span>{{item.name}}</span>
        </el-menu-item>
      </template>
    </template>
  </div>
</template>
<script>

export default {
  name: 'SideBarItem',
  // props: ['list'],
  props: {
    list: {
      type: Array || ''
    }
  },
  data () {
    return {
      treeData: [{
        label: 'province',
        children: [{
          label: 'Provincial Committee of the Communist Party of China'
          // children: [{
          // label: 'Level 3 1-1-1'
          // }]
        }, {
          label: 'CPC Provincial Office'
        }, {
          label: 'Organization Department of a certain province of the Communist Party of China'
        }
        ]
      }
      ],
      isShow: false
      // menuList: []
    }
  },
  mounted () {
    this.loadSysMenu()
  },
  methods: {
    loadSysMenu () {
      // console.log('menu', this.menuList)
    },
    // personManage (name) {
    // if (name === 'personnel management') {
    // this.isShow = !this.$store.state.common.rbflag
    // // alert('111' + this.isShow)
    // this.$store.commit('common/updateShowRbox', this.isShow)
    // }
    // },
    selectItem(name, path){
      // alert(name)
      this.$router.push(path)
      this.$store.commit('common/updateMenuActiveName', name)
    }
  },
}
</script>
<style lang="less" scoped>
.menu{
  width: 100%;

  .sub-menu-item /deep/ .el-submenu__title,
  .menu-item{
    height: 60px;
    line-height: 60px;
    text-align: left;
    //padding-left: 30px !important;
    //border-bottom: 1px solid #000;
    //border-right: 1px solid #000;
    color: #fff;
  }

  .sub-menu-item .el-menu-item{
    padding-right: 0;
  }

 /deep/ .el-menu-item .is-active{
    background-color: #0087df;
  }

  .menu-item:hover,
  /deep/ .el-submenu__title:hover{
    background-color: #0087df;
  }

  .menu-item span,
  .sub-menu-item /deep/ .el-submenu__title>span{
    font-weight: 700;
  }

  .menu-item-group /deep/ .el-menu-item-group__title{
    padding: 0 !important;
  }

  .menu-item-group .menu-item{
    background: url('../../assets/img/sidebar_bg.png') no-repeat;
  }

  .el-menu-item-group span{
    font-weight: normal;
  }

}

</style>

Later I found that the folding was not successful, and the style of the selected item did not change after selection. Later I found that it was not selected. After research, I found that it was because an extra layer of div was nested, and the el-menu-item-group project did not need this, so the improvement was as follows:

Parent component SideBar

<template>
  <el-menu class="menu-wrap" :default-active="menuActiveName" :collapse="sidebarFold" :collapseTransition="false" :unique-opened="true">
    <template>
      <el-menu-item @click="foldSideBar">
        <i v-show="!sidebarFold" class="el-icon-s-fold"></i>
        <i v-show="sidebarFold" class="el-icon-s-unfold"></i>
        <span slot="title" class="sidebar-one">Navigation List</span>
      </el-menu-item>
    </template>
    <side-bar-item v-for="menu in menuList" :key="menu.id" :menu="menu"></side-bar-item>
  </el-menu>
</template>

<script>

export default {
  name: 'SideBar',
  components:
    SideBarItem: () => import('@/components/common/SideBarItem')
  },
  data () {
    return {
    }
  },
  mounted () {
  },
  methods: {
    foldSideBar(){
      this.sidebarFold = !this.sidebarFold
      this.menuActiveName = 'NAV'
    }
  },
  computed: {
    menuList: {
      get () {
        return this.$store.state.common.menuList
      },
      set (val) {
        this.$store.commit('common/updateMenuList', val)
      }
    },
    menuActiveName: {
      get () {
        console.log(this.$store.state.common.menuActiveName)
        return this.$store.state.common.menuActiveName
      },
      set (val) {
        this.$store.commit('common/updateMenuActiveName', val)
      }
    },
    sidebarFold: {
      get() {return this.$store.state.common.sidebarFold;},
      set(val) {this.$store.commit("common/updateSidebarFold", val);}
    },
  },
}
</script>
<style lang="less" scoped>
.menu-wrap{
  width: 200px;
  min-height: 1020px;
  background: url('../../assets/img/sidebar_bg.png') no-repeat;
  background-size: 100% 100%;
}

/deep/ .el-menu{
  background-color: transparent !important;
  .iconfont {
    font-size: 18px;
    vertical-align: sub;
    margin-right: 5px;
    display: inline-block;
    width: 20px;
    text-align: center;
  }
}

/deep/ .el-menu-item,
/deep/ .el-submenu__title{
  color: #fff;

  .iconfont{
    color: #fff;
  }
}

/deep/ .el-menu-item span,
/deep/ .el-submenu__title span{
  padding-left: 10px;
}

/deep/ .el-menu-item.is-active {
  -webkit-box-shadow: inset 5px 100px 0px -2px #0064B6;
  box-shadow: inset 5px 100px 0px -2px #0064B6;
}

/deep/ .el-submenu__title:hover,
/deep/ .el-menu-item:hover{
  background: #0064B6;
}

</style>

Subcomponent SideBarItem

<template>
    <!-- There are submenus under this menu-->
    <el-submenu v-if="menu.children.length" :index="menu.code" :popper-append-to-body=false>
        <template slot="title">
            <i class="iconfont icon-danganjianying"></i>
            <span>{{ menu.name }}</span>
        </template>
        <side-bar-item v-for="item in menu.children" :key="item.id" :menu="item"></side-bar-item>
    </el-submenu>
    <!-- There is no submenu under this menu-->
    <el-menu-item v-else :index="menu.code" @click="selectItem(menu.code, menu.path)">
        <i class="iconfont icon-danganjianying"></i>
        <span>{{ menu.name }}</span>
    </el-menu-item>
</template>
<script>

export default {
  name: 'SideBarItem',
  // props: ['menu'],
  props: {
      menu:
      type: Object || {}
    }
  },
  data () {
    return {

    }
  },
  mounted () {
  },
  methods: {
    selectItem(code, path){
      // alert(name)
      console.log(code, path)
      this.$router.push(path)
      this.$store.commit('common/updateMenuActiveName', code)
    }
  },
}
</script>
<style lang="less" scoped>
.menu{
  width: 100%;

  .menu-item{
    height: 60px;
    line-height: 60px;
    text-align: left;
    color: #fff;
  }

  .sub-menu-item .el-menu-item{
    padding-right: 0;
  }

 /deep/ .el-menu-item .is-active{
    background-color: #0087df;
  }

  .menu-item:hover{
    background-color: #0087df;
  }

  .menu-item span{
    font-weight: 700;
  }

}

</style>

The function is basically implemented, but there is a bug. When the mouse clicks on the fold, a certain event will be called cyclically, resulting in a stack overflow error. To view the article, just set the attribute of the submenu: popper-append-to-body="false". Refer to the article: Element-ui NavMenu submenu uses recursive generation to use error

Finally, attach some simple test data:

testData: [
            {"id":"34161C2E8-7348-4439-8899-9A8039AE6AE4","pid":"0","code":"HOME","name":"Home","path":"/home","type":null,"icon":null,"sysId":"2761C2E8-7348-4439-8899-9A8039AE6AE3","orderNo":0,"isCheck":null,"children":[]},
            {"id":"703DBEBD-F92C-4347-9203-F60A73153C3F","pid":"0","code":"WD","name":"Temperature","path":"/temperature","type":null,"icon":null,"sysId":"2AB00274-73DF-459A-A02E-C79A4D8A8929","orderNo":0,"isCheck":null,"children":[]},
            {"id":"73660AB4-48D3-4BDB-86FD-C8397D4D54EC","pid":"0","code":"BJ","name":"Alarm","path":"/alarm","type":null,"icon":null,"sysId":"2AB00274-73DF-459A-A02E-C79A4D8A8929","orderNo":0,"isCheck":null,
              "children":[
                {"id":"1C99333D-886F-4AD6-93C4-7C5244E48247","pid":"73660AB4-48D3-4BDB-86FD-C8397D4D54EC","code":"FD","name":"Anti-theft","path":"/burg","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,"children":[]},
                {"id":"1DBDF678-F51F-444A-B995-61E5D9CCA5AF","pid":"73660AB4-48D3-4BDB-86FD-C8397D4D54EC","code":"JL","name":"Alarm bell","path":"/bell","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,"children":[]},
                {"id":"BFC8C2E1-0E5B-4EEE-B91D-3DABC63FF481","pid":"73660AB4-48D3-4BDB-86FD-C8397D4D54EC","code":"JS","name":"immersion","path":"/immersion","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,"children":[]},
                {"id":"BFC8C2E1-0E5B-4EEE-B91D-3DABC63FF482","pid":"73660AB4-48D3-4BDB-86FD-C8397D4D54EC","code":"MJ","name":"Access Control","path":"/punch","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,"children":[]},
                {"id":"BFC8C2E1-0E5B-4EEE-B91D-3DABC63FF483","pid":"73660AB4-48D3-4BDB-86FD-C8397D4D54EC","code":"ZT","name":"State","path":"/state","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,"children":[]}
              ]
            },
            {"id":"34161C2E8-7348-4439-8899-9A8039AE6AE5","pid":"0","code":"GZ","name":"Work","path":"/work","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,
              "children":[]
            },
            {"id":"0CD6B09A-AA43-4AE9-9AC7-29BC5AC83495","pid":"0","code":"SJ","name":"数据","path":"/data","type":null,"icon":null,"sysId":"2AB00274-73DF-459A-A02E-C79A4D8A8929","orderNo":0,"isCheck":null,
              "children":[]
            },
            {"id":"049C670D-A33E-4188-9206-B3F3B5DDE77B","pid":"0","code":"SP","name":"视频","path":"/video","type":null,"icon":null,"sysId":"3691C2E8-8848-4439-8899-9A8039AE6AB5","orderNo":0,"isCheck":null,"children":[]},
            {"id":"0A15DBB6-3241-4C7F-AAD4-5417E7BBECAA","pid":"0","code":"RZ","name":"Log","path":"/log","type":null,"icon":null,"sysId":"2AB00274-73DF-459A-A02E-C79A4D8A8929","orderNo":0,"isCheck":null,
              "children":[]
            }
          ]

The effect is as shown below:

insert image description here

After folding, as shown:

insert image description here

This is the end of this article about vue+elementUI component recursive implementation of foldable dynamic rendering multi-level sidebar navigation. For more related elementUI foldable dynamic sidebar navigation content, please search 123WORDPRESS.COM's previous articles or continue to browse the following related articles. I hope everyone will support 123WORDPRESS.COM in the future!

You may also be interested in:
  • Detailed explanation of how to use the navigation bar to jump to the route in element-ui
  • An example of using vue-router with ElementUI to implement navigation
  • Let's talk about the router problem of element-ui sidebar

<<:  Is it necessary to create a separate index for the MySQL partition field column?

>>:  File sharing between Ubuntu and Windows under VMware

Recommend

js realizes horizontal and vertical sliders

Recently, when I was doing a practice project, I ...

A brief discussion on the implementation principle of Vue slot

Table of contents 1. Sample code 2. See the essen...

MySQL multi-master and one-slave data backup method tutorial

Overview Operations on any one database are autom...

Detailed explanation of how to create MySql scheduled tasks in navicat

Detailed explanation of creating MySql scheduled ...

html opens a new window with a hyperlink and can control window properties

1. The window size opened by the HTML hyperlink C...

VMware, nmap, burpsuite installation tutorial

Table of contents VMware BurpSuite 1. Virtual mac...

HTML discount price calculation implementation principle and script code

Copy code The code is as follows: <!DOCTYPE HT...

Docker creates MySQL explanation

1. Download MySQL Image Command: docker pull mysq...

In-depth analysis of the slow query problem of MySQL Sending data

Through an example, I shared with you the solutio...

Detailed explanation of SELINUX working principle

1. Introduction The main value that SELinux bring...

Solve the problem of inconsistency between mysql time and system time in docker

Recently, when I installed MySQL in Docker, I fou...

A brief introduction to Vue filters, lifecycle functions and vue-resource

1. Filter Example: <!DOCTYPE html> <html...

A magical MySQL deadlock troubleshooting record

background Speaking of MySQL deadlock, I have wri...

How to monitor the running status of docker container shell script

Scenario The company project is deployed in Docke...

The difference and introduction of ARGB, RGB and RGBA

ARGB is a color mode, which is the RGB color mode...
