Vue encapsulation component upload picture component

<template>
  <div>
    <el-form>
      <!-- :on-change="uploadFile" -->
      <el-upload
        :limit="limit" //The maximum number of uploads allowed action
        accept="image/*" //Accept upload:on-change="uploadFile" //Function when file status changeslist-type="picture-card" //File list type:auto-upload="false" //Whether to upload immediately after selecting a file:file-list="fileList" //Virtual file array:on-exceed="handleExceed" //Function when the number of files exceeds the limit:on-preview="handlePictureCardPreview" //Function when clicking on an uploaded file in the file list:on-remove="handleRemove" //Function when removing a file from the file listref="upload"
        class="avatar-uploader"
        :class="{hide:showUpload}" //Used to hide the upload button after reaching the maximum limit: disabled="disabled" //To view the upload failure process>
        <i class="el-icon-plus"></i>
      </el-upload>
      //View the image <el-dialog width="30%" :visible.sync="dialogVisible">
        <img width="100%" :src="imgUrl.url" alt />
      </el-dialog>
      //If you don't need to upload directly, but need to click a button to upload the image, please open this method //Change on-change in the el-upload tag above to http-request method<!-- <Button text="Upload" type="add_u" style="margin-top: 10px;" @click.native="submitUpload"></Button> -->
    </el-form>
  </div>
</template>

<script>
//Introduce the upload image interface import { uploadImg } from "@/api/public/api";
export default {
  props: {
    limit: Number,
    fileList: Array,
    disabled: Boolean,
  },
  data() {
    return {
      showUpload: false, //Close the upload button after controlling the maximum limit dialogVisible: false, //View the image pop-up box imgUrl: [], //Collection of addresses after uploading the image};
  },
  //Listen to the array of uploaded pictures (to handle the automatic rendering problem and the disappearance of the upload button when modifying);
  watch:
    fileList(newName, oldName) {
      if (newName.length == this.limit) this.showUpload = true;
      else this.showUpload = false;
    },
  },
  methods: {
    //Function for removing files from the file list handleRemove(file, fileList) {
      const index = this.fileList.findIndex((item) => item === file.uid);
      this.imgUrl.splice(index, 1);
      this.$emit("delUrl", this.imgUrl);
      if (fileList.length < this.limit) this.showUpload = false;
    },
    //Function when clicking an uploaded file in the file list handlePictureCardPreview(file) {
      this.imgUrl.url = file.url;
      this.dialogVisible = true;
    },
    //This is a method for uploading via a button instead of directly uploading submitUpload() {
      this.$refs.upload.submit();
    },
    //Function when file status changes (main logic function)
    uploadFile(e, fileList) {
      //Judge the maximum number of user uploads to make the upload button disappear if (fileList.length >= this.limit) this.showUpload = true;
      // const file = e.file; <- here it is not necessary to upload directly but upload through the button const file = e.raw; // <- here it is uploaded directly // size const size = file.size / 1024 / 1024 / 2;
      if (
        !(
          file.type === "image/png" ||
          file.type === "image/gif" ||
          file.type === "image/jpg" ||
          file.type === "image/jpeg"
        )
      ) {
        this.$notify.warning({
          title: "Warning",
          message:
            "Please upload images in the formats of image/png, image/gif, image/jpg, image/jpeg",
        });
      } else if (size > 2) {
        this.$notify.warning({
          title: "Warning",
          message: "Image size must be less than 2M",
        });
      } else {
        if (this.limit == 1) this.imgUrl = []; //When judging it as one, the array needs to be cleared const params = new FormData();
        params.append("source", file);
        uploadImg(params).then((res) => {
        //The data structure returned here (modify according to your own return structure)
          if (res.data.status === 1) {
            this.$message.success("Upload successful");
            this.imgUrl = res.data;
            //Call the parent component method to pass the image parameter this.$emit("getUrl", this.imgUrl);
          } else this.$message.error("Upload failed");
        });
      }
    },
    //Function when the number of files exceeds the limit handleExceed(files, fileList) {
      this.$message.info(`Only ${this.limit} pictures can be uploaded`);
    },
  },
};
</script>

//Modify the styles before and after uploading here (I think el-upload is not good-looking and you can modify it yourself)
<style scope>
.hide .el-upload--picture-card {
  display: none !important;
}
.avatar-uploader > .el-upload {
  width: 200px;
  height: 200px;
  line-height: 200px;
  border-radius: 0px;
  background: #fff;
  border: 1px dashed #ccc;
}
.avatar-uploader > .el-upload > i {
  font-size: 28px;
  color: #ccc;
}
.avatar-uploader > .el-upload-list {
  display: block;
}
.avatar-uploader > .el-upload-list > .el-upload-list__item {
  width: 200px;
  height: 200px;
  display: block;
}
.avatar-uploader > .el-upload-list > .el-upload-list__item > img {
  width: 200px;
  height: 200px;
  border-radius: 0px;
}
</style>

//Image upload component import UploadImg from "@/views/common/UploadImg.vue";
Vue.component('UploadImg', UploadImg)

<el-form-item label="Upload picture">
 //limit the maximum number of images to upload //fileList image array //getUrl get the uploaded address //delUrl delete the uploaded address // disabled disable processing <UploadImg :limit="1" :file-list="fileList" @getUrl="getUrl($event,'Parameters you need to carry')" @delUrl="delUrl($event,'Parameters you need to carry')" :disabled="true" />
</el-form-item>

//Variable declaration data:{
 fileList:[]
 }
//Function getUrl(getUrl){
 console.log(getUrl)
 };
delUrl(getUrl){
console.log(getUrl)
};
