Example of how to build a Harbor public repository with Docker

The previous blog post talked about the Registry private warehouse. Today, let’s configure the Harbor warehouse. Harbor can be used as a public warehouse or a private warehouse. Today, let’s configure how Harbor implements public and private warehouses.

For more information about Registry public repositories, please visit the blog post: Deploy Docker private repositories Registry

The difference between Registry and Harbor

Registry: It is a private image repository with poor graphical support and is used by small enterprises.
Harbor: supports visual management, private and public repositories, and image management and control;

Advantages of Docker Harbor

VMWare's open source image management solution;
Support graphical management;
Easy access and configuration;
Facilitates image access control;
Support mirroring responsibility strategy;
Audit and count the usage of user access images;

Docker Harbor dependent programs

Python;
Install Docker;
Docker Compose;

1. Build Harbor Warehouse

Case description:

Two CentOS7.4, one server and one client (for testing);

Both servers need to install the Docker service. My Docker version is 19.03.9.

For more information about installing Docker containers, please visit: Install Docker.v19.03.9

1. Configure Docker Compose

Visit the Daoyun official website, find the installation of Docker Compose, and copy the command to the Docker server: Daoyun

[root@centos01 ~]# curl -L https://get.daocloud.io/docker/compose/releases/download/1.25.5/docker-compose-`uname -s`-`uname -m` > /usr/local/bin/docker-compose
<!--Download Docker Compose-->
[root@centos01 ~]# chmod +x /usr/local/bin/docker-compose <!--Docker Compose adds execution permissions-->
[root@centos01 ~]# docker-compose -v <!--View Docker Compose version-->
docker-compose version 1.25.5, build 8a1c60f6

2. Configure Docker Harbor public repository

1) Open Github official website

Open Github official website and search for harbor, then click goharbor/harbor, then click "releases", download the corresponding version according to your needs, and upload it to the server (the URL is as follows: https://github.com/goharbor/harbor/releases. You can also download the online installation package, which I haven't tried, so you can try it yourself), as follows:

2) Configure Harbor warehouse

harbor-online-installer-v1.9.1.tgz <!--Upload Harbor compressed package-->
[root@centos01 ~]# tar zxvf harbor-online-installer-v1.9.1.tgz -C /usr/local/
  <!--Unzip harbor to /usr/local/directory-->
[root@centos01 ~]# cd /usr/local/harbor/ <!--Enter the Harbor directory-->
[root@centos01 harbor]# cp harbor.yml harbor.yml.bak <!--Backup Harbor main configuration file-->
[root@centos01 harbor]# vim harbor.yml <!--Modify Harbor main configuration file-->
 5 hostname: 192.168.100.10 <!--Change to the Docker server IP address-->
<!--hostname can be a domain name, but the domain name also requires changing the hosts file or installing DNS. I will use the IP address here-->
 8 http: <!--Use http protocol-->
10 port: 80 <!--80 port number-->
27 harbor_admin_password: Harbor12345 <!--Default password, can be customized-->
[root@centos01 harbor]# ./install.sh <!--Install Harbor-->
[Step 0]: checking installation environment ...

Note: docker version: 19.03.9

Note: docker-compose version: 1.25.5
……………… <!--Some content is omitted here-->
Creating harbor-log ... done
Creating registryctl ... done
Creating redis ... done
Creating harbor-portal ... done
Creating registry ... done
Creating harbor-db ... done
Creating harbor-core ... done
Creating nginx ... done
Creating harbor-jobservice ... done

✔ ----Harbor has been installed and started successfully.----

Now you should be able to visit the admin portal at http://www.benet.com .
For more details, please visit https://github.com/goharbor/harbor .
   <!--The above code appears after the installation is complete, indicating success-->
[root@centos01 ~]# vim /usr/lib/systemd/system/docker.service <!--Edit this configuration file-->
14 ExecStart=/usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock --insecure-registry 192.168.100.10:80
 <!--Locate this line and add "--insecure-registr" to specify Harbor's IP and its listening port-->
[root@centos01 harbor]# systemctl daemon-reload <!--Run docker as a daemon-->
[root@centos01 harbor]# systemctl restart docker <!--Restart Docker service-->
[root@centos01 harbor]# docker-compose stop <!--Stop all containers-->
[root@centos01 harbor]# docker-compose start <!--Start all containers-->
[root@centos01 harbor]# netstat -anptu |grep 80 <!--Listen to port 80-->
tcp6 0 0 :::80 :::* LISTEN 23473/docker-proxy

3) After the installation is complete, use the browser to access the Harbor repository

4) Create a public repository

5) Ensure that the image public repository has been created successfully

6) Log in to the Harbor repository on the Docker server

[root@centos01 ~]# docker login -uadmin -pHarbor12345 192.168.100.10:80 <!--Log in to Harbor warehouse-->
WARNING! Using --password via the CLI is insecure. Use --password-stdin.
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store

Login Succeeded <!--This prompt indicates that the login is successful-->
[root@centos01 ~]# docker tag tomcat:latest 192.168.100.10:80/image/nginx:nginx
   <!--Modify the image tag-->
[root@centos01 ~]# docker push 192.168.100.10:80/image/nginx:nginx
  <!--Upload the image to the Harbor repository-->
[root@centos01 ~]# docker logout 192.168.100.10:80 <!--Docker server exits Harbor-->
Removing login credentials for 192.168.100.10:80

7) Harbor checks whether the image is uploaded successfully

3. Configure the Docker client

<!--Docker client installs Docker service-->

1) Modify the configuration file to load the Docker Harbor server [root@centos02 ~]# vim /usr/lib/systemd/system/docker.service <!--Edit this configuration file-->
ExecStart=/usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock --insecure-registry 192.168.100.10:80
 <!--Locate this line and add "--insecure-registr" to specify Harbor's IP and its listening port-->
[root@centos02 ~]# systemctl daemon-reload <!--Daemon process runs docker-->
[root@centos02 ~]# systemctl restart docker <!--Restart docker service-->
[root@centos02 ~]# docker login -uadmin -pHarbor12345 192.168.100.10:80
   <!--docker client logs in to Harbor-->
WARNING! Using --password via the CLI is insecure. Use --password-stdin.
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store

Login Succeeded <!--Login successful-->
[root@centos02 ~]# docker pull 192.168.100.10:80/image/nginx:nginx
 <!--Docker client downloads the image in the Harbor public repository-->
[root@centos02 ~]# docker images <!--View Docker client image-->
REPOSITORY TAG IMAGE ID CREATED SIZE
192.168.100.10:80/image/nginx nginx 1b6b1fe7261e 7 days ago 647MB

4. Create a Harbor private warehouse

1) Create a private warehouse

2) Create a user

3) Add the newly created private user to the private repository

4) Upload the image to the Harbor private warehouse

[root@centos01 ~]# docker tag tomcat:latest 192.168.100.10:80/private/tomcat:tomcat
  <!--Docker server modifies the image tag-->
[root@centos01 ~]# docker login -uprivate -pHarbor12345 192.168.100.10:80
   <!--Log in to Harbor private warehouse-->
WARNING! Using --password via the CLI is insecure. Use --password-stdin.
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store

Login Succeeded <!--Login successful-->
[root@centos01 ~]# docker push 192.168.100.10:80/private/tomcat:tomcat
  <!--Upload the image to a private repository-->

5) Harbor checks whether the image is uploaded successfully

6) The Docker client downloads the image in the private repository

[root@centos02 ~]# docker login -uprivate -pHarbor12345 192.168.100.10:80
  <!--Docker client logs in to Harbor private warehouse-->
WARNING! Using --password via the CLI is insecure. Use --password-stdin.
WARNING! Your password will be stored unencrypted in /root/.docker/config.json.
Configure a credential helper to remove this warning. See
https://docs.docker.com/engine/reference/commandline/login/#credentials-store

Login Succeeded <!--Login successful-->
[root@centos02 ~]# docker pull 192.168.100.10:80/private/tomcat:tomcat
   <!--Docker client downloads the image in the Harbor private warehouse-->
[root@centos02 ~]# docker images <!--Docker client checks whether the image is downloaded successfully-->
REPOSITORY TAG IMAGE ID CREATED SIZE
192.168.100.10:80/image/nginx nginx 1b6b1fe7261e 7 days ago 647MB
192.168.100.10:80/private/tomcat tomcat 1b6b1fe7261e 7 days ago 647MB

7) Harbor supports log statistics function

This is the end of this article about how to use Docker to build a Harbor public repository. For more information about how to use Docker to build a Harbor public repository, please search for previous articles on 123WORDPRESS.COM or continue to browse the following related articles. I hope you will support 123WORDPRESS.COM in the future!
