MySQL 5.7 and above version download and installation graphic tutorial

1. Download

1. MySQL official website download address: https://downloads.mysql.com/archives/community/

2. After downloading, unzip it. The unzipped image is as shown below:

3. Place the unzipped folder in your preferred location

2. Configure MySQL

1. In the mysql-5.7.17-winx64 directory, create a new my.ini. Just copy the following code and save it. my.ini will replace the following my-default.ini file

Note: The contents of the my.ini file:

[mysql]

; Set the default character set for the mysql client

default-character-set=utf8

[mysqld]

; Set port 3306

port = 3306

; Set the installation directory of mysql

basedir=F:\mysql-5.7.10-winx64

; Set the storage directory for mysql database data

datadir=F:\mysql-5.7.10-winx64\data

; Maximum number of connections allowed

max_connections=200

; The default character set used by the server is the 8-bit latin1 character set

character-set-server=utf8

; The default storage engine that will be used when creating new tables

default-storage-engine=INNODB

3. Install MySQL service

1. Right-click the Start button and select Search and enter cmd. A command prompt will appear. Right-click and select Run as Administrator. Otherwise, an error code of "Insufficient identity" will appear.

2. After opening the cmd window as an administrator, switch the directory to the bin directory of your unzipped file. Then enter mysqld install and press Enter to run it. Note that it is mysqld, not mysql. Installation success will appear. Since I already installed it, this is what happened.

3. At this time, we can use mysqld --initialize to initialize the data directory first:

4. Change password

1. Add a command skip-grant-tables under the [mysqld] entry in the my.ini configuration file, and then restart mysql

2.

(1) Enter the MySQL database:

mysql> use mysql;Database changed

(2) Set a new password for the root usermysql> update user set authentication_string=password("new password") whereuser="root";

Query OK, 1 rows affected(0.01sec)Rows matched: 1 Changed: 1Warnings: 0

(3) Refresh the database (be sure to remember to refresh) mysql>flush privileges; QueryOK, 0 rows affected (0.00 sec)

(4) Exit mysql: mysql> quit

Finally, comment out skip-grant-tables in the configuration file. Next time you enter mysql -uroot -p you can log in with the new password
